Service Manual
ADVANCE SERIES OVENS
SERVICE MANUAL
"ADVANCE" SERIES OVENS
Service Manual
04/02/2020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ADVANCE Series and is the answer not in the manual?

Questions and answers

-JEAN LOUIS LETELLIER
May 7, 2025

J'ai le code erreur E11. comment remettre le four en route ? merci

0
1 comments:
Mr. Anderson
May 18, 2025

To reset the Fagor ADVANCE Series oven with error code E11, switch off the oven. Once the fault causing the error is removed, the outputs return to normal operation.

This answer is automatically generated

0
Диана
June 19, 2025

Есть кто нибудь живой АУ АУ!!!!

0
Диана
June 18, 2025

Выдаёт ошибку Е-8

0
Диана
June 18, 2025

Нет подачи напряжения на клапан подачи воды

0

Subscribe to Our Youtube Channel

Related Manuals for Fagor ADVANCE Series

Summary of Contents for Fagor ADVANCE Series

  • Page 1 Service Manual 04/02/2020 ADVANCE SERIES OVENS SERVICE MANUAL “ADVANCE” SERIES OVENS Service Manual...

  • Page 2: Table Of Contents

    SERVICE MANUAL ADVANCE OVENS 1. INTRODUCTION ................................6 2. OPERATING TESTS ................................ 6 3. SAFETY INSTRUCTIONS ............................... 6 4. PICTOGRAMS ................................. 9 5. UPKEEP ................................... 9 6. PROLONGED PERIOD OF INACTIVITY .......................... 9 7. MAINTENANCE ................................10 7.1. DAILY MAINTENANCE ............................. 10 7.1.1.
  • Page 3 SERVICE MANUAL ADVANCE OVENS 11.23. AG-201 ............................... 43 11.24. APG-201 ..............................44 11.25. AG-102 ............................... 45 11.26. ACG-102 ..............................46 11.27. APG-102 ..............................47 11.28. ACG-202 ..............................48 11.29. AG-202 ............................... 49 11.30. APG-202 ..............................50 12. TECHNICAL DATA ..............................51 12.1.
  • Page 4 SERVICE MANUAL ADVANCE OVENS 15.8. HEATING POWER AND FAN SPEED ...................... 75 15.9. AUXILIARY FUNCTIONS (until 01/01/2016) ..................76 15.10. AUXILIARY FUNCTIONS (from 01/01/2016) ..................76 15.11. PRICK PROBE FUNCTION ........................77 15.12. DELTA FUNCTION ............................ 78 15.13. COOL DOWN ............................. 78 15.14.
  • Page 5 17.13.4. DELTA ..............................129 17.13.5. ºC - ºF ..............................129 17.13.6. AUTOMATIC LOCKING ........................129 17.13.7. THERMAL STOP..........................130 17.14. FAGOR COOKING ........................... 130 17.14.1. CREATE RECIPE ..........................133 17.14.2. EDIT RECIPE ............................135 17.14.3. DELETE RECIPE ..........................136 17.14.4. EXPORT ............................... 136 17.14.5.
  • Page 6 SERVICE MANUAL ADVANCE OVENS 18. OVEN CONTROL ............................... 146 18.1. ACE & ACG DISPLAY ..........................147 19. MAIN COMPONENTS ............................... 148 19.1. FREQUENCY VARIATOR OF FAN MOTOR ................... 148 19.1.1. FREQUENCY VARIATOR PARAMETERS ..................... 151 20. ELECTRICAL DIAGRAM ............................152 20.1.

  • Page 7: Introduction

    SERVICE MANUAL ADVANCE OVENS 1. INTRODUCTION Dear customer, We would like to thank you for the confidence you have placed in our brands and in our product. We are sure that this machine will meet your requirements. This manual is designed to offer the information necessary for the installation, start-up, and maintenance of ADVANCE ovens.
  • Page 8 SERVICE MANUAL ADVANCE OVENS - Report the incident to the corresponding gas supplier (if it is not possible to contact the gas supplier, call the local fire brigade). Only for gas appliances - If your appliance is installed below an extractor hood, keep this connected while the appliance is working (steam and combustion gases).
  • Page 9 Do not open the compartments marked with this symbol. Access is restricted to qualified personnel authorised by FAGOR. Failure to comply with this regulation will render the guarantee void and expose the user to the risk of injury or even loss of life.

