1/10 ep rwd r/c drift car assembled chassis set (8 pages)
Summary of Contents for Yokomo MASTER SPEED MS 10
Page 2
走行してして下さい。 ① スピー ドコン トローラのスイッチをOFFにします。 ② バッテリーの接続を外します。 ③ 送信機のスイッチをOFFにし、 アンテナを縮めます。 Thank you for purchasing this Yokomo product. This high performance competition kit has been proudly manufactured by Yokomo - World Champion R/C car manufacturer. Proper assembly of this product will provide fun, safe enjoyment. PRECAUTIONS FOR SAFE ENJOYMENT OF YOUR R/C CAR For children under the age of 13, parental guidance is recommended when running. ■ ASSEMBLY PRECAUTIONS ■ ■ PRECAUTIONS BEFORE RUNNING ■ ■ BATTERY USAGE ■ ● Do not assemble around small children. The ● Yokomo R/C cars are built for competition use, and (Carefully read the instruction included with the batteries) parts can be dangerous if accidentally some models may exceed speeds of 40km per hour. ● When charging batteries, make sure that the swallowed. Practice common sense and run the car in open safe surrounding area is void of anything highly flammable. places, or R/C car tracks. ● Check the contents carefully before Also avoid charging in high-temperature locations. assembly. Please contact Customer Support ● Do not run the car on public roads with high amounts ...
Page 4
1 スプールの組立て Spool Assembly B9-501MA はめ込む ZC-BH310A ソリッドアクスル Put in. M3x10 ボタンヘッド Solid Axle BHS Screw このページで使用するパーツ B9-501MA Parts used on this page はめ込む フランジ Put in. Flange ビス袋から必要に応じてお選びください。 B9-501MCSA Please choose from screw bags as needed. ドライブカップ Drive Cup ZC-BH310A B9-501MCSA M3x10 ボタンヘッド ×2 ドライブカップ BHS Screw B9-BTCA Drive Cup ベルト調整カム Belt Tension Adjusting Cam 袋 #1 の内容 Bag #1 Contents はめ込む Put in. ZC-BH310A B9-501MA B9-501MA M3x10 ボタンヘッド...
Page 5
3. ギヤデフの組立て Gear Diff Assembly B10-500GMA ケースリング Case Ring B9-503GPA クロスピン Cross Pin B9-503GSA B9-503GPA デフシム (S) デフギヤ (S) Diff Shim (S) Diff Gear (S) このページで使用するパーツ B10-500GMA ケースリング Parts used on this page Case Ring CS-7500B ギヤデフオイル #7500 ×1 Gear Diff Oil オイル量の基準は 1.5g。 CS-7500B クロスピンが隠れるまで 袋 #1 の内容 ギヤデフオイル #7500 入れる。 Gear Diff Oil Bag #1 Contents Reference amount of oil is 1.5g. Oil is put in until a pin hides.
Page 6
4. プーリーの組立て Pulley Assembly はめ込む。 Put in. B10-630MA ドライブプーリーハウジング Drive Pulley Housing 向きに注意 Pay attention to the direction of the part. SG-A6490 スパーギヤ 90T Spur Gear B10-630OA ドライブプーリーハブ Drive Pulley Hub このページで使用するパーツ Parts used on this page B10-630CA C クリップ 袋 #3 の内容 C-Clip Bag #3 Contents B10-630OA ドライブプーリーハブ ×1 Drive Pulley Hub B10-630MA ドライブプーリーハウジング ×1 Drive Pulley Housing ZC-S100SA φ10mm/0.2mm シム Shim SG-A6490 スパーギヤ 90T ×1 Spur Gear ZC-S100SA...
Page 7
5. メインシャシーの組立て 注意!ー各バルクヘッドには向きがありますので MS-32RLB 取付には注意して下さい。 リヤロアバルクヘッド (B) Main Chassis Assembly Important! ー Please pay attention to the direction Rear Lower Bulkhead (B) of the bulkheads when installing. このページで使用するパーツ 溝が双方、内側になるように取り付けて下さい。 Please install so that both grooves are on Parts used on this page the inside. MS-32RLA リヤロアバルクヘッド (A) Rear Lower Bulkhead (A) MS-002 メインシャシー ×1 MS-32FLB Main Chassis フロントロアバルクヘッド (B) Front Lower Bulkhead (B) ZC-F36-A ZC-F38A M3x6 サラビス ×8 M3x8 サラビス ×4 FHS Screw FHS Screw MS-32FLA フロントロアバルクヘッド (A) ZC-F315A Front Lower Bulkhead (A) M3x15 サラビス ×2 FHS Screw...
