Safety Warnings 1. Safety Warnings The safety instructions given in this document are indicative of safe practice and are not be considered exhaustive. Additionally, they are not intended to replace local safety procedures in the region where the instrument is used. If the equipment is used in a manner not specified by the manufacturer, the protection provided by the equipment may be impaired.
All test leads, probes and crocodile clips must be in good order, clean and with no broken or cracked insulation. Verify the integrity of the test leads before use. Only “Megger” approved test leads must be used with this product. The safe maximum limit of a measurement connection is that of the lowest rated component in the ...
The warning will not operate if the instrument is set to Off. Internal Error Warning Internal Error Warning switch off and bACk on. Contact Megger if not cleared. Read the User Guide Refer to the user guide if this message shows.
In addition the IMT100 also incorporates temperature measurement and compensation (for Insulation Resistance and DLRO tests), direction of rotation plus supply phase rotation tests. All these new test abilities go together to make the IMT100 a real world, versatile, hand held test instrument for rotating machinery.
Company web site. Occasionally an information bulletin may be issued via the Megger web site. This may be new accessories, new usage instructions or a software update. Please occasionally check on the Megger web site for anything applicable to your Megger instruments.
Motor direction of rotation (Light grey) Insulation Resistance Test, 500 V (Red) Digital Low Resistance Ohmmeter (Yellow) Insulation Resistance Test, 1 kV (Red) Continuity and diode test (Orange) Insulation Resistance Test, user selectable voltage (Red) IMT100 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
Front The external connections are all situated on top of the IMT100. A sliding cover is installed to prevent any other connection being made at the same time as the USB port. Connection to the USB port can only be made when the sliding cover is pushed completely to the back of the instrument.
For initial date and time set up, Refer to 14.4.3 Date on page 78 and Refer to 14.4.7 Time on page 79. NOTE : If the IMT100 should lose the date and time setting, (for example if the batteries have been...
Testing or access the USB is not possible while the instrument is being charged. See also Refer to 16. Specifications on page 85 Initial test set up 1. Turn on the IMT100 by rotating the range dial to the test type required. 2. Select the required test mode.
Instrument Set up 3. Connect the test leads to the IMT100. 3.1. Press the Information ( ) button to view the lead set up diagram. NOTE : When the diagram is displayed a test cannot be performed. Press Information (...
Page 18
Diode Continuity Single direction (auto and manual) Bi-direction (auto and manual) DLRO 3 Phase Low Resistance Ohmmeter Motor rotation Auto Capacitance Inductance 3 Phase Thermocouple temperature Manual temperature Temperature measurement IMT100 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
The lockout voltage is active on all test modes. It is hard-coded to Activate at 20 V. The only exception is the insulation resistance tests, where the lockout voltage can be set in the settings (as 20 V, 30 V, 50 V or 75 V). IMT100 GlobalTestSupply www.
Temperature missing pop-up window. If the temperature reading is more than 30 minutes old, a red time stamp will be displayed in the secondary field above the temperature reading. IMT100 GlobalTestSupply www. .com Find Quality Products Online at:...
Two Terminal and Guard The IMT100 is fitted with a guard terminal. The guard terminal is used to conduct leakage currents away from the measured circuit to reduce errors. The guard terminal is only used for insulation testing and as and additional connection in 3-phase testing. The lead is coloured blue.
No indication given. Buzzer on - loud mode Sound icon will appear on screen and buzzer will sound. Buzzer on - optical / silent mode Eye icon will appear on screen. IMT100 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
Soft key 2 - carousel sub mode left Buzzer setting details Soft key 1 - not used Secondary field - Temp compensation Secondary field - voltage and amps settings Time IMT100 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
To enable this Refer to 14.2.3 Lock on page 75 NOTE : As the test starts the Soft Key Function field disappears, secondary and function fields drop to the bottom of the screen. Sub-mode initials separate the secondary fields. IMT100 GlobalTestSupply www. .com Find Quality Products Online at:...
4. To start the test press the TEST button. A warning triangle will flash on screen. NOTE : The test can be stopped at any time by pressing the TEST button. IMT100 GlobalTestSupply www. .com Find Quality Products Online at:...
2. Press soft keys 2 and 3 to move the carousel left or right through sub-modes to PI (Polarization Index). NOTE : The full title text of the sub-mode will appear in the secondary field for a few seconds. IMT100 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
Page 27
A message will inform you the data was saved and which asset ID it was saved to. NOTE : If the test was stopped before completion, it cannot be saved. 7. To restart the test pressing the TEST button again. IMT100 GlobalTestSupply www. .com Find Quality Products Online at:...
