1.
INSTRUCTIONS FOR USE ........................................................................... 4
2.
SAFETY PRECAUTIONS .............................................................................. 6
3.
ENVIRONMENTAL RESPONSIBILITY .......................................................... 8
4.
DESCRIPTION OF CONTROLS.................................................................... 9
5.
USING THE HOB......................................................................................... 10
6.
CLEANING AND MAINTENANCE ............................................................... 13
7.
POSITIONING ON THE HOB TOP.............................................................. 15
8.
ELECTRICAL CONNECTION...................................................................... 17
9.
GAS CONNECTION .................................................................................... 18
10. ADAPTATION TO DIFFERENT TYPES OF GAS....................................... 20
THESE INSTRUCTIONS ARE VALID ONLY FOR THE DESTINATION COUNTRIES
WHOSE IDENTIFYING SYMBOLS ARE INCLUDED ON THE COVER OF THIS
MANUAL. THIS IS A CLASS 3 BUILT-IN HOB.
INSTRUCTIONS FOR THE USER: these instructions contain user
recommendations, a description of the controls and the correct
procedures for cleaning and maintenance of the appliance.
INSTRUCTIONS FOR THE INSTALLER: these are intended for the qualified
technician who must install the appliance, set it functioning and carry out
an inspection test.
Contents
3
Advertisement
Table of Contents
Related Manuals for Smeg P755ABBN
Summary of Contents for Smeg P755ABBN
-
Page 1: Table Of Contents
INSTRUCTIONS FOR THE INSTALLER: these are intended for the qualified technician who must install the appliance, set it functioning and carry out an inspection test. -
Page 2: Instructions For Use
General instructions 1. INSTRUCTIONS FOR USE THIS MANUAL IS AN INTEGRAL PART OF THE APPLIANCE. IT MUST BE KEPT IN ITS ENTIRETY AND IN AN ACCESSIBLE PLACE FOR THE WHOLE WORKING LIFE OF THE HOB. WE ADVISE YOU TO READ THIS MANUAL AND ALL THE INFORMATION IT CONTAINS CAREFULLY BEFORE USING THE HOB. -
Page 3: General Instructions
ALWAYS CHECK THAT THE CONTROL KNOBS ARE IN THE (OFF) POSITION WHEN YOU FINISH USING THE HOB. NEVER PLACE PANS WITH BOTTOMS WHICH ARE NOT PERFECTLY FLAT AND SMOOTH ON THE COOKING HOB PAN STANDS. NEVER USE PANS WHICH PROJECT BEYOND THE OUTSIDE EDGE OF THE HOB. -
Page 4: Safety Precautions
DO NOT REMOVE THIS PLATE ON THE CASING FOR ANY REASON. BEFORE CONNECTING THE DEVICE, MAKE SURE THAT IT HAS BEEN REGULATED FOR THE TYPE OF GAS THAT WILL FEED IT, CHECKING THE LABEL UNDER THE CASING. BEFORE CARRYING OUT INSTALLATION/MAINTENANCE WORK, MAKE SURE THAT THE APPLIANCE IS NOT CONNECTED TO THE POWER GRID. - Page 5 General instructions DO NOT LET CHILDREN GO NEAR THE APPLIANCE WHEN IT IS IN OPERATION OR PLAY WITH IT AT ANY TIME. DO NOT INSERT POINTED METAL OBJECTS (CUTLERY OR UTENSILS) INTO THE SLITS IN THE APPLIANCE. DO NOT USE STEAM JETS FOR CLEANING THE APPLIANCE.
-
Page 6: Environmental Responsibility
Therefore, at the end of the product's... -
Page 7: Description Of Controls
All the hob controls are grouped together on the front central area. CONTROL ZONE KNOB DESCRIPTION To light the flame, press the knob and, at the same time, turn it anticlockwise to the maximum flame symbol To adjust the flame, turn the knob to the zone between the... -
Page 8: Using The Hob
Each rack must be positioned on the corresponding burner in order to guarantee proper operation. Be very careful to match the different central diameters of the racks to the flame-spreader crowns. At the ends of the legs of the racks there are... - Page 9 Hold down the knob for about 2 seconds to keep the flame lit and to activate the safety device. The burner may go out when the knob is released. If this happens, repeat the procedure, holding the knob down for longer.
