1. Product overview
Thank you for choosing the ULP Ultrasonic
Anemometer from Calypso Instruments.
This ULP is the first model or our generation II,
representing an important technology breakthrough
condensing an extensive R+D investment:
· Both shape andfirmware have been enhancedfor
an improved rain performance,beingthis point key
for static applications such as weather stations.
· Mechanical design has been revamped making the
unit more robust and dependable.
· We feel very proud to release a unit that requires
under 0,4 mA of power at 5V, sampling at 1Hz.
·
Different output options available: RS485 and UART/TTL
Applications for the ULP are the following:
Weather Stations | Drones
Temporary Scaffolding and construction |
Infrastructures and building | Cranes
Spraying | Irrigation | Fertilizing | Precision
Agriculture
Smart Cities | Wild fires | Shooting | Scientific
2. Package content
The package contains the following:
· Ultrasonic Wired Wind Instrument + cable 2 meters
for connection
· Serial number reference in the back of the
packaging
· Quality control referece in the same place as
the previous one.
(Both shown in the Image 1)
· User Quick guide at the back of the packaging and
some more information useful for the customer.
· Connection instructions picture including at the box
package.
· M4headless screw (x6)
· M4 screw (x3)
Quality control passed
MAC address /serial
Image 1. Serial number/Control quality label
ULTRASONIC ULP
3. Technical specifications
ULP incorporates the following
technical specifications:
Dimensions · Diameter: 68 mm
Image 2. Main dimensions of the unit.
Noth mark position
Make sure the north mark
is perfectly aligned.
Image 3. North mark.
ULTRASONIC ULP
3.2. Weight · Weight: 210 grams
M4x0,5
Image 4. Screw holes position .