The secondary field displays actual voltage output and the current measured. 6. When the test has completed, The primary field displays the test results. The secondary field displays actual voltage output and the current measured. IMT100 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
NOTE : The test can be stopped at any time by pressing the TEST button. 4. During the tests, The primary field displays the test results. The secondary field displays actual voltage output and the current measured. IMT100 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
Page 30
A message will inform you the data was saved and which asset ID it was saved to. NOTE : If the test was stopped before completion, it cannot be saved. 7. To restart the test pressing the TEST button again. IMT100 GlobalTestSupply www. .com Find Quality Products Online at:...
3. Press soft keys 2 and 3 to move the carousel left or right through sub-modes. IR is default, scroll through to 3P, PI, T(s) DAR. 4. Run the chosen test as described in the previous sections. IMT100 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
Secondary field Time TRMS (True RMS) Default is TRMS mode shows true RMS voltage. In TRMS mode the IMT100 will measure both AC and DC components of the supply voltage (AC+DC). 1. Turn rotary switch to select the Voltmeter (V) position.
The primary field displays the measured voltage. 6. The result can be saved by pressing the SAVE button. A message will inform you the data was saved and which asset ID it was saved to. IMT100 GlobalTestSupply www. .com Find Quality Products Online at:...
The secondary field displays frequency. 5. The result can be saved by pressing the SAVE button. A message will inform you the data was saved and which asset ID it was saved to. IMT100 GlobalTestSupply www. .com Find Quality Products Online at:...
Crossed null sysmbol will show when the leads have not been nulled to zero NULL the test leads by touching the two test probe ends. Press the TEST button until the NULL (symbol) appears on the screen. The ohmic value on the primary screen will read 0 Ω. IMT100 GlobalTestSupply www.
6. Press soft keys 2 and 3 to move the carousel left or right through sub-modes to uni-direction NOTE : The full title text of the sub-mode will appear in the secondary field for a few seconds. IMT100 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
Page 37
The primary field displays the result of the true resistance of the unit under test. The secondary field displays test current and the previous resistance value in Uni direction. IMT100 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
7. Move the probes to the next phase 8. Press test NOTE : A result can be assigned to any phase and there is a possibility to change the phase if required. IMT100 GlobalTestSupply www. .com Find Quality Products Online at:...
Page 39
NOTE : Results can be saved at any point during the 3 Phase test sequence. One, two or three test values can be saved. 15. To restart the test, press soft key 4 then repeat the steps for 3 Phase testing. IMT100 GlobalTestSupply www. .com Find Quality Products Online at:...
The secondary field displays the test current and the resistance values in both directions - highest value shown in Primary. The test in bi-direction mode runs continually IMT100 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
The only information to display is the diode drop voltage if the instrument senses a voltage across the device. If no current flows the main display will show “O/C”. IMT100 GlobalTestSupply www.
Secondary field left - P1-P2 connection Forward reverse readings status (Bi directional only) Secondary field left - previous temperature Auto on compensation measurement Soft key 4 - Temperature compensation Time IMT100 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
3. Connect the test leads to the unit under test. 4. If there is a continuity reading detected for C and P connections the secondary fields will display with a tick and background will be green. IMT100 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
Page 44
8. The result can be saved by pressing the SAVE button. A message will inform you the data was saved and which asset ID it was saved to. 9. To restart the test, press the TEST button again. IMT100 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
A message will inform you the data was saved and which asset ID it was saved to. 9. To restart the test, re-connect to a new test piece and the test will start automatically. IMT100 GlobalTestSupply www. .com Find Quality Products Online at:...
9. The result can be saved by pressing the SAVE button. A message will inform you the data was saved and which asset ID it was saved to. 10. To restart the test, press the TEST button again. IMT100 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
A message will inform you the data was saved and which asset ID it was saved to. 10. To restart the test, re-connect to a new test piece and the test will start automatically. IMT100 GlobalTestSupply www. .com Find Quality Products Online at:...
11. Press soft key 2 to assign reading to a phase (or press test before assigning to retest) 12. Move the probes to the next phase 13. Press test IMT100 GlobalTestSupply www. .com Find Quality Products Online at:...
3 Phase testing. Test failure 7.7.1 Lost connection Should the connection be lost during the test the IMT100 will notify the user. The user can re-make the connection then restart the test after a few seconds by pressing the test button or by reconnecting to a test piece.
Direction of Motor Rotation 8. Direction of Motor Rotation 1. Turn on the IMT100 by rotating the range dial to the test type required. 2. Turn rotary switch to select direction of motor rotation position. 3. Connect the test leads to the IMT100.
