- Page 1 MPCC230 Register Megger Pro Circuit Checker megger.com/register User Guide User Guide Firmware updates Support megger.com/support English...
- Page 2 Megger Limited, Archcliffe Road, Dover, Kent CT17 9EN. ENGLAND T +44 (0)1304 502101 F +44 (0)1304 207342 www.megger.com Megger Limited reserves the right to alter the specification of its products from time to time without notice. Although every effort is made to ensure the accuracy of the information contained within this document it is not warranted or represented by Megger Limited to be a complete and up - to - date description.
- Page 3 Limited described in this user guide is in compliance with Directive 2014/53/EU. Other equipment manufactured by Megger Instruments Limited described in this user guide is in compliance with Directives 2014/30/EU and 2014/35/EU where they apply. The full text of Megger Instruments EU declarations of conformity are available at the following internet address: megger.com/company/about-us/eu-dofc www.megger.com...
- Page 4 4.2.3 RCD AUTO function LOOP 4.3.1 Test modes: 4.3.2 LOOP test operation HAR voltage harmonics 4.4.1 Test mode: 4.4.2 Harmonics function MEM Memory / REPORT 4.5.1 Operation 4.5.2 Report create 4.5.3 MEMORY 5. Maintenance General maintenance Cleaning 6. Specifications www.megger.com MPCC230...
- Page 5 7. Calibration, Repair and Warranty Calibration, Service and Spare Parts Approved Repair Companies Return procedure 8. Decommissioning WEEE Directive Battery disposal 9. Worldwide Sales Offices www.megger.com MPCC230...
- Page 6 An auto-RCD test will confirm the operation of the protective device at measure the contact voltage value. In addition, the MPCC230 will not only provide the TRMS supply voltage, but also indicate the total harmonic distortion measured and allow the user to identity which harmonics are present.
- Page 7 Personal protective equipment should be used if there are ACCESSIBLE HAZARDOUS LIVE PARTS in the installation where measurement is to be carried out. „ Do not use on or around uninsulated hazardous live conductors where a potential to cause electric shock, electrical burns or arc flash exists. www.megger.com MPCC230...
- Page 8 UK conformity. This equipment complies with current UK legislation EU conformity. Equipment complies with current EU directives Conforms to relevant Australian Safety and EMC standards >250 V Prohibited for use on electrical systems above 250 V Do not dispose of in the normal waste stream www.megger.com MPCC230...
- Page 9 Function button to select the Socket Test / VOLT - RCD - LOOP - Harmonics measurement mode. / Memory. Sub-function navigation Cycle through displayed features or memory values Display TFT 1,77” Anti-scratch glass UK plug EU plug www.megger.com MPCC230...
- Page 10 2.2. If an error occurs due to incorrect wiring or a high voltage detected on the earth, the bar will turn red and an audible alarm will sound. The unit will display the failed parameter on the screen (examples in Fig 2 and 3). Fig. 1 Fig. 2 Fig. 3 www.megger.com MPCC230...
- Page 11 2. Press the F1 button to select the type of RCD and F2 button to select AUTO. 3. Press the RED test button to start the test. 4. The instruments will execute all tests in sequence, reset the RCD between each step. AUTO mode consist of 6 test in the following sequence: ƒ www.megger.com MPCC230...
- Page 12 5. RCD Tripping Time is shown on the display in ms for every STEP. 5.1. Passed trip time results are displayed in GREEN (Fig 6). 5.2. Failed trip times will be displayed in red (Fig 7) and the test will be stopped. www.megger.com MPCC230...
- Page 13 Loop test measures the impedance between Phase and Earth/Ground without a RCD trip. CAUTION : The MPCC230 uses a low current no-trip loop test method. However, this DOES NOT guarantee an RCD will not trip. Accumulative or highly sensitive RCDs or RCBOs may still trip, so care should be taken to ensure that a loss of supply will not cause a hazardous situation to arise.
- Page 14 5. In MEM mode, press the RED button to generate a results QR code on the display (Fig.12) 6. With the Megger Pro Circuit Checker App running on your mobile device, select “Scan QR”. All saved measurements will be imported to the App and displayed in a simple report. This can then be exported in either PDF or csv format.
- Page 15 Value indicates the measured result. 9. For saved RCD measurements, a pass or fail value is shown as either GREEN or RED: 9.1. GREEN if the result has passed the test. 9.2. RED if the result has not passed the test. www.megger.com MPCC230...
- Page 16 Ensure the unit is kept clean and dry after use. Store in protective case when not in use. Cleaning Disconnect from mains power. Wipe the instrument with a clean cloth dampened with either water or isopropyl alcohol (IPA). www.megger.com MPCC230...
- Page 17 CAT II 250 V to ground Max Input: 250 VAC General reference standards Safety of measuring instruments IEC/EN61010-1 IEC/EN61010-2-2017 IEC/EN61326-1 Display and memory Features TFT colour graphic LCD Memory safety section 64 results Working environment conditions Reference temperature 5ºC to 23ºC www.megger.com MPCC230...
- Page 18 Specifications Working temperature 5ºC to 40ºC Relative humidity <80%RH Storage temperature -10ºC to 60ºC Storage humidity <80%RH Mechanical features Dimensions 81.5 x 70 x 83 mm Weight 110 g www.megger.com MPCC230...
- Page 19 New instruments are covered by a two year warranty from the date of purchase by the User, the second year being conditional on the free registration of the product on www.megger.com. You will need to log in, or first register and then login to register your product. The second year warranty covers faults, but not recalibration of the instrument which is only warranted for one year.
- Page 20 3. Pack the instrument carefully to prevent damage in transit. 4. Before the instrument is sent to Megger, freight paid, make sure that the returns label is attached or that the RA number is clearly marked on the outside of the package and on any correspondence.
- Page 21 8. Decommissioning WEEE Directive The crossed out wheeled bin symbol placed on Megger products is a reminder not to dispose of the product at the end of its life with general waste. Megger is registered in the UK as a Producer of Electrical and Electronic Equipment. The Registration No is WEE/ HE0146QT.
- Page 22 +48 22 2809 808 info.pl@megger.com PORTUGAL +34 916 16 54 96 info.es@megger.com România +40 21 2309138 info.ro@megger.com РОССИЯ +7 495 2 34 91 61 sebaso@sebaspectrum.ru SLOVENSKO +421 2 554 23 958 info.sk@megger.com Türkiye +46 08 510 195 00 seinfo@megger.com www.megger.com MPCC230...
- Page 23 MPCC230...
- Page 24 This instrument is manufactured in Italy. The company reserves the right to change the specification or design without prior notice. Megger is a registered trademark For Patent information about this instrument refer to www.megger.com/patents MPCC230_UG_en_V02 09 2024 © Megger Limited 2024...
