  • Page 3: Table Of Contents

    Table of contents Table of contents General information........................................5 1.1 Symbols and signal words....................................5 Safety instructions.......................................... 6 Scope of delivery..........................................7 Assembly.............................................. 9 Protecting the environment....................................15 MPS-450 E-Drum Set...
  • Page 4 MPS-450 E-Drum Set...
  • Page 5: General Information

    Our products and documentation are subject to a process of continuous development. They are therefore subject to change. Please refer to the latest version of the documentation, which is ready for download under www.thomann.de. 1.1 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this document.
  • Page 6: Safety Instructions

    Safety instructions Safety instructions DANGER! Risk of injury and choking hazard for children! Children can suffocate on packaging material and small parts. Children can injure themselves when handling the device. Never allow chil‐ dren to play with the packaging material and the device. Always store packaging material out of the reach of babies and small children. Always dispose of packaging material properly when it is not in use.
  • Page 7: Scope Of Delivery

    Scope of delivery Scope of delivery Before you assemble your e-drum set, use the following list and the figure to ensure the contents of the package are complete. Item Qty. Lateral support tube on the left Lateral support tube on the right Support tube for left crossbeam Support tube for right crossbeam Upper horizontal connection tube...
  • Page 8 Scope of delivery ö & (2 ×) (2 ×) (3 ×) < (4 ×) (2 ×) MPS-450 E-Drum Set...
  • Page 9: Assembly

    Assembly Assembly Overview Loosen the screws of the clamps before sticking the tubes together. Mount the various elements in the specified sequence. The final positions of the components are shown in the illustration below. Hi-hat pad (10 inch) Crash (12 inch), ride (12 inch) Tom pad 1 (8 inch), tom pad 2 (8 inch), tom pad 3 (8 inch) Snare pad (10 inch) Bass drum pad (8 inch)
  • Page 10 Assembly Assembling the rack CAUTION! Risk of cuts to the hands from sharp edges during assembly! Tools, screws and components can have sharp edges that can cause cuts during assembly. Pay attention to sharp edges when assembling and screwing the individual parts. Wear protective gloves if necessary. &...
  • Page 11 Assembly Then tighten the mounting screws with the drum key (23). Insert the brackets (10, 11) for the cymbals (crash, ride) and the hi-hat into the provided mounting clamps on the rack. Use the mounting screws to attach the brackets at the required height. Loosen the retaining screws on the bracket joints and turn the brackets into the desired playing positions.
  • Page 12 Assembly Mounting cymbals on the rack Unscrew the wing nuts from the cymbal holders (10) and take the felt washers off the holders. Place the cymbals (13) as shown in the figure on the holders. Be sure to attach the crash pad (10 inch) to the left holder and the ride pad (12 inch) to the right cymbal holder.
  • Page 13 Assembly Setting up the bass drum pedal Engage the bolt of the bass drum pedal (17) in the designated recess on the bass drum pad (16). Place the beater (18) into the hole provided on the rotary head of the pedal (16) and tighten the fastening screw with the drum key (23).
  • Page 14 Assembly Set-up and cabling Set up the rack, the pads and the cymbals according to your needs. Finally, position the bass drum pedal with the bass drum pad and the hi-hat pedal in front of the rack and connect all trigger cables to the e-drum module. MPS-450 E-Drum Set...
  • Page 15: Protecting The Environment

    When disposing of the device, comply with the rules and regulations that apply in your country. You can also return your old device to Thomann GmbH at no charge.