Digital test measurement / results 3 Phase readings Percentage difference NOTE : Results of measurements can be adversely affected by impedances of additional operating circuits connected in parallel or by transient current. IMT100 GlobalTestSupply www. .com Find Quality Products Online at:...
4. Press soft keys 1 to toggle between 120 Hz and 1000 Hz. 5. To start the test press the TEST button. The IMT100 determines if the load is inductive, capacitive or resistive automatically. 6. During the tests, The primary field displays the result for the reactive ...
3. Connect the test leads to the unit under test. 4. Press soft keys 1 to toggle between 120 Hz and 1000 Hz. 5. To start the test press the TEST button. The IMT100 determines if the load is inductive, capacitive or resistive automatically. 6. During the tests, ...
7. Move the probes to the next phase 8. Press test NOTE : A result can be assigned to any phase and there is a possibility to change the phase if required. IMT100 GlobalTestSupply www. .com Find Quality Products Online at:...
Page 55
NOTE : Results can be saved at any point during the 3 Phase test sequence. One, two or three test values can be saved. 15. To restart the test, press soft key 4 then repeat the steps for 3 Phase testing. IMT100 GlobalTestSupply www. .com Find Quality Products Online at:...
Inductance (L); Capacitance (C); Resistance (R) (LCR) LCR Calibration NOTE : For full IMT100 re-calibration procedure Refer to 18. Calibration, Repair and Warranty on page 89. 1. Inductance calibration can be accessed from any sub-mode within the LCR family by pressing soft key 4.
Page 57
13. Press the tick button ( ) or soft key 4 to return to the last LCR test mode. The IMT100 has been successfully recalibrated and is ready for use. The new calibration will be stored. 14. If calibration fails, 2 options appear: Press soft key 1 to go bACk ...
Temperature measurement 10. Temperature measurement Thermocouple connected, type “T” is set as default, the IMT100 can also be configured for “J” and “K” type thermocouples. Before an insulation resistance test can be carried out with temperature compensation enabled a temperature measurement must be carried out to establish the temperature of the unit under test.
Page 59
4. Press soft key 1 to toggle between ºC (Centigrade) or ºF (Fahrenheit). NOTE : This will change the temperature units of measure for all temperature reading within the IMT100 test and measurement results. 5. Place the thermocouple against the test piece and allow the thermocouple to rise to a stable temperature.
11. Press soft key 2 and 3 to scroll through the digits. 12. Press soft key 4 to accept the temperature value. 13. Press soft key 1 to cancel and return to the previous menu at IMT100 any point. GlobalTestSupply www.
Page 61
14. The new temperature will be displayed. The result can be saved by pressing the SAVE button. A message will inform you the data was saved and which asset ID it was saved to. IMT100 GlobalTestSupply www. .com Find Quality Products Online at:...
Creating a new asset ID 1. Turn rotary switch to select the data management position. The primary field shows list of Assets stored on the IMT100. The secondary field shows the amount of entries, the total storage available are shown in the left hand field and the number of entries under the selected asset are shown in the right hand field.
Using an existing asset ID 1. Turn rotary switch to select the data management position. The primary field shows list of assets stored on the IMT100. The secondary field shows the amount of entries, the total storage available are shown in the left hand field and the number of entries under the selected asset are shown in the right hand field.
Deleting an asset 1. Turn rotary switch to select the data management position. The primary field shows list of Assets stored on the IMT100. The secondary field shows the amount of entries, the total storage available are shown in the left hand field and the number of entries under the selected asset are shown in the right hand field.
Deleting items from within an asset 1. Turn rotary switch to select the data management position. The primary field shows list of Assets stored on the IMT100. The secondary field shows the amount of entries, the total storage available are shown in the left hand field and the number of entries under the selected asset are shown in the right hand field.
Deleting a single test 1. Turn rotary switch to select the data management position. The primary field shows list of assets stored on the IMT100. The secondary field shows the amount of entries, the total storage available are shown in the left hand field and the number of entries under the selected asset are shown in the right hand field.
Page 67
9. Press soft keys 2 and 3 to scroll up and down through the individual test list. 10. Press soft key 4 to delete the entry. 11. Press soft key 4 to confirm Soft key 1 to cancel. IMT100 GlobalTestSupply www. .com Find Quality Products Online at:...
2. Connect a USB Memory stick to the IMT100. A USB type A socket is provided on the top of the IMT100 for transferring test results. The position is clearly marked with a USB symbol, the slider must be in the backward position.
