Smeg A31G7IXIA Instructions For Installation And Use Manual

Smeg range instructions for installation and use
Hide thumbs

Advertisement

Table of Contents

1. INSTRUCTIONS FOR USE ........................................................38
ENVIRONMENT..........................................................................39
3. SAFETY INSTRUCTIONS ..........................................................40
4. GET TO KNOW YOUR APPLIANCE ..........................................42
5. BEFORE INSTALLATION...........................................................43
6. USING THE HOB........................................................................44
7. CLEANING AND MAINTENANCE ..............................................57
8. INSTALLING THE APPLIANCE..................................................60
9. GAS CONNECTION ...................................................................64
11. FINAL OPERATIONS FOR GAS APPLIANCES.........................68
INSTRUCTIONS FOR THE USER: these contain user advice, description
of the commands and the correct procedures for cleaning and maintenance
of the appliance
INSTRUCTIONS FOR THE INSTALLER: these instructions are intended
for the qualified technician who must perform the installation, put it into
operation and test the appliance
Contents
37

Advertisement

Table of Contents
loading

Related Manuals for Smeg A31G7IXIA

Summary of Contents for Smeg A31G7IXIA

  • Page 1: Table Of Contents

    1. INSTRUCTIONS FOR USE ...38 2. INSTRUCTIONS FOR DISPOSAL – OUR CONCERN FOR THE ENVIRONMENT...39 3. SAFETY INSTRUCTIONS ...40 4. GET TO KNOW YOUR APPLIANCE ...42 5. BEFORE INSTALLATION...43 6. USING THE HOB...44 7. CLEANING AND MAINTENANCE ...57 8. INSTALLING THE APPLIANCE...60 9.

  • Page 2: Instructions For Use

    Precautions for use 1. INSTRUCTIONS FOR USE THIS MANUAL IS AN INTEGRAL PART OF THE APPLIANCE. IT MUST BE KEPT IN ITS ENTIRETY AND IN AN ACCESSIBLE PLACE FOR THE WHOLE WORKING LIFE OF THE HOB. WE URGE YOU TO READ THIS MANUAL AND ALL THE INFORMATION IT CONTAINS CAREFULLY BEFORE USING THE APPLIANCE.

  • Page 3: Instructions For Disposal - Our Concern For The Environment

    Instructions for disposal 2. INSTRUCTIONS DISPOSAL – CONCERN FOR THE ENVIRONMENT Our product's packing is made of non-polluting materials, therefore compatible with the environment and recyclable. Please help by disposing of the packaging correctly. You can obtain the addresses of collection, recycling and disposal centres from your retailer or from the competent local organisations.

  • Page 4: Safety Instructions

    THE GLASS CERAMIC HOB, SWITCH THE APPLIANCE OFF AND CONTACT AN AUTHORISED TECHNICAL ASSISTANCE CENTRE. USERS OF PACEMAKERS OR SIMILAR DEVICES MUST ENSURE THAT THE OPERATION OF THEIR DEVICES WILL NOT BE AFFECTED BY THE INDUCTION FIELD, WHICH HAS A FREQUENCY RANGE OF 20-50 KHZ.
  • Page 5 Safety instructions IN CONFORMITY WITH THE PROVISIONS REGARDING ELECTROMAGNETIC COMPATIBILITY, THE ELECTROMAGNETIC INDUCTION COOKING HOB COMES UNDER GROUP 2 AND CLASS B (EN 55011). The manufacturer cannot be held liable for damage to persons or things caused by failure to observe the above instructions, by interference with any part of the appliance or by the use of non-original spare parts.

  • Page 6: Get To Know Your Appliance

    Instructions for the user 4. GET TO KNOW YOUR APPLIANCE Auxiliary Burner (AUX) Semi-rapid Burner (SR) Rapid Burner (R) Ultra-rapid burner (UR3) Ultra-rapid burner (UR3) Raised rack spokes Fish burner Small glass ceramic hot plate Large glass ceramic hot plate Barbeque resistance Resistance safety...