  • Page 10: Pictograms

    SERVICE MANUAL ADVANCE OVENS 4. PICTOGRAMS Danger Risk of imminent danger that may lead to serious physical injury or loss of life. Failure to observe this instruction may result in property damage or personal injury. Warning Risk of potential hazard that may lead to serious physical injury or loss of life. Failure to observe this instruction may result in property damage or personal injury.

  • Page 11: Maintenance

    SERVICE MANUAL ADVANCE OVENS • Disconnect the water supply. • Disconnect the gas supply. • The appliance must not be in left in environments with temperatures less than 5 ºC. • Leave the door ajar to allow the air to circulate and to prevent the appearance of mould. 7.

  • Page 12: Regular Checks Performed By The User

    The machine is made of high quality stainless steel. However, under certain conditions, corrosion may appear. To keep the stainless steel surfaces permanently free of corrosion, only use suitable cleaning products. To ensure the correct operation of the equipment, Fagor Industrial recommends the following maintenance tasks are performed daily: •...

  • Page 13: Specialised Maintenance

    SERVICE MANUAL ADVANCE OVENS 7.2. SPECIALISED MAINTENANCE To ensure that the equipment is in perfect and safe condition, it should be maintained and serviced by an Authorised Service Centre at least once a year. DANGER • High voltage • Before removing the panel from the machine, accessing components and carrying out work on live components, disconnect the machine from the power supply.

  • Page 14: Check Points For Maintenance Of The Appliance

    SERVICE MANUAL ADVANCE OVENS 7.3. CHECK POINTS FOR MAINTENANCE OF THE APPLIANCE Door joint Daily Daily Daily Daily Daily Daily Upper hinge months months months months months months Lower hinge months months months months months months Lever months months months months months months...
  • Page 15 SERVICE MANUAL ADVANCE OVENS Grease collection tray months months months months months months Hoses months months months months months months Water leaks months months months months months months Contactors months months months months months months Contacts months months months months months months Chamber resistors...

  • Page 16: Maintenance Intervals

    SERVICE MANUAL ADVANCE OVENS 7.3.1. MAINTENANCE INTERVALS 7.3.2. MAINTENANCE POINTS DOOR SEAL JUNTA RACK (solo 201 y 202) HINGE DOOR LEVER LOCK DOOR SENSOR CHAMBER LIGHT FLUEPIPE CLOSING SEAL FLUEPIPE COIL MOTOR 1 MOTOR 2 (only 201 and 202) FAN 1 TURBINE FAN 2 (only 201 and 202) FREQUENCY VARIATOR 1...
  • Page 17 SERVICE MANUAL ADVANCE OVENS DOOR SEAL JUNTA RACK (solo 201 y 202) HINGE DOOR LEVER LOCK DOOR SENSOR CHAMBER LIGHT FLUEPIPE CLOSING SEAL FLUEPIPE COIL MOTOR 1 MOTOR 2 (only 201 and 202) FAN 1 TURBINE FAN 2 (only 201 and 202) FREQUENCY VARIATOR 1 FREQUENCY VARIATOR 2 (only 201 and 202) DRAINAGE PUMP...

  • Page 18: Everyday Cleaning

    SERVICE MANUAL ADVANCE OVENS STEAM BURNER BLOWER BURNER 1 GAS VALVE BURNER 2 GAS VALVE (only 201 and 202) STEAM BURNER GAS VALVE BURNER 1 IGNITION CONTROL BURNER 2 IGNITION CONTROL (only 201 and 202) STEAM BURNER IGNITION CONTROL BURNER 1 BURNER 2 (only 201 and 202) STEAM BURNER BURNER 1 AIR INTAKE...

