4. Application

4.1 One-to-One Extension

Transmitter
HDMI
Laptop

4.2 One-to-Many splitter

Transmitter
HDMI
DVD Player

4.3 Many-to-Many Matrix/ Videowall

To configure matrix and video wall, perform the following:
Scan the QR code or search "VDirector" in App store to install VDirector using
your phone or tablet PC.
iOS Apple Store
Connect all transmitters, receivers and the wireless router to the network switch according
to the following diagram shown:
INFOBIT AV
RS232
Switch
www.infobitav.com
Receiver
HDMI RS232
Projector
Receiver
...
Receiver
Google Play
TV
HDMI
TV
HDMI