Page 8
6. ギヤデフ、センターマウントの組立て ZC-A3620BA 2mm アルミスペーサー ・ 黒 ZC-BH36-A Gear Diff,Center Mount Assembly 2mm Aluminum Spacer ・ Black M3x6 ボタンヘッド BHS Screw ZC-F310A このページで使用するパーツ MS-302M M3x10 サラビス BD-351LA ZC-M3DWA Parts used on this page モーターマウント FHS Screw ドライブベルト サラワッシャー Motor Mount Drive Belt Rosette Washer B10-CFMA ZC-BH35A ファンマウント M3x5 ボタンヘッド ×1 Fan Mount BHS Screw ZC-F36-A M3x6 サラビス ×2 BB-730-4A プーリー FHS Screw 3x7 ベアリング...
Page 9
7. ベルトテンション調整 Belt Tension Adjustment プーリー位置が高い場合 ミドル〜ローグリップ路面向け Medium-Low grip tracks. Upper Diff Position ●FRONT● ●REAR● ゆるむ Loosen ゆるむ Loosen はる Tighten はる Tighten プーリー位置が低い場合 Lower Diff Position ●FRONT● ●REAR● はる 2mm レンチ等で調整して下さい。 Tighten 2mm Allen wrench. はる Tighten ベルトの張り調整を行う場合は、アッパーバルクヘッドのビスを 軽く緩め、イラストの様にベルト調整カムのミゾを利用すれば簡 単に行う事ができます。 ゆるむ ( 必ず左右対称で同じカム位置に合わせてください。) Loosen To adjust belt tension,slightly loosen the upper bulkhead cap screws, and reposition the cams as shown in the illustration. ゆるむ (Make sure that the left and right cams are adjusted to ...
Page 10
9. サスアームの組立て ZC-BH26A R 側も対称に組立てます。 ●FRONT● M2x6 ボタンヘッド Assemble each side in the Suspension Arm Assembly BHS Screw same manner . B11-008A フロントショックマウント R このページで使用するパーツ B11-008A Front Shock Mount R フロントショック Parts used on this page マウント L Front Shock Mount L 溝にはめ込む ZC-SS38A Attach to the groove. 3.5mm 程度出す M3x8 セットスクリュー ×4 Extend about 3.5mm. Set Screw ZC-411A E リング・4mm はめ込む E-ring Put in. ZC-SS48A M4x8 セットスクリュー ×4 MS-009S Set Screw MS-412SB サスボール キャップ ...
Page 11
10. サスアームの取付け Suspension Arm Installation ●FRONT● ZC-A3820BA 2mm アルミスペーサー ・ 黒 2mm Aluminum Spacer ・ Black このページで使用するパーツ Parts used on this page ZC-F38A M3x8 サラビス ×8 FHS Screw 袋 #7 の内容 Bag #7 Contents ZC-F38A M3x8 サラビス FHS Screw ZC-A3820BA 2mm アルミスペーサー ・ 黒 ZC-A3820BA 2mm Aluminum Spacer ・ Black 2mm アルミスペーサー ・ 黒 ×8 2mm Aluminum Spacer ・ Black ●REAR● ZC-A3820BA 2mm アルミスペーサー ...
Page 12
B11-412MAA 11. スタビの取付け B9-412REA ●FRONT● スタビマウント (A) スタビエンド (A) Stabilizer Installation Stabilizer Mount A ZC-F36-A Stabilizer End A M3x6 サラビス MS-412F1 FHS Screw グレーの部分をカット はめ込む フロント スタビワイヤー (φ1.1) このページで使用するパーツ してください。 Put in. Front Stabilizer Wire (φ1.1) Parts used on this page Please remove the gray shaded area. B11-412MBA 反対側も。 スタビマウント (B) the other side too. Stabilizer Mount B ZC-SS325LA B11-412OA M3x2.5 O リング (φ1) ネジロック剤付セットスクリュー x4 O-ring 1.5mm Set Screws w/Thread Locking ZC-SS33A ②...
