- Page 1 DETAILED INSTRUCTIONS FOR USE OF UPRIGHT FREEZER www.gorenje.com www.gorenje.com...
- Page 2 We thank you for the confidence you have shown by purchasing our appliance. We wish you find a lot of pleasure in its use. The appliance is intended solely for household use. The freezer is intended for freezing fresh food and for long-term storage of frozen food (up to one year, depending on the type of food).
-
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION IMPORTANT NOTES AND PRECAUTIONS 10 ADVICE FOR SAVING POWER WITH REFRIGERATION APPLIANCES 11 APPLIANCE DESCRIPTION APPLIANCE DESCRIPTION 12 INSTALLATION AND CONNECTION 15 CHANGING THE DIRECTION OF DOOR OPENING 19 OPERATING THE APPLIANCE 25 APPLIANCE INTERIOR EQUIPMENT STORING AND 26 FREEZING AND STORING FROZEN FOOD FREEZING FOOD... -
Page 4: Important Notes And Precautions
IMPORTANT NOTES AND PRECAUTIONS BEFORE USING THE APPLIANCE FOR THE FIRST TIME Before connecting the appliance to the power mains, please read carefully the instructions for use which describe the appliance and its correct and safe use. The instructions apply to several appliance types/models; thus, settings or equipment may be described herein which is not available in your appliance. - Page 5 IMPORTANT SAFETY INSTRUCTIONS WARNING! Risk of fire/flammable materials. The appliance must be connected to the power mains and grounded in compliance with the effective standards and regulations. WARNING! Do not locate multiple portable socket-outlets or portable power supplies at the rear of the appliance. Before cleaning the appliance, unplug it from the power mains (unplug the power cord from the wall outlet).
- Page 6 Danger of frostbite Never put frozen food in your mouth and avoid touching frozen food as this may cause frostnip or frostbite. Safety of children and vulnerable persons The appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
- Page 7 Children aged from 3 to 8 years are allowed to load and unload refrigerating appliances. Warning regarding the refrigerant The appliance contains a small amount of an environmentally friendly yet flammable gas R600a. Make sure that no parts of the cooling system are damaged. A gas leak is not hazardous to the environment, but it could cause eye injury or fire.
- Page 8 IMPORTANT INFORMATION ON THE USE OF APPLIANCE WARNING! This appliance is intended to be used in household and similar applications such as: – staff kitchen areas in shops, offices and other working environments; - farm houses and by clients in hotels, motels and other residential type environments;...
- Page 9 Technical information on the appliance Rating plate can be found in the appliance interior. It indicates data on voltage, gross and net volume, type and amount of refrigerant, and information on the climate classes. If the language on the rating plate is not the language of your choice or the language of your country, replace it with the one supplied.
-
Page 10: Advice For Saving Power With Refrigeration Appliances
ADVICE FOR SAVING POWER WITH REFRIGERATION APPLIANCES • Install the appliance as specifi ed in the instruction manual. • Do not open the door more often than necessary. • Occasionally make sure air circulation underneath the appliance is unobstructed. • Condenser unit on the rear wall should be kept clean (see chapter Cleaning the appliance). -
Page 11: Appliance Description
APPLIANCE DESCRIPTION Control unit 2 Led lighting of freezer interior 3 NO FROST freezing unit (cooler, fan ...) 4 Freezing and storage compartment 5 Foot • The drawers are protected against pulling out. To remove a drawer from the appliance, pull it out as far as it will go, then lift at the front and pull out completely. -
Page 12: Installation And Connection
INSTALLATION AND CONNECTION SELECTING THE ROOM • Install the appliance in a dry and well ventilated room. The appliance will operate correctly if the environment temperature is in the interval specifi ed in the table. The appliance class is indicated on the rating plate / label with the basic information on the appliance. Class Temperature from +10°C to +32°C... - Page 13 • Do not expose the appliance to direct sunlight and do not place it near any source of heat. If this cannot be avoided, install an insulation panel. • The appliance may stand alone or it may be placed ext to a cupboard or a wall. Consider the clearance required to fully open the door in order to allow pulling out the drawers and shelves (see installation diagram).
- Page 14 Note: When placing the appliances side by side, the anti-dew (anti-condensation) set has to be purchased and installed! Code for ordering the set: dry room (relative humidity below 60%) Code for ordering the set METAL PLATE (INOX) 576604 PLASTIC PLATE WHITE 672114 GREY...
-
Page 15: Changing The Direction Of Door Opening
CHANGING THE DIRECTION OF DOOR OPENING VERSION I – CONTROLS IN THE APPLIANCE INTERIOR Tools required: socket wrench No. 8, Phillips screwdriver, torx 25, flat screwdriver The procedure to change the direction of door opening should be carried out by at least two persons. - Page 17 VERSION II – CONTROLS ON THE DOOR Tools required: socket wrench No. 8, Phillips screwdriver, torx 25, flat screwdriver The procedure to change the direction of door opening should be carried out by at least two persons. 1. Remove the upper hinge cover (A), the connector cover (B1) and the covering cap (M). 2.