  • Page 7: Before Installation

    Instructions for the user 5. BEFORE INSTALLATION Do not discard packing in the home environment. Separate the various waste materials and take them to the nearest special garbage collection centre. In order to remove all manufacturing residues, we recommend you to clean the appliance.

  • Page 8: Using The Hob

    Instructions for the user 6. USING THE HOB Gas hob Before lighting the hob burners, check that the flame-spreader crowns are correctly in place with their respective burner caps, making sure that the holes A in the flame-spreaders are aligned with the plugs and thermocouples.
  • Page 9 Instructions for the user Practical tips for using the burners For better burner efficiency and to minimise gas consumption, use pans with a flat, smooth base and a lid that have a suitable size for the burner, thus preventing the flames reaching the sides of the pan (see point "6.3 Pan diameters").
  • Page 10 Instructions for the user Glass ceramic hob The appliance has two cooking zones of various power levels and diameters. The positions are clearly indicated by circles and the heat is concentrated within the diameters traced on the hob. The radiating zones come on after a few seconds and their heat level can be adjusted by rotating the knob to the required position between 1 and 9.
  • Page 11 Instructions for the user For best cooking results and energy saving, only use containers suitable for electric cooking: • The bases of containers must be very thick, perfectly flat and clean and dry. The hob must also be clean and dry. •...
  • Page 12 Instructions for the user The adjustment of the barbeque hot plate's power is done using the control knob, turning it to the desired position between 1 and 9. The adjustment is gradual so all the intermediate zones can be used. The indicator light comes on to indicate that the plate is heating up.
  • Page 13 Instructions for the user 6.6.1 Some good frying tips The level of oil in the basin must always be between 3 litres (minimum amount indicated inside the basin) and 3.5 litres (maximum amount indicated inside the basin). The resistance cannot operate in the open air: it must always be immersed in the oil or fat.
  • Page 14 Instructions for the user 6.6.2 When the frying is finished The basket containing the fried food can be left to "drain" before tipping out the contents. You can do this by hanging it using the specific hooks on the upper part of the resistance as shown in the figure to the side.
  • Page 15 Instructions for the user Induction hob Metal objects such as silverware or lids must not be placed on the cooking hob surface as they can become very hot. 6.7.1 Cooking zones The appliance has 2 cooking zones of various power levels and diameters. Their position is clearly indicated with circles and the heat is limited to within the diameters traced on the glass.
  • Page 16 Instructions for the user 6.7.2 Heating accelerator Each cooking zone has a heating accelerator. This system lets the burner operate at maximum power for a time that is proportional to the selected power. To start the heating accelerator, turn the knob to the left, select the “A” position and release.
  • Page 17 Instructions for the user 6.7.4 Cookware Appliances of this type require special cookware to be able to work. In fact, the cookware must have an iron or steel/iron bottom to generate the magnetic field necessary for it to be heated up. Recipients made of the following are not suitable: •...
  • Page 18 Instructions for the user Make sure you only use containers intended for induction cooking, with a thick and completely flat bottom, or, if not available, containers without a curved bottom (concave or convex). 6.7.5 Cookware detector signal Every cooking zone has a “cookware detector” that only starts the cooking if there is a well positioned container with the suitable characteristics present on the burner.
  • Page 19 Instructions for the user Operation Fan turns on at low speed Fan turns on at high speed Fan returns to low speed Fan turns off Operating power reduced from Power to 9 Reduction of power of a point for every cooking zone Turning off all the cooking zones Switching the cooking zones on again at reduced power...
  • Page 20 Instructions for the user Take care not to spill sugar or sweet mixtures on to the hob when hot. Never place materials or substances which may melt (plastic or aluminium foil) on the hob. If this occurs, promptly switch off and remove the molten material with the scraper provided while the cooking zone is still warm to prevent it from being damaged.

