- Page 1 Rookie E-Drum Set...
- Page 2 Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 Internet: www.thomann.de 06.10.2022, ID: 549098...
- Page 3 Table of contents Table of contents Safety instructions.......................................... 4 Scope of delivery..........................................5 Assembly.............................................. 6 Protecting the environment....................................12 Rookie E-Drum Set...
-
Page 4: Safety Instructions
Safety instructions Safety instructions DANGER! Danger for children Ensure that plastic bags, packaging, etc. are disposed of properly and are not within reach of babies and young children. Choking hazard! Ensure that children do not detach any small parts (e.g. knobs or the like) from the unit. They could swallow the pieces and choke! Never let children unattended use electrical devices. -
Page 5: Scope Of Delivery
Scope of delivery Scope of delivery Before you assemble the drum set, make sure the contents of package is complete according to the following list and figure. ö & Item Qty. Drum module Millenium Rookie Tom pad 1, Tom pad 2, Tom pad 3, Snare pad (7" each, Mesh Head) Hi-hat pedal, Bass Drum pedal Cymbal (Crash, Ride), Hi-hat pad (8"... -
Page 6: Assembly
Assembly Assembly Overview Mount the various elements in the specified sequence. The final positions of the components are shown in the illustration below. ö Drum module Millenium Rookie Tom pad 1, Tom pad 2, Tom pad 3, Snare pad (7" each, Mesh Head) Hi-hat pedal, Bass Drum pedal Cymbal (Crash, Ride, Hi-hat pad, 8"... - Page 7 Assembly Assembling the rack & Loosen the wing screws of the rack feet (6) and plug the rack feet onto the lateral supports of the rack (5). Then tighten the wing screws of the rack feet (6). Loosen the fixing screws of the rack clamps on the three lateral crossbeams using the drum key (12) and turn the cross‐ beams into the desired playing position.
- Page 8 Assembly Mounting pads on the rack Screw the pads (2) to the provided holes at the bottom side with two fixing screws (11) and one mounting clamp (10) each. Fixthe pads in the provided positions at the rack (5). Align the pads on the rack to meet your needs, then tighten the fixing screws (11) of the mounting clamps (10) evenly using the drum key (12).
- Page 9 Assembly Mounting the drum module on the rack ö ö Screw the drum module (1) to the provided holes at the bottom side with two fixing screws (11) and one mounting clamp (10). Fix the drum module in the provided position at the rack (5). Align the drum module on the rack to meet your needs, then tighten the fixing screws (11) of the mounting clamp (10) evenly using the drum key (12).
- Page 10 Assembly Mounting cymbals on the rack Insert the brackets (7, 8) for the cymbals and the Hi-hat into the provided mounting clamps on the rack. Fasten the brackets using the wing screws of the mounting clamps at the desired height. Put as shown two felt washers (14), the Hi-hat pad (4) and the Hi-hat nut (15) on the bracket for the Hi-hat (8).
- Page 11 Assembly Set-up and cabling ö Place as shown the Bass Drum pedal (2) centred under the rack, the Hi-hat pedal (2) to the left of the rack. Set up the rack, the pads and the cymbals according to your needs The pads and cymbals are wired with the triggers of the multiple cable (9) with the drum module (1).
-
Page 12: Protecting The Environment
Protecting the environment Protecting the environment Disposal of the packaging material For the transport and protective packaging, environmentally friendly materials have been chosen that can be supplied to normal recycling. Ensure that plastic bags, packaging, etc. are properly disposed of. Do not just dispose of these materials with your normal household waste, but make sure that they are collected for recycling. - Page 13 Notes Rookie E-Drum Set...
- Page 14 Notes Rookie E-Drum Set...
- Page 16 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