-
Page 19: Operating The Appliance
OPERATING THE APPLIANCE CONTROL UNIT 1 A Temperature adjustment and freezer boost key B Freezer temperature display C Freezer boost function indicator D Alarm indicator SWITCHING THE APPLIANCE ON/OFF When you connect your appliance to the mains for the first time, it will be in standby mode (powered, but switched off). - Page 20 ADJUSTING THE TEMPERATURE IN THE APPLIANCE • Adjust the temperature as desired with the A key. • Press the A key until the desired temperature is set. • Recommended setting is -18 °C. FREEZER BOOST FUNCTION To activate the freezer boost function, press the A key until the symbol C lights up.
- Page 21 HIGH TEMPERATURE ALARM If the temperature inside the appliance is too high, acoustic alarm will be activated (intermittent tone) and the D symbol will flash. • Acknowledge and turn off the acoustic alarm by pressing the A key. If the alarm is not deactivated manually, it will be sounded for the fi...
- Page 22 CONTROL UNIT 2 (CONTROLS ON THE DOOR) A Temperature adjustment and freezer boost key B Freezer temperature display C Freezer boost function indicator D Alarm indicator...
- Page 23 SWITCHING THE APPLIANCE ON/OFF When you connect your appliance to the mains for the first time, it will be in standby mode (powered, but switched off). To switch on the appliance press A key for 3 seconds. To switch off the appliance press again A key for 3 seconds.
- Page 24 FREEZER BOOST FUNCTION To activate the freezer boost function, press the A key until the symbol C lights up. • Use this setting after switching on the appliance for the fi rst time, before cleaning, or 24 hours before adding a large amount of food.
-
Page 25: Appliance Interior Equipment
APPLIANCE INTERIOR EQUIPMENT (* EQUIPMENT DEPENDS ON THE MODEL) STORAGE BIN (MULTIBOX)* • The MultiBox bin is convenient for storing food with a strong or pungent smell. • The silicone lid provides an air-tight seal that prevents the food from drying out and the odour to spread throughout the refrigerator compartment. -
Page 26: Freezing And Storing Frozen Food
FREEZING AND STORING FROZEN FOOD FREEZING PROCESS Maximum amount of fresh food that may be inserted at once is specified on the appliance rating plate. If the amount of food to be frozen exceeds the indicated amount, the quality of freezing will be inferior;... -
Page 27: Important Warnings On Freezing Fresh Food
IMPORTANT WARNINGS ON FREEZING FRESH FOOD Only freeze the food that is suitable for freezing in the freezer. Make sure the food you freeze is of high quality and fresh. Choose appropriate packaging and use the packaging correctly. Packaging should not be permeable to humidity; it should be airtight to prevent the food from drying out and loss of vitamins. -
Page 28: Storage Of Industrially Frozen Food
STORAGE OF INDUSTRIALLY FROZEN FOOD • When storing and using frozen food, observe the manufacturer's instructions. Temperature and expiry date are indicated on the packaging. • Only choose food with undamaged packaging, stored in freezers at temperatures of -18°C or lower. •... -
Page 29: Defrosting The Appliance
DEFROSTING THE APPLIANCE DEFROSTING A NO FROST FREEZER • The NO FROST freezer will defrost automatically. Occasional frost that may appear on the walls will disappear automatically. • Build-up of ice or frost in the freezer compartment can be a result of abnormal use of appliance (door opened too frequently and/or too long, door not properly closed etc.). -
Page 30: Cleaning The Appliance
CLEANING THE APPLIANCE Before cleaning, unplug the appliance from the power mains – switch off the appliance (see chapter Switching the Appliance On/Off) and unplug the power cord from the wall outlet. • Use a soft cloth to clean all surfaces. Cleaners that contain abrasive substances, acids, or solvents are not suitable for cleaning as they may damage the surface. -
Page 31: Troubleshooting
TROUBLESHOOTING Problem: Cause or remedy: Appliance is connected • Make sure there is voltage in the power outlet and that to the power mains but it the appliance is switched on. does not work. Cooling system operates • Too high environment temperature. continuously for a long •... -
Page 32: Information About Appliance Noise
WE RESERVE THE RIGHT TO MAKE CHANGES THAT DO NOT AFFECT THE FUNCTIONALITY OF THE APPLIANCE. Instructions for use of the appliance can also be found on our website at www.gorenje. com / < http://www.gorenje.com />... - Page 36 FREEZER_FS600_ADVANCED en (12-19)