  • Page 19: Recycling

    SERVICE MANUAL ADVANCE OVENS 9.1. RECYCLING 04/02/2020...
  • Page 20 SERVICE MANUAL ADVANCE OVENS All the packaging can be recycled. Dispose of packaging correctly. This machine does not contain components which may damage the environment if not correctly processed. The machine must not be disposed of in the municipal waste. The machine must be disposed of in accordance with the current local legislation, which can be obtained from the local authorities.

  • Page 21: General Information And Warnings

    SERVICE MANUAL ADVANCE OVENS 10. GENERAL INFORMATION AND WARNINGS BEFORE INSTALLING AND STARTING THE APPLIANCE, PLEASE READ THE INSTRUCTIONS CONTAINED IN THIS MANUAL CAREFULLY. THIS APPLIANCE IS INTENDED EXCLUSIVELY FOR PROFESSIONAL USE AND MAY ONLY BE USED BY QUALIFIED PERSONNEL. IT MUST BE INSTALLED AND REPAIRED EXCLUSIVELY BY AN AUTHORISED AND QUALIFIED TECHNICAL SUPPORT SERVICE.

  • Page 22: Dimensions

    SERVICE MANUAL ADVANCE OVENS 11. DIMENSIONS 11.1. ACE-061 A: Soft water intake B: Hard water inlet C: Electrical supply D: Drainage 04/02/2020...
  • Page 23 SERVICE MANUAL ADVANCE OVENS 11.2. AE-061 A: Soft water intake B: Hard water inlet C: Electrical supply D: Drainage 04/02/2020...
  • Page 24 SERVICE MANUAL ADVANCE OVENS 11.3. APE-061 A: Soft water intake B: Hard water inlet C: Electrical supply D: Drainage 04/02/2020...
  • Page 25 SERVICE MANUAL ADVANCE OVENS 11.4. ACE-101 A: Soft water intake B: Hard water inlet C: Electrical supply D: Drainage 04/02/2020...
  • Page 26 SERVICE MANUAL ADVANCE OVENS 11.5. AE-101 A: Soft water intake B: Hard water inlet C: Electrical supply D: Drainage 04/02/2020...
  • Page 27 SERVICE MANUAL ADVANCE OVENS 11.6. APE-101 A: Soft water intake B: Hard water inlet C: Electrical supply D: Drainage 04/02/2020...
  • Page 28 SERVICE MANUAL ADVANCE OVENS 11.7. ACE-201 A: Soft water intake B: Hard water inlet C: Electrical supply D: Drainage 04/02/2020...
  • Page 29 SERVICE MANUAL ADVANCE OVENS 11.8. AE-201 A: Soft water intake B: Hard water inlet C: Electrical supply D: Drainage 04/02/2020...
  • Page 30 SERVICE MANUAL ADVANCE OVENS 11.9. APE-201 A: Soft water intake B: Hard water inlet C: Electrical supply D: Drainage 04/02/2020...
  • Page 31 SERVICE MANUAL ADVANCE OVENS 11.10. ACE-102 A: Soft water intake B: Hard water inlet C: Electrical supply D: Drainage 04/02/2020...
  • Page 32 SERVICE MANUAL ADVANCE OVENS 11.11. AE-102 A: Soft water intake B: Hard water inlet C: Electrical supply D: Drainage 04/02/2020...
  • Page 33 SERVICE MANUAL ADVANCE OVENS 11.12. APE-102 A: Soft water intake B: Hard water inlet C: Electrical supply D: Drainage 04/02/2020...
  • Page 34 SERVICE MANUAL ADVANCE OVENS 11.13. ACE-202 A: Soft water intake B: Hard water inlet C: Electrical supply D: Drainage 04/02/2020...
  • Page 35 SERVICE MANUAL ADVANCE OVENS 11.14. AE-202 A: Soft water intake B: Hard water inlet C: Electrical supply D: Drainage 04/02/2020...
  • Page 36 SERVICE MANUAL ADVANCE OVENS 11.15. APE-202 A: Soft water intake B: Hard water inlet C: Electrical supply D: Drainage 04/02/2020...
  • Page 37 SERVICE MANUAL ADVANCE OVENS 11.16. ACG-061 A: Soft water intake B: Hard water inlet C: Electrical supply D: Drainage E: Gas inlet F: Air inlet 04/02/2020...