  • Page 21: Cleaning And Maintenance

    Instructions for the user 7. CLEANING AND MAINTENANCE NEVER USE A JET OF STEAM FOR CLEANING THE APPLIANCE. Before performing any operations requiring access to powered parts, switch off the power supply to the appliance. Cleaning stainless steel To keep stainless steel in good condition it should be cleaned regularly after use.
  • Page 22 Instructions for the user Cleaning the glass ceramic hob The glass ceramic hob should be regularly cleaned, preferably after every use, once the residual heat warning lights have gone off. Smudges from aluminium-based pans can be easily cleaned off with a cloth dampened in vinegar. Remove any burnt residues after cooking with the scraper provided;...
  • Page 23 Instructions for the user WARNING: when the resistance is raised, take care not to activate the control device. Danger of burns! Cleaning the deep fat fryer As well as following the instructions in paragraph “7.1 Cleaning stainless steel” there are a few considerations need to be made regarding the cleaning of the basin.

  • Page 24: Installing The Appliance

    Instructions for the installer 8. INSTALLING THE APPLIANCE Positioning in the counter top This is a cat. 3 appliance. The following operation requires building and/or carpentry work, therefore it must be carried out by a skilled technician. Installation can be carried out on various materials such as masonry, metal, solid wood or plastic laminated wood as long as they are heat resistant (T 90°C).
  • Page 25 Instructions for the installer 8.1.2 Fixing to the electric model support structure Create an opening in the counter top with the dimensions shown in the figure, keeping a minimum distance of 40 mm from the rear edge. The lower part of the casing must be fully accessible after the appliance has been installed.
  • Page 26 Instructions for the installer Important: other types of installation are possible if supervised by the manufacturer. Important: for fixing this product to the support structure, you are advised not to use mechanical or electrical screwdrivers and to exert moderate pressure by hand on the mounting parts. Important: for fixing the product, use the supplied brackets in all the fixing points.
  • Page 27 Instructions for the installer Electrical connection Make sure that the voltage and capacity of the power line conform to the data shown on the plate located under the casing. Do not remove this plate for any reason. The plug at the end of the power cable and the wall socket must be compatible and in compliance with current legislation on electrical systems.

  • Page 28: Gas Connection

    Instructions for the installer 9. GAS CONNECTION Before installation, make sure that the local distribution conditions (nature and pressure of the gas) and the state of regulation of the appliance are compatible. Connection to the gas supply network can be made using a rigid copper hose or a flexible steel hose with a continuous wall and in compliance with the guidelines established under current legislation.
  • Page 29 Instructions for the installer Room ventilation The room containing the appliance should have an air supply in accordance with the standards in force. The room where the appliance is installed must have enough air flow needed for the regular combustion of gas and the necessary air change in the room itself.

  • Page 30: Adaptation To Different Types Of Gas

    Instructions for the installer 10. ADAPTATION TO DIFFERENT TYPES OF GAS Before carrying out the following operations, disconnect the appliance from the electricity supply. The appliance is preset for natural gas G20 (2H) at a pressure of 20 mbar. In the case of operation with other types of gas the burner nozzles must be changed and the minimum flame adjusted on the gas taps.

  • Page 31: Burner And Nozzle Characteristics Table

    Instructions for the installer 10.2 Burner and nozzle characteristics table ATED HEATING Burner CAPACITY (KW) Auxiliary (1) 1.05 Semi-rapid (2) 1.75 Rapid (3) Ultra-rapid (4) Ultra-rapid (5) Fish burner (6) ATED HEATING Burner CAPACITY Auxiliary (1) 1.05 Semi-rapid (2) 1.75 Rapid (3) Ultra-rapid (4) Ultra-rapid (5)

  • Page 32: Final Operations For Gas Appliances

    Instructions for the installer 11. FINAL OPERATIONS FOR GAS APPLIANCES After making the adjustments described above, reassemble the appliance by following the instructions in point "10.1 Replacement of nozzles on the hob" in reverse order. After adjustment with a gas other than the preset one, replace the label on the casing of the appliance with the label corresponding to the new gas.
