2. OPERATION

Please read all instructions before operating the HYPROP 2 and the VARIOS to ensure it
performs to its full potential.
PRECAUTION
METER sensors are built to the highest standards, but misuse, improper protection, or improper installation may
damage the sensor and possibly void the manufacturer's warranty. Before integrating HYPROP 2 and VARIOS into a
system, make sure to follow the recommended installation instructions and have the proper protections in place to
safeguard sensors from damage.
Please observe the following considerations carefully:
1. Read all applicable safety instructions.
2. Electrical installations must follow the safety and EMC requirements of the country
where the system is used.
IMPORTANT: Do not use the device if the electrical wire is damaged. Always avoid direct sunlight exposure.
3. Dispose of all materials and chemicals according to national legislation and
environmental care regulations.
Please refer to the respective safety data sheets.
4. Do not touch the ceramic tips of the tensiometer shafts with bare hands.
Grease or soap reduces the hydrophilic characteristics of the ceramic.
5. Do not stick sharp objects into the holes of the sensor unit.
This may damage the pressure sensors.

2.1 INSTALLATION

Follow the steps listed below to set up HYPROP 2 and start collecting data.
Tools needed
• Microsoft Windows computer (Windows 10 or newer)
• LABROS software with METER USB driver
1. Download the installation package (LABROS SoilView software) from the METER
website either support page:
varios-support).
NOTE: The combination measurement is only possible with versions of software and firmware beginning with
software version 5.2.0, VARIOS firmware version 1.6.5, and HYPROP firmware version 3.0.3.
2. Run the LABROS SoilView *.exe file and follow the instructions on the installation
assistant screen.
Default settings will simultaneously install both the software LABROS SoilView
(measurement software) and LABROS SoilView-Analysis (evaluation software) (see
Figure 1). If only one software package is desired, please select Entire feature will be
unavailable in the window for the software that is not needed (Figure 2).
OPERATION
HYPROP 2 (meter.ly/hyprop-support), or
2
VARIOS (meter.ly/