Page 13
12. フロントハブキャリアの組立て 2 セット作ります。 ネジロック剤 &D カットに当てる。 Assemble 2 Sets . Use screw lock adhesive. Front Hub Carrier Assembly Contact the D-cut surface. B11-010TWA B11-010TWA 2mm ジョイントピン M3x2 セットスクリュー B9-500DPA Joint Pin Set Screw ジョイントプロテクター Joint Protector D カット D カット D-Cut D-Cut B11-010BWA ブラックグリス フロントボーン Front Bone ブラックグリス B11-010TWA このページで使用するパーツ ジョイント Parts used on this page Joint CS-BGA ブラックグリス ブラックグリス ×1 Black Grease ネジロック剤...
Page 14
13. リヤハブキャリアの組立て 2 セット作ります。 Assemble 2 Sets . Rear Hub Carrier Assembly B9-010RAA リヤユニバーサルシャフト ( 完成済 ) Assembled Rear Universal Drive shaft B9-500DPA B9-415SGA ジョイントプロテクター ステアリングブロック Joint Protector Steering Block BB-1050PA BB-1050PA 5x10 ベアリング 5x10 ベアリング Bearing Bearing ブラックグリス ZC-C25NA M2x5 キャップスクリュー Cap Screw ピン溝にはめ込む Attach to the pin groove. このページで使用するパーツ B10-011A Parts used on this page ホイルハブ Wheel Hub ① CS-BGA ブラックグリス ×1 Black Grease ③...
Page 15
14. フロント ハブキャリアの取付け 反対側も対称に組立てます Front Hub Carrier Installation Assemble each side in the same manner. フロントハブキャリア (R) Front Hub Carrier (R) 注意!ー①ドライブカップスリットには必ず ( ブラックグリス ) を塗る様に して下さい。 Important! ー①Always apply black grease to the drive cup. ドライブカップスリット Drive Cup Slit ダイレクト用 Direct ジョイントプロテクター用 Joint Protector ドライブカップに嵌め込む。 Put into the drive cup. フロントハブキャリア (L) このページで使用するパーツ Front Hub Carrier (L) Parts used on this page ドライブカップ Drive Cup 袋 #7 の内容 MS-009S ② サスボール キャップ Bag #7 Contents スペーサー 1.5mm Sus Ball Cap ...
Page 16
15. リヤ ハブキャリアの取付け 反対側も対称に組立てます Rear Hub Carrier Installation Assemble each side in the same manner. リヤ ハブキャリア (R) リヤ ハブキャリア (L) 注意!ー①ドライブカップスリットには必ず Rear Hub Carrier (R) Rear Hub Carrier (L) ( ブラックグリス ) を塗る様に して下さい。 ドライブカップに嵌め込む。 Important! ー①Always apply black grease Put into the drive cup. to the drive cup. ドライブカップスリット Drive Cup Slit ダイレクト用 Direct ① はめ込む Put in. ジョイントプロテクター用 Joint Protector このページで使用するパーツ ② Parts used on this page 袋 #7 の内容 Bag #7 Contents MS-009S サスボール キャップ ...
Page 17
16. ステアリングロッド , ベルクランクの組立て B9-TB39AA 2 セット作ります。 Steering Rod,Bell Crank Assembly 39mm ターンバックル Assemble 2 Sets . 39mm Turnbuckle ボールエンドキャップ このページで使用するパーツ Ball Cup 片側が逆ネジになっています。 Parts used on this page One side of the turnbuckle is B9-207A 26mm B9-207A reverse threaded. ボールエンドキャップ ボールエンドキャップ ターンバックル Ball Cup Ball Cup Turnbuckle ZC-BH36-A ZC-BH38-A B9-TB20AA M3x6 ボタンヘッド ×2 M3x8 ボタンヘッド ×5 1 セット作ります。 20mm ターンバックル BHS Screw BHS Screw Assemble 1 Set.
Page 18
17. サーボの取付け ZC-F36-A M3x6 サラビス Servo Installation FHS Screw このページで使用するパーツ Parts used on this page ZC-F36-A はめ込む M3x6 サラビス ×3 Put in. FHS Screw 18. アッパーデッキの取付け Upper Deck Installation ZC-BH36-A M3x6 ボタンヘッド BHS Screw このページで使用するパーツ Parts used on this page ZC-BH36-A M3x6 ボタンヘッド ×12 BHS Screw MS-003R リヤ アッパーデッキ Rear Upper Deck ZC-BH36-A 袋 #12 の内容 M3x6 ボタンヘッド Bag #12 Contents BHS Screw MS-003F フロント アッパーデッキ ×1 Front Upper Deck MS-003F フロント アッパーデッキ...