  • Page 38 SERVICE MANUAL ADVANCE OVENS 11.17. AG-061 A: Soft water intake B: Hard water inlet C: Electrical supply D: Drainage E: Gas inlet F: Air inlet 04/02/2020...
  • Page 39 SERVICE MANUAL ADVANCE OVENS 11.18. APG-061 A: Soft water intake B: Hard water inlet C: Electrical supply D: Drainage E: Gas inlet F: Air inlet 04/02/2020...
  • Page 40 SERVICE MANUAL ADVANCE OVENS 11.19. ACG-101 A: Soft water intake B: Hard water inlet C: Electrical supply D: Drainage E: Gas inlet F: Air inlet 04/02/2020...
  • Page 41 SERVICE MANUAL ADVANCE OVENS 11.20. AG-101 A: Soft water intake B: Hard water inlet C: Electrical supply D: Drainage E: Gas inlet F: Air inlet 04/02/2020...
  • Page 42 SERVICE MANUAL ADVANCE OVENS 11.21. APG-101 A: Soft water intake B: Hard water inlet C: Electrical supply D: Drainage E: Gas inlet F: Air inlet 04/02/2020...
  • Page 43 SERVICE MANUAL ADVANCE OVENS 11.22. ACG-201 A: Soft water intake B: Hard water inlet C: Electrical supply D: Drainage E: Gas inlet F: Air inlet 04/02/2020...
  • Page 44 SERVICE MANUAL ADVANCE OVENS 11.23. AG-201 A: Soft water intake B: Hard water inlet C: Electrical supply D: Drainage E: Gas inlet F: Air inlet 04/02/2020...
  • Page 45 SERVICE MANUAL ADVANCE OVENS 11.24. APG-201 A: Soft water intake B: Hard water inlet C: Electrical supply D: Drainage E: Gas inlet F: Air inlet 04/02/2020...
  • Page 46 SERVICE MANUAL ADVANCE OVENS 11.25. AG-102 A: Soft water intake B: Hard water inlet C: Electrical supply D: Drainage E: Gas inlet F: Air inlet 04/02/2020...
  • Page 47 SERVICE MANUAL ADVANCE OVENS 11.26. ACG-102 A: Soft water intake B: Hard water inlet C: Electrical supply D: Drainage E: Gas inlet F: Air inlet 04/02/2020...
  • Page 48 SERVICE MANUAL ADVANCE OVENS 11.27. APG-102 A: Soft water intake B: Hard water inlet C: Electrical supply D: Drainage E: Gas inlet F: Air inlet 04/02/2020...
  • Page 49 SERVICE MANUAL ADVANCE OVENS 11.28. ACG-202 A: Soft water intake B: Hard water inlet C: Electrical supply D: Drainage E: Gas inlet F: Air inlet 04/02/2020...
  • Page 50 SERVICE MANUAL ADVANCE OVENS 11.29. AG-202 A: Soft water intake B: Hard water inlet C: Electrical supply D: Drainage E: Gas inlet F: Air inlet 04/02/2020...
  • Page 51 SERVICE MANUAL ADVANCE OVENS 11.30. APG-202 A: Soft water intake B: Hard water inlet C: Electrical supply D: Drainage E: Gas inlet F: Air inlet 04/02/2020...
  • Page 52 SERVICE MANUAL ADVANCE OVENS 12. TECHNICAL DATA 12.1. MACHINE SPECIFICATIONS The machine you have just purchased is a specialised product for the cooking of food, used in restaurants and hostelry. As it is an industrial product, it is characterised for having a high capacity. All the appliances have a specifications plate which identifies the appliance and indicates its technical characteristics, it is located on one side of the machine.
  • Page 53 SERVICE MANUAL ADVANCE OVENS 12.2.2. AE (ADVANCE ELECTRIC) SUPPLY POWER SWITCH MOD. HOSE DIAMETER TOTAL POWER kW VOLTAGE GENERAL 400V 3N~ 50/-60Hz 3x1.5 mm + N+T AE-0623 230V 3~ 50/-60Hz 3x2.5 mm²+T 230V 1~ 50/-60Hz 2x4 mm²+T 400V 3N~ 50/-60Hz 3x2.5 mm +N+T AE-061...
  • Page 54 SERVICE MANUAL ADVANCE OVENS 12.2.4. ACG (ADVANCE CONCEPT GAS) SUPPLY CABLE POWER SWITCH MOD. VOLTAGE SECTION GENERAL 230V 50-60Hz 2 x 1.5 mm² + T ELECTRICAL OUTPUT 1.2 kW ACG-061 kcal/h (Hi) G30/G31/G20 10,325 POWER BTU/h (Hi) G30/G31/G20 40,975 HEATING Kw (Hi) G30/G31/G20 230V 50-60Hz...