- Page 10 3 Medium Rapid 18-24 4 Large Rapid 20-26 • Do not use griddles or plates to cook or heat food on the ultra-rapid/ triple crown burner; • Do not place aluminium foil under the burners during use • It is not advisable to use earthenware or steatite pans to cook or heat...
-
Page 11: Cleaning And Maintenance
To clean and preserve the glass and brass surfaces, always use only specific products that do not contain abrasives or chlorine-based acids. How to use: pour the product onto a damp cloth and wipe the surface, rinse thoroughly and dry with a soft or microfibre cloth. - Page 12 Cleaning parts 6.2.1 Knobs The knobs should be cleaned with a soft cloth dampened with warm water, then dried carefully. For ease of cleaning they can be extracted by pulling upwards. Do not use aggressive products containing alcohol or products for cleaning steel and glass when cleaning the knobs, as these products could cause permanent damage.
-
Page 13: Positioning On The Hob Top
In case of installation on an empty kitchen unit with doors, a separation panel must be placed under the hob. Keep a minimum distance of 10 mm between the bottom of the hob and the surface of the panel, which must be easily extractable to allow sufficient access for... - Page 14 The figure to the side shows the exact holes to be used to correctly attach the hob to the work surface with brackets. IMPORTANT: If the hob is to be installed on top of an oven, ensure that the latter is equipped with a cooling fan.
-
Page 15: Electrical Connection
Do not remove this plate for any reason. The plug at the end of the supply cable and the wall socket must be of the same type and must conform to the applicable legislation on electrical installations. -
Page 16: Gas Connection
The hob is preset for natural gas G20 (2H) at a pressure of 20 mbar. To set it up for supply using other types of gas, see “5. ADAPTATION TO DIFFERENT TYPES OF GAS”. The gas inlet connection is threaded ½”... - Page 17 The air vents, protected by grills, must be the right size to comply with current regulations and positioned so that no part of them is obstructed, not even partially.
-
Page 18: Adaptation To Different Types Of Gas
Before carrying out the following operations, disconnect the appliance from the power supply The hob is preset for natural gas G20 (2H) at a pressure of 20 mbar. If other types of gas are to be used, the nozzles must be replaced and the primary air must be adjusted. - Page 19 Instructions for the installer 10.2 Replacement of nozzles on the cooker hob Unscrew screw C and push air regulator D as far as it will go. Using a 7-mm wrench, remove nozzle E and replace it with the appropriate nozzle, following the instructions in the tables for the type of gas to be used.
-
Page 20: Burner And Nozzle Characteristics Table
Instructions for the installer 10.3 Burner and nozzle characteristics table Rated heating Burner LPG – G30/G31 50 mbar capacity (kW) Nozzle Reduced Capacity Capacity diameter capacity g/h G30 g/h G31 1/100 mm Auxiliary 1.05 Semi-rapid Medium Rapid Large Rapid 1050... - Page 21 G30 g/h G31 1/100 mm Auxiliary 1.05 Semi-rapid 1.65 Medium Rapid Large Rapid 1050 Rated heating Burner Natural gas – G20/G25 20/25 mbar capacity (kW) Nozzle diameter Reduced capacity 1/100 mm Auxiliary 1.05 Semi-rapid Medium Rapid Large Rapid 1050...
-
Page 22: Primary Air Adjustment
If after adjusting the air the flame is in the modes shown in the diagram: the following changes need to be made: A: the flame is noisy, unstable and is separated from the burner: the primary air is too open. - Page 23 Burner and nozzle characteristics table”. After adjustment with a gas other than the preset one, replace the label on the casing with the label corresponding to the new gas. The label is in the bag with the nozzles provided. 10.7 Arrangement of the burners on the hob...