Page 69
7. As the data is uploading, a message appears and blocks navigation in the secondary field. No other work can be carried out while uploading is in progress. 8. When the export is successful the IMT100 will notify the user. IMT100 GlobalTestSupply www.
5. The will progress through various stages. 6. When complete, return the range dial to off position. 7. Remove the USB. 8. Restart the IMT100 by turning the rotary switch to any test position. 9. The firmware update screen will display while the update in progress.
If the error code number is 1000 or higher the instruction on screen will suggest rebooting the instrument and if the problem persists, contact Megger. For Megger contact details Refer to 18. Calibration, Repair and Warranty on page 89. IMT100 GlobalTestSupply www.
2.1. This will toggle between the two options where a toggle key is displayed to the right hand side. 2.1. This will enter a sub menu if more than two options are available. IMT100 GlobalTestSupply www. .com Find Quality Products Online at:...
The lock setting enables the lock button for IR tests. There are two options available for Lock. Press the tick button ( ) to toggle between on and off. 14.2.4 Temperature compensation IMT100 GlobalTestSupply www. .com Find Quality Products Online at:...
6. Press soft key 2 and 3 to scroll through the digits. 7. Press soft key 4 to accept the third digit and save the setting. 8. Press soft key 1 to cancel and return to the previous menu at any point. IMT100 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
( 2. Press soft key 2 and 3 to scroll through the options. 3. Press soft key 4 to accept the selected setting. 4. Press soft key 1 to cancel and return to the previous menu. IMT100 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
( 2. Press soft key 2 and 3 to scroll through the options. 3. Press soft key 4 to accept the selected setting. 4. Press soft key 1 to cancel and return to the previous menu. IMT100 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
2. Toggle on screen shots in the setting. 3. Press brightness button at any point during use of the IMT100 to take screen shot. These are automatically saved to the attached pen drive. 4. To access the images, open the pen drive on a computer. 2 folders will display on the pen drive, a folder for results and a folder for screen shots.
14.5 Language settings The languages set in the IMT100 are English, French, German and Spanish. From the settings menu screen select the Language sub-menu using soft keys 2 and 3. Select the required language using soft keys 2 and 3, the language changes immediately.
The battery condition icon is positioned at the top right hand corner of display. This icon is displayed at all times when the IMT100 is switched on. When running on battery, the icon will indicate state of charge, the icon will be filled in proportion to the state of charge.
When charging the IMT100 while the instrument is OFF, an animated battery will display in the top right hand corner of the screen. While the IMT100 is charging a test can not be performed. If the test button in pressed the buzzer will sound.
CAUTION : Battery cells should not be left in the instrument if remaining unused for an extended period. Description Quantity Screw, Captive Cover, Battery Battery isolation tab Battery Screw, Captive Cover, Fuses Fuses IMT100 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
15.4.1 Replace battery cells and remove isolation tab The battery cells are housed in the lower section of the IMT100, behind the rotary switch. Looking at the back of the instrument, the lower (battery) cover incorporates a stand and has the replacement cell types written on it.
15 - 400 Hz (0 - 1000 V) Frequency resolution 0.1 Hz Frequency accuracy ±0.5% (±1 digit) Diode test accuracy: ±2% ±2 digits 0.01 V to 3.00 V Display range: 0.00 V to 3.00 V IMT100 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
Page 84
-10 °C to 50 °C (14 °F to 122 °F) Storage temperature range -25 °C to 50 °C (-13 °F to 122 °F) Humidity 90% RH at 40 °C (104 °F) max. Calibration temperature 20 °C (68 °F) IMT100 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
Page 85
0.1 Ω 23 % 23 % Key to table: A: Intrinsic uncertainty : Reference position ±90º : Supply Voltage : Temperature 0 ºC to 30 ºC IEC61557 -1, 61557-2 and 61557-4 IMT100 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
Test probe set, long reach CAT IV 600 V 1012-066 Test probe set, long reach, CAT II 1000 V 1012-065 Temperature probe, T type CAT III 600 V 1012-067 SP5 remote probe accessory 1007-157 IMT100 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
3. Pack the instrument carefully to prevent damage in transit. 4. Before the instrument is sent to Megger, freight paid, make sure that the returns label is attached or that the RA number is clearly marked on the outside of the package and on any correspondence. Copies of the original purchase invoice and packing should be sent simultaneously by airmail to expedite clearance through customs.
19.1 WEEE Directive The crossed out wheeled bin symbol placed on Megger products is a reminder not to dispose of the product at the end of its life with general waste. Megger is registered in the UK as a Producer of Electrical and Electronic Equipment. The Registration No is WEE/ HE0146QT.
