3.2 CONFIGURE AND START THE MEASUREMENT
1.
Enter sample name and storage location in the line showing the HYPROP/VARIOS soil
sample to be measured (Figure 22).
The Balance is automatically detected. Weight measurements are entered here for
empty soil sampling ring, and silicone retaining ring. Weights can be entered before or
after the measurement is complete using the LABROS SoilView-Analysis software.
2.
Adapt HYPROP 2 and VARIOS measurement profiles by selecting the button marked in
Figure 23.
For more information about the measurement profiles, refer to section 2.6.4 in the
HYPROP User
Manual and section 2.7.4.1 in the
HYPROP-VARIOS CONNECTOR
Figure 21 Connected devices
Figure 22 Start manager
VARIOS User
19
Manual.