  • Page 55 SERVICE MANUAL ADVANCE OVENS 12.2.5. AG (ADVANCE GAS) SUPPLY CABLE POWER SWITCH MOD. VOLTAGE SECTION GENERAL 230V 50-60Hz 2 x 1.5 mm² + T ELECTRICAL OUTPUT 1.2 kW AG-061 kcal/h (Hi) G30/G31/G20 10,325 POWER BTU/h (Hi) G30/G31/G20 40,975 HEATING Kw (Hi) G30/G31/G20 230V 50-60Hz 2 x 1.5 mm²...
  • Page 56 SERVICE MANUAL ADVANCE OVENS 12.2.6. APG (ADVANCE PLUS GAS) SUPPLY CABLE POWER SWITCH MOD. VOLTAGE SECTION GENERAL 230V 50-60Hz 2 x 1.5 mm² + T ELECTRICAL OUTPUT 1.2 kW APG-061 kcal/h (Hi) G30/G31/G20 10,325 POWER BTU/h (Hi) G30/G31/G20 40,975 HEATING Kw (Hi) G30/G31/G20 230V 50-60Hz...
  • Page 57 SERVICE MANUAL ADVANCE OVENS 13. INSTALLATION OF THE MACHINE THE MANUFACTURER MAY NOT BE HELD LIABLE FOR ANY PROPERTY DAMAGE OR PERSONAL INJURY RESULTING FROM THE INCORRECT INSTALLATION, USE, MAINTENANCE OR REPAIR, OR CAUSED BY FAILURE TO COMPLY WITH THE STANDARDS AND INSTRUCTIONS PROVIDED.
  • Page 58 SERVICE MANUAL ADVANCE OVENS 13.2. INSTALLATION OF TABLE TOP MODELS Level the frame horizontally before placing the oven on the frame. Rest the oven on the frame and line up the supports with the holes on the frame. The appliance must be horizontally level. tray s are placed in the oven at a maximum height of 1.60 m, provided the original accessories are...
  • Page 59 The mobile load trolley (optional) must be horizontal on the appliance. 13.4. LEVELLING Fagor Industrial recommends that the place where the appliance is to be installed should be analysed prior to installation to check that it is suitable. For optimum operation, it is essential that the appliance is correctly levelled.
  • Page 60 SERVICE MANUAL ADVANCE OVENS 14. CONNECTIONS 14.1. ELECTRICAL CONNECTION Before connecting the machine to the power connection, check that the network voltage and frequency correspond to those indicated on the appliance nameplate. Check that the cross-section of the power cable is appropriate for the required consumption.
  • Page 61 SERVICE MANUAL ADVANCE OVENS 14.2. HYDRAULIC CONNECTION Connect the machine to the mains water supply at the points indicated, using the hose supplied. The pressure of the incoming water should be between 200 and 400 kPa (2÷4 kg/cm = 2÷4 bar). We recommend 250 kPa. pH: 6,5 ÷...
  • Page 62 SERVICE MANUAL ADVANCE OVENS WATER INLET TEMPERATURE Min. Max. 40 ºC / 104 Cold Water 15 ºC / 59 ºF ºF 40 ºC / 104 60 ºC / 140 Hot Water ºF ºF For the correct hydraulic installation of the machine, you must: •...
  • Page 63 SERVICE MANUAL ADVANCE OVENS Incorrect installation of the oven may result in the incorrect operation of the appliance. Therefore, the drainage Kit supplied (DN50) by the manufacturer should be installed (Fig. 12). This drainage system should be connected to an open tank or grille.
  • Page 64 SERVICE MANUAL ADVANCE OVENS El kit contains the following units, which can be assembled in various ways, depending on where the oven is installed. Advance/ Concept oven configuration Advance Plus oven configuration During assembly, care should be taken to ensure that the holes are facing the opposite side to the oven panel 04/02/2020...
