Summary of Contents for Gorenje UKM235XNF

  • Page 1 Instructions for use Upright freezer...

  • Page 2: Table Of Contents

    Thank you for your confi dence in buying our appliance and congratulations on the excellent choice. We hope it will successfully serve its purpose for many years. Upright freezer is used in households for freezing fresh food and storage of frozen food for up to one year (depending on the type of food).

  • Page 3: Before Fi Rst Operation

    • The appliance must be connected to the mains supply in accordance with the standing regulations and local requirements. • The appliance must not be used in open air or exposed to weather precipitation. • Always disconnect the appliance from power supply (pull the power cord from wall socket) before cleaning and before replacing the light bulb.
  • Page 4 • Rating plate with basic information is located in the interior of the appliance. If the sticker plate is not suitable for your language, replace it with the attached one. • Warning: Ventilation slots on the appliance or built-in element should always be kept clean and unobstructed.

  • Page 5: Description Of The Appliance

    • Drawers are protected against accidental extraction. To extract the drawer from the appliance, open it and lift front part upwards, then pull it out. Certain models are fi tted with pull-out slide guides which facilitate opening. Pull-out guide drawers are extracted by lifting the rear end and pulling out inclined under the 45°...
  • Page 6 • Drawers are protected against accidental extraction. To extract the drawer from the appliance, open it and lift front part upwards, then pull it out. Certain models are fi tted with pull-out slide guides which facilitate opening. Pull-out guide drawers are extracted by lifting the rear end and pulling out inclined under the 45°...

  • Page 7: Installation And Connection

    • Place the appliance fi rmly on a fl at and solid base. The appliance is fi tted with adjustable feet on the front side, used to level the appliance. Rear side of the appliance is fi tted with wheels (certain models only) facilitating the positioning of the appliance at the preselected place.
  • Page 8 Connecting to power • Use the power cord to connect the appliance to the mains supply power. Wall outlet must be fi tted with ground terminal (safety socket). Nominal voltage and frequency are indicated on the relevant label or rating plate of the appliance.

  • Page 9: Reverse Door Swing

    Fix the attached stopper with its bearing on the opposite side of the door. 4. Unscrew the forced door closure system (B) and fi x it to the opposite side of the door (certain models only). 5. Tilt the appliance backward (max. 35°) to lean to the rear side of the cabinet.

  • Page 10: Control Panel - Appliance With Electronical Regulation

    D Red LED: fl ashing with freezer alarm E Fast freezing button* F Orange LED: on during fast freezing procedure G Digital freezer temperature display indicates actual freezer temperature inside the appliance from -16°C to -24°C* * Certain models only.
  • Page 11 (the appliance, however, is still under mains power). Setting freezer • Temperature of the appliance is set by turning the button A to temperature the position between the Min and Max span. • Recommended setting of the thermostat knob is to Eco position (around -18°C in appliances with digital display).
  • Page 12 The ‘Super Freeze’ • Use this setting after turning on the appliance for the fi rst time, function before cleaning, and when inserting larger quantities of food (see “freezing procedure”). - control unit I : press the E button – The orange LED F lights up.

  • Page 13: Control Panel - Appliance With Mechanical Regulation

    To activate: rotate the temperature setting knob in the clockwise direction towards the Max position. When the appliance is switched on for the fi rst time, a red LED lights up; this LED will go off when the refrigerator has cooled down to a temperature at which there is no more danger of damage to the food.

  • Page 14: Freezing And Storage Of Frozen Food

    • 24 hours before freezing fresh food, activate the Super Freeze function: - control unit I: press the E button; - control units II and III: rotate the A knob to the SF position (Super Freeze). After 24 hours, insert the fresh food into the freezing drawer.
  • Page 15 Making ice Remove the cap from ice tray (certain models only) and fi ll it to the mark with fi ltered cold water or some other liquid, suitable for freezing. Close it and place it on the door shelf. One tray can be placed over the other.

  • Page 16: Defrosting The Appliance

    • Avoid using defrosting sprays, as they may cause damage to the plastic parts and may be hazardous to health. • Clean the interior of the appliance and wipe it dry (see chapter Cleaning). • Before reloading food into the freezer switch the appliance on prior.

  • Page 17: Cleaning

    Please remove traces of any cleaning detergents you may have used. • To clean any surface, use a soft cloth. • Clean the exterior of the appliance with water and mild liquid detergent. • For cleaning of plastic, coated, or aluminum parts avoid using abrasive or special cleansing agents (like the stainless steel polish), otherwise you may damage the surface.

  • Page 18: Troubleshooting Guide

    Troubleshooting guide Fault: Cause/Remedy The appliance does not operate • Check if there is power in the socket and if the appliance is after connection to the mains: switched on. Cooling system operates • Check air circulation for suffi cient cooling of the compressor, continuously without intermittent and clean the condenser.

  • Page 19: Noise Level

    Troubleshooting helpful hints: • If you are not able to fi x the trouble by any of the above tips, turn the thermostat button to the position ,disconnect the power cord from the mains outlet, wait 10 minutes, and reconnect the appliance.
  • Page 20 ZOS 3167, ZOF 2467 FREEZER 142541/en (07-08)
