4. Technical specifications
The ULP has the following technical specifications:
4.1. Dimensions
· Diameter: 70 mm (2.76 in.)
· Height: 65 mm (2.56 in.)
4.2. Weight
210 grams (7.4 ounces)
4.3 Power
· 3.3 - 18 VDC
4.4. Sensors
Ultrasonic transducers (4x)
Sample rate: 0.1 Hz to 10 Hz
Sample rate: 0.1 Hz to 10 Hz (Configurable)
Wind Speed
Range: 0.5 to 45 m/s (1.12 to 100 mph) or 0.5 to 25m/s (1.12 to 56 mph)
Accuracy: ±0.1 m/s at 10m/s (0.22 at 22.4 mph)
Threshold: 0.5 m/s (1.12 mph)
Wind direction
Range: 0 - 359º
Accuracy: ±1º
ULP STD User Manual
4.5 Wind Information
· Wind speed
· Wind direction
4
