  • Page 1 ESSENSSE NEO AC/EC BASIC INSTALLATION VCES4 B-xxx-BA- AC/EC 15.12.2023 v-01...

  • Page 2: About The Manual

    The manufacturer reserves the right to change, including the technical documentation, without prior notice. Keep the manual for future use. The instructions herein are part of the product Declaration of conformity Details can be found at www.2vv.cz/en/...

  • Page 3: Check Delivery

    0 °C, it must be left in working conditions for at least 2 hours without switching on after unpacking. 2VV. Creating innovative solutions for you and your business since 1995. 2VV. Creating innovative solutions for you and your business since 1995.

  • Page 4: Main Components

    VCES4 B 200 VCES4 B 200 1825 1825 2160 2160 VCES4 B 250 VCES4 B 250 2235 2235 2570 2570 2VV. Creating innovative solutions for you and your business since 1995. 2VV. Creating innovative solutions for you and your business since 1995.

  • Page 5: Technical Parameters

    *Intake air temperature +18 °C, at maximum heating level and highest fan speed. The other technical parameters can be found in the corresponding technical sheet of the product 2VV. Creating innovative solutions for you and your business since 1995. 2VV. Creating innovative solutions for you and your business since 1995.

  • Page 6: Installation

    Check that the curtain is fastened properly to prevent it falling 2VV. Creating innovative solutions for you and your business since 1995. 2VV. Creating innovative solutions for you and your business since 1995.
  • Page 7 2. Fastening to the curtain 4 M8 threaded rods (not included) 8 M8 nuts (not included) 30mm 10mm 2VV. Creating innovative solutions for you and your business since 1995. 2VV. Creating innovative solutions for you and your business since 1995.
  • Page 8 The exhausts of the Essensse air cur- tain can blow air at a maximum angle of 15° Connect the pipes. 15° 2VV. Creating innovative solutions for you and your business since 1995. 2VV. Creating innovative solutions for you and your business since 1995.
  • Page 9 - unscrew two M5 screws on the bottom of the cover side Top side Bottom side - Power supply connection - Control panel connection 2VV. Creating innovative solutions for you and your business since 1995. 2VV. Creating innovative solutions for you and your business since 1995.

  • Page 10: Installation Of Control Panel

    The controller can only be installed on a wall or on a fixed non-portable object. The cable must be secured against being pulled out of the controller. 2VV. Creating innovative solutions for you and your business since 1995. 2VV. Creating innovative solutions for you and your business since 1995.
  • Page 11 High fan speed, heating is enabled (heating level 1 and 2 enabled) Heating switch (water heater = heating level 1, electric heater = heating level 1 and 2) 2VV. Creating innovative solutions for you and your business since 1995. 2VV. Creating innovative solutions for you and your business since 1995.
  • Page 12 DOOR terminals (door switch, external control switch, ...). 2VV. Creating innovative solutions for you and your business since 1995. 2VV. Creating innovative solutions for you and your business since 1995.
  • Page 13 WIRING OF THE CONTROLLER AND ACCESSORIES BASIC EC Electric version Whater version Air-only version 2VV. Creating innovative solutions for you and your business since 1995. 2VV. Creating innovative solutions for you and your business since 1995.
  • Page 14 WIRING OF THE CONTROLLER AND ACCESSORIES BASIC AC Electric version Whater version Air-only version 2VV. Creating innovative solutions for you and your business since 1995. 2VV. Creating innovative solutions for you and your business since 1995.
  • Page 15 - Cable: Three-conductor cable with a cross-section of 1.5 mm2, 230 V/ 50 Hz. ATTENTION! Not supplied with the product. 2VV. Creating innovative solutions for you and your business since 1995. 2VV. Creating innovative solutions for you and your business since 1995.
  • Page 16 Any tampering or changes to the internal interconnection are prohibited and will void the warranty. • We recommend using the accessories supplied by 2VV or its authorized distributors. If in doubt about the possibility of • using non-original accessories, please contact your supplier.