  • Page 65 SERVICE MANUAL ADVANCE OVENS 14.4. GAS PNEUMATIC CONNECTION It is essential to ensure that the gas supply pipes and the connection pipes for the corresponding measurement systems are the correct diameter. Once the appliance has been connected, check that there are no leaks using a gas detector (spray, etc.).
  • Page 66 2E3P HU - IS - MT - NL 3B/P Fagor Industrial recommend the annual maintenance by an authorised technician of the components relating to the gas installation. 14.6. VENTILATION OF THE PREMISES The machines must be installed in such a way as to allow adequate ventilation to prevent the unauthorised concentration in the premises of steam and products emitted during combustion, which may be harmful to health.
  • Page 67 SERVICE MANUAL ADVANCE OVENS 14.7.3. GAS OVEN CONNECTED TO EVACUATION FLUEPIPE (TYPE B13) Convection/combined ovens with a non-return draught diverter system (special accessory) may be connected directly to the fluepipe. The draught diverter accessory can be ordered using the following references: Oven model 061/101: 19012272 Oven model 201: 19012290...
  • Page 68 To validate your rights to guarantee, please ask the Technical Service installing the oven to complete the present checklist and send it, duly completed, to the corresponding branch of Fagor Industrial, within 15 days of the installation and start-up of the oven. Company or premises where oven is installed: __________________________________________...
  • Page 69 Is there any other equipment at less than 500 mm from the oven? “ ” , what type of equipment? ___________________________________ d) Has a hood/extractor system been installed? e) Is there a genuine FAGOR extractor hood installed? “ ” , what model is it? ___________________________ “...
  • Page 70 SERVICE MANUAL ADVANCE OVENS 4. Gas installation a) Is the gas supply to the oven independent? b) Is the cut-off tap for the gas supply to the oven independent? c) Can the cut-off tap for the gas supply to the oven be accessed by the user? d) Has the oven been converted to gas? e) Is the gas control to the oven independent? “...
  • Page 71 SERVICE MANUAL ADVANCE OVENS 15. USE OF CONCEPT ACE & ACG OVENS 15.1. ACE ELECTRIC OVEN CONTROL PANEL (until 01/01/2016) Oven ON switch Oven OFF switch Convection/Mixed/Regeneration/Steam operating mode Selector/Button Convection mode display Mixed mode display Regeneration mode display Steam mode display Chamber true temperature Temperature setting, chamber Temperature selector encoder...
  • Page 72 SERVICE MANUAL ADVANCE OVENS 15.2. ACG GAS OVEN CONTROL PANEL (until 01/01/2016) 1. Oven ON switch 2. Oven OFF switch 3. Convection/Mixed/Regeneration/Stea operating mode Selector/Button 4. Convection mode display 5. Mixed mode display 6. Regeneration mode display 7. Steam mode display 8.
  • Page 73 SERVICE MANUAL ADVANCE OVENS 15.3. ACE & ACG ELECTRIC OVEN CONTROL PANEL (from 01/01/2016) 1. Oven ON switch 2. Oven OFF switch 3. Convection/Mixed/Regeneration/Steam operating mode Selector/Button 4. Convection mode display 5. Mixed mode display 6. Regeneration mode display 7. Steam mode display 8.
  • Page 74 SERVICE MANUAL ADVANCE OVENS 15.4. ON/OFF To start the oven, press and to switch it off, press OFF. Each time that the oven is switched on, the last-used values are displayed. If this is the first time the oven is switched on, the defect values are displayed.
