4. Technical specifications

The ULP has the following technical specifications:

4.1. Dimensions

· Diameter: 70 mm (2.76 in.)
· Height: 83 mm (3.27 in.)

4.2. Weight

418 grams (14.7 ounces)
3.3 - 18 VDC (Wind Meter)

4.3 Power

12 VDC (Heating)

4.4. Sensors

Ultrasonic transducers (4x)
Sample rate: 0.1 Hz to 10 Hz
Sample rate: 0.1 Hz to 10 Hz (Configurable)
Wind Speed
Range: 0.5 to 45 m/s (1.12 to 100 mph) or 0.5 to 25m/s (1.12 to 56 mph)
Accuracy: ±0.1 m/s at 10m/s (0.22 at 22.4 mph)
Threshold: 0.5 m/s (1.12 mph)
Wind direction
Range: 0 - 359º
Accuracy: ±1º
Heated ON-> Temperature <5ºC/41º F
Heated OFF -> Temperature >= 15ºC/59º F
After turning ON it will only be switched OFF when reaches 15ºC/59º F
ULP SUMMIT HEATED User Manual

4.5 Wind Information

· Wind speed
· Wind direction