  • Page 17: Troubleshoting

    IF YOU CAN‘T FIX THE FAULT YOURSELF If you have not been able to resolve the problem, please contact your supplier or 2VV‘s exclusive representative. Warranty and post-warranty service is provided by the supplier or by one of the authorised service organisations, a list of which is available from the supplier.
  • Page 18 VCES4B-100 / 150 / 250 brown blue blue black white white ye/gr ye/gr L2 L3 N PE L1 N PE 2VV. Creating innovative solutions for you and your business since 1995. 2VV. Creating innovative solutions for you and your business since 1995.
  • Page 19 L2 L3 N PE VCES4B100-E1AC-BA FUSE blue black white ye/gr L2 L3 N PE 2VV. Creating innovative solutions for you and your business since 1995. 2VV. Creating innovative solutions for you and your business since 1995.
  • Page 20 L2 L3 N PE VCES4B150-E0AC-BA FUSE blue black white ye/gr L2 L3 N PE 2VV. Creating innovative solutions for you and your business since 1995. 2VV. Creating innovative solutions for you and your business since 1995.
  • Page 21 L2 L3 N PE VCES4B150-E2AC-BA FUSE blue black white ye/gr L2 L3 N PE 2VV. Creating innovative solutions for you and your business since 1995. 2VV. Creating innovative solutions for you and your business since 1995.
  • Page 22 L2 L3 N PE VCES4B200-E1AC-BA FUSE brown blue white ye/gr L2 L3 N PE 2VV. Creating innovative solutions for you and your business since 1995. 2VV. Creating innovative solutions for you and your business since 1995.
  • Page 23 L2 L3 N PE VCES4B250-E0AC-BA FUSE blue black white ye/gr L2 L3 N PE 2VV. Creating innovative solutions for you and your business since 1995. 2VV. Creating innovative solutions for you and your business since 1995.
  • Page 24 L2 L3 N PE VCES4B250-E2AC-BA FUSE blue black white ye/gr L2 L3 N PE 2VV. Creating innovative solutions for you and your business since 1995. 2VV. Creating innovative solutions for you and your business since 1995.
  • Page 25 ELECTRICAL DIAGRAMS VCES4Bxx-S0EC-BA FUSE DOOR HEATER WHITE BLUE YELLOW BROWN Ovladač BLUE YE/GR L1 N PE VCES4Bxx-V2EC-BA FUSE DOOR HEATER WHITE BLUE YELLOW BROWN Ovladač BLUE YE/GR L1 N PE...
  • Page 26 ELECTRICAL DIAGRAMS VCES4B100-E0EC-BA FUSE DOOR HEATER WHITE BLUE YELLOW BROWN BLUE YE/GR L2 L3 N PE VCES4B100-E1EC-BA FUSE DOOR HEATER WHITE BLUE YELLOW BROWN BLUE YE/GR L2 L3 N PE...
  • Page 27 ELECTRICAL DIAGRAMS VCES4B100-E2EC-BA FUSE DOOR HEATER WHITE BLUE YELLOW BROWN BLUE YE/GR L2 L3 N PE VCES4B150-E0EC-BA FUSE DOOR HEATER WHITE BLUE YELLOW BROWN BLUE YE/GR L2 L3 N PE...
  • Page 28 ELECTRICAL DIAGRAMS VCES4B150-E1EC-BA FUSE DOOR HEATER WHITE BLUE YELLOW BROWN BLUE YE/GR L2 L3 N PE VCES4B150-E2EC-BA FUSE DOOR HEATER WHITE BLUE YELLOW BROWN BLUE YE/GR L2 L3 N PE...
  • Page 29 ELECTRICAL DIAGRAMS VCES4B200-E0EC-BA FUSE DOOR HEATER WHITE BLUE YELLOW BROWN BLUE YE/GR L2 L3 N PE VCES4B200-E1EC-BA FUSE DOOR HEATER WHITE BLUE YELLOW BROWN BLUE YE/GR L2 L3 N PE...
  • Page 30 ELECTRICAL DIAGRAMS VCES4B200-E2EC-BA FUSE DOOR HEATER WHITE BLUE YELLOW BROWN BLUE YE/GR L2 L3 N PE VCES4B250-E0EC-BA FUSE DOOR HEATER WHITE BLUE YELLOW BROWN BLUE YE/GR L2 L3 N PE...
  • Page 31 ELECTRICAL DIAGRAMS VCES4B200-E1EC-BA FUSE DOOR HEATER WHITE BLUE YELLOW BROWN BLUE YE/GR L2 L3 N PE VCES4B200-E2EC-BA FUSE DOOR HEATER WHITE BLUE YELLOW BROWN BLUE YE/GR L2 L3 N PE...
  • Page 32 If you have any doubts or questions, please do not hesitate to contact our sales or technical support department. Address 2VV s.r.o. Nádražní 794 533 51 Pardubice - Rosice Czech Republic Internet: https://www.2vv.cz/en 2VV. Creating innovative solutions for you and your business since 1995. 2VV. Creating innovative solutions for you and your business since 1995.
