- Page 1 Instructions for use Upright refrigerator - freezer...
-
Page 2: Table Of Contents
Refrigerator is used in households for storage of fresh food at temperatures above 0°C). Freezer is used in households for freezing fresh food and storage of frozen food for up to one year (depending on the type of food). -
Page 3: Before Fi Rst Operation
• Always disconnect the appliance from power supply (pull the power cord from wall socket) before cleaning and before replacing the light bulb. • If the power supply cord is damaged, in order to avoid hazard it must be replaced by the service or by qualifi ed personnel. - Page 4 The symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring...
-
Page 5: Description Of The Appliance
• Drawers are protected against accidental extraction. To extract the drawer from the appliance, open it and lift front part upwards, then pull it out. Certain models are fi tted with pull-out slide guides which facilitate opening. Pull-out guide drawers (or shelves) are extracted by lifting the rear end and pulling out inclined under the 45°... - Page 6 • Drawers are protected against accidental extraction. To extract the drawer from the appliance, open it and lift front part upwards, then pull it out. Certain models are fi tted with pull-out slide guides which facilitate opening. Pull-out guide drawers (or shelves) are extracted by lifting the rear end and pulling out inclined under the 45°...
-
Page 7: Installation And Connection
• Place the appliance fl atly and fi rmly on a solid base. The appliance is fi tted with adjustable feet on the front side, used to level the appliance. Rear side of the appliance is fi tted with wheels (certain models only) facilitating the positioning of the appliance at the preselected place. - Page 8 * Applies to OLD TIMER appliances (in the model marking …O…). Connecting to power Connecting to power • Use the power cord to connect the appliance to the mains supply supply power. Wall outlet must be fi tted with ground terminal (safety socket).
-
Page 9: Reverse Door Swing
Fix the attached stopper with its bearing on the opposite side of the door. 4. Unscrew the forced door closure system (B) and fi x it to the opposite side of the door (certain models only). -
Page 10: Control Panel - Appliance With Electronical Regulation
Model with knobs CONTROL UNIT II Model without knobs A Temperature selector and ON/OFF button B Green LED: illuminated when the appliance is in operation* C Freezer alarm off button* D Red LED: fl ashing with freezer alarm* E Fast freeze button* F Orange LED: on during fast freezing procedure* * Certain models only. - Page 11 (the appliance, however, is still under mains power). Setting freezer Setting freezer • Temperature of the appliance is set by turning the button A to temperature temperature the position between the Min and Max span. • Recommended setting of the thermostat knob is to Eco position.
- Page 12 E ON/OFF button and temperature setting F Orange light lit: Intensive freezing option is on G Digital temperature display: indicates actual refrigerator temperature from +1°C to + 9°C, for freezer from - 16°C to - 24°C and SF (intensive freezing).
- Page 13 E select the intensive freezing option (SF) and wait for 5 seconds for the setting to be saved. Orange light (F) is lit. If the setting is not switched off manually, it will be switched off automatically after approximately two days.
- Page 14 (intermittent beep), red light (D) is fl ashing. • Alarm is switched of by pressing the knob C. Red light goes off automatically when the freezer is cooled suffi ciently and there is no danger for stored food to get foul.
- Page 15 N Refrigerator temperature digital display: indicates temp. range +1°C do +9°C. Switching the appliance Switching the appliance Before the fi rst use of the appliance fi rst plug the power cable ON/OFF ON/OFF into the wall socket. Display indicates dashes for both the refrigerator and the freezer.
- Page 16 (continuous tone) and red signal lamp J is on. The alarm is automatically switched off when the door is closed, but you can also switch it off by pressing the alarm off button (I). Intermittent sound - freezer/refrigerator temperature is too...
- Page 17 During the fi rst start of the appliance there is a 24 hour delay of the temperature alarm to avoid unnecessary alarm operation.. Intermittent alarm sound - power failure signal If the temperature of the refrigerator or freezer is raised too much as a consequence of power failure, sound alarm is activated (intermittent tone), red signal lamp is on, and the display fl...
-
Page 18: Control Panel - Appliance With Mechanical Regulation
Control panel - appliance with mechanical regulation CONTROL UNIT V Model without fan Model with fan A Temperature setting and ON/OFF button B Illumination ON/OFF push-button... - Page 19 ON/OFF button ON/OFF button The appliance is switched on by turning the button A in clockwise direction, towards Max. The appliance is switched off when the dot is positioned against (the appliance is still powered). Temperature setting Temperature setting • Temperature of the refrigerator is set with button A which can be positioned between the Min and Max range.
- Page 20 • Turning the fan on / off ON = OFF = When the fan is on, a red dot is indicated on the switch. Note: When the fan is activated, power consumption is increased and temperature in the refrigerator drops.
-
Page 21: Recommended Distribution Of Food
Recommended Refrigerator compartments: distribution of food distribution of food - top section: canned food, bread, wine, cake, … - middle section: dairy products, cheese, readymade food, desserts, juices, beer, TV-dinners, … - bottom section: meat, meat products, delicatessen, … - crisp pan: resh fruit, vegetables, salads, appliances without ZERO’N’FRESH drawer also: root vegetables, potatoes,... -
Page 22: Storing Fresh Food
Maximum load of the rack is 9 bottles of 0,75 l, or 13 kg of total mass - see label at the right side of the interior of the appliance. -
Page 23: Freezing And Storage Of Frozen Food
• 24 hours before freezing fresh food, activate the rapid freezing function (freeze boost): - control unit I, II, III and IV: press the E key or rotate the A button to the SF position; - control unit V with or without the fan: rotate the A button to the mid point between Min and Max;... - Page 24 It is imperative that food is frozen as quickly as possible. We therefore recommend the size of the package not to be too large and to be cooled before placing into the freezer. The amount of the fresh foods that can be loaded in the freezer as a single load is declared on the rating plate.
-
Page 25: Defrosting The Appliance
Making ice Remove the cap from ice tray (certain models only) and fi ll it to the mark with fi ltered cold water. Close it and place it on the door shelf. Ice tray can freeze 8 cubes. It is recommended to make ice on stock. -
Page 26: Cleaning
• Clean the interior of the appliance and wipe it dry (see chapter Cleaning). • Before reloading food into the freezer switch the appliance on. Defrosting traditional Defrosting traditional • Defrosting of NO FROST freezer is automatic. Periodic freezer freezer appearance of frost layer eventually disappears automatically. -
Page 27: Troubleshooting Guide
Troubleshooting guide Fault: Cause/Remedy The appliance does not operate • Check if there is power in the socket and if the appliance is after connection to the mains: switched on. Cooling system operates • Ambient temperature too high. continuously without intermittent •... -
Page 28: Noise Level
• If the green LED is fl ashing, call the nearest service center. Troubleshooting helpful hints: • If you are not able to fi x the trouble by any of the above tips, turn the thermostat button to the position...