Page 19
19. フロント & リヤ ショックの組み立て フロント用、リヤ用各 2 セットを作ります。 Assemble 2 front and 2 rear shocks. Front&Rear Shock Assembly ③ ② MS-S116 O リングにキズをつけないよう注意。 ピストン Try not to scratch the o-ring. Piston このページで使用するパーツ ZC-410A E リング・2mm Parts used on this page E-ring YS-450B S4-S3XA ショックオイル #450 ×1 X30 X リング (3.0mm) Shock Oil X ring ① MS-S2B シャフトガイド Shaft Guide 袋 #13 の内容 向きに注意 Pay attention to the Bag #13 Contents MS-S5S direction of the part.
Page 20
20. フロント & リヤ ショックの取付け Front&Rear Shock Installation ●FRONT● フロント ショック Front Shock Assembly ZC-BH310A M3x10 ボタンヘッド BHS Screw 反対側も同様に。 フロント ショック Some on the other side. Front Shock Assembly ZC-A3615BA 1.5mm アルミスペーサー ・ 黒 1.5mm Aluminum Spacer ・ Black ZC-A3615BA ZC-A3620BA 1.5mm アルミスペーサー ・ 黒 2mm アルミスペーサー ・ 黒 1.5mm Aluminum Spacer ・ Black 2mm Aluminum Spacer ・ Black 注意!ーボールの動きが渋い場合は ペンチ等で挟んで調整をし て下さい。...
Page 21
22. バンパーの組立てのつづき ZC-F38A M3x8 サラビス Bumper Assembly FHS Screw B11-016H ボディ マウント シーソー Body Mount Seesaw ① ① ② RC-313MA フードピン このページで使用するパーツ Hood Pin 袋 #14 の内容 Parts used on this page Bag #14 Contents ② ZC-F38A B11-016H RC-313MA RC-313MA M3x8 サラビス ×2 ボディマウントシーソー ×2 フードピン ×2 フードピン FHS Screw Body Mount Seesaw Hood Pin Hood Pin B11-016H 23. リヤボディポストの取付け ボディ ポスト R ...
Page 22
面取加工モーター推奨。 24. モーターの取付け ZC-SS33A Edge trimming motor M3x3 セットスクリュー Motor Installation recommendation. Set Screw 別途ご用意下さい。 Sold separately. 平らな面 Flat side ピニオンギヤ Pinion Gear 別途ご用意下さい。 モーター 別途ご用意下さい。 Sold separately. Motor Sold separately. 仮止程度に。 Lightly tighten. ZC-BH38-A M3x8 ボタンヘッド BHS Screw 注意! ①キットにはモーター、ピニオンギヤは含まれておりませんので、別途ご用意下さい。 ②ピニオンギヤの取り付けはモーターシャフトの D カット されている部分にセットスクリューが当たる様、 しっかりと締め込んで下さい。 ③バックラッシュは少し隙間が出来る程度に調整して下さい。 (調整不足はノイズ及びギヤ破損の原因になります。) ④連続走行はモーターに必要以上の負荷を掛けるだけでなく寿命も短くなりますので完全に冷えた事を確認して から走行をさせて下さい。 Important! ①Motor and pinion gear not included in kit.
Page 23
受信機、スピードコントローラー ( 別途ご用意下さい。 ) 25. 受信機、スピードコントローラー、 Receiver and speed controller.(Sold separately.) バッテリーの取付け サイズに合わせて Receiver,ESC,Battery Installatio カットします。 Cut to size. 注意! ①受信機、スピードコントローラーの固定は付属の両面テープ ZC-203BA を使用し、シャーシにしっかりと固定して下さい。 両面テープ (接着面をクリーナーなどで脱脂しておくと、はがれにくく Double -Sided Tape はめ込む なります。) Put in. ②余ったアンテナ線は稼働部分に触れない様に注意して下さい。 ③バッテリープレートは外れにくいよう固めにできています。 B9-118A Important! ①Secure the receiver and speed controller to the バッテリープレート chassis using double-sided tape. Battery Plate (Cleaning the surface with motor spray will ensure better adhesion. ) ②Make sure to bundle any remaining antenna wire so that it does not interfere with the drivetrain. ③Battery plate is made to be hardened so as not to come off. このページで使用するパーツ はめ込む...