  • Page 75 SERVICE MANUAL ADVANCE OVENS • If 95 ºC <X<106 ºC: It operates continuously ” • If 105 ºC <X<251 ºC: The output VHM stops when TV>=(TC/4+77 ºC) and is reset (6 ” ” cycles (2 ON, 4 OFF)) when TV<=(TC/4+74 ºC) REGENERATION (40% dry heat + 60% moist heat): Heating uses hot air and steam simultaneously, but with •...
  • Page 76 SERVICE MANUAL ADVANCE OVENS 15.7. TIME SELECTION The encoder is used to increase /decrease the cooking time setting. This enables the increase/decrease of the cooking time setting in units. Remaining time: Displays the cooking time remaining. This time decreases every minute, displaying the final point if the countdown is active.
  • Page 77 SERVICE MANUAL ADVANCE OVENS 15.9. AUXILIARY FUNCTIONS (until 01/01/2016) 18/19/20-. Temperature / Spike / Delta selector button (optional) 21-Button / Cool down display 22-Humidifier button 23-Unlock gas The appliance has Auxiliary Functions including: Temperature / Spike / Delta selector button Button / Cool down display Humidifier button Unlock gas (Only AGC)
  • Page 78 SERVICE MANUAL ADVANCE OVENS 15.11. PRICK PROBE FUNCTION The Spike Probe function is an Auxiliary Function of the cooking process which uses the temperature reading taken from the core of the product being cooked to control the length of the cooking process. For this, use the Spike Probe and select the relevant function.
  • Page 79 SERVICE MANUAL ADVANCE OVENS 15.12. DELTA FUNCTION The DELTA Function is an Auxiliary Function which operates with the temperature difference between the true core temperature and the temperature of the chamber. The Chamber Setting Temperature is always 50 ºC higher than the temperature recorded by the Core Probe. As the value of the True Core Temperature increases, the Chamber Temperature Setting also increases automatically by the same amount.
  • Page 80 Remove possible traces of chemicals and rinse the inside of the cooking chamber thoroughly with the hand shower. Fagor Industrial recommends the use of the product KOIPERRE PLUS for this process. Other chemical processes may damage the appliance or its components.
  • Page 81 SERVICE MANUAL ADVANCE OVENS 15.17.1. KOIPERRE PLUS TECHNICAL SPECIFICATIONS DOSAGE PRODUCT SPECIFICATIONS It is dispensed: In a concentration of one part product Particularly suitable for the removal of fat and grease and five parts water burnt onto the hot plates of industrial cookers, ovens, If the oven is very dirty, use the product without extractor hoods, etc.
  • Page 82 SERVICE MANUAL ADVANCE OVENS 15.17.2. KOIPERRE PLUS SAFETY DATA SHEET In accordance with standard ISO-11.014, RD 255/03 and RD 770/99 TOXICOLOGY REGISTRY: SIT NO. A-532/01 HEALTH REGISTRY No 37/0043- BI 1. IDENTIFICATION OF THE PRODUCT AND THE COMPANY Name: Koiperre Plus. Description: liquid detergent for removing burnt grease and fat on kitchen hot plates, ovens...
  • Page 83 SERVICE MANUAL ADVANCE OVENS 7. HANDLING, STORAGE. AND USES Handling: Personal protective equipment should prevent product coming into contact with the skin and eyes. Goggles, rubber gloves and boots. Hazards due to Contact with eyes: Conjunctivitis, burns. Contact with skin: Burns.
  • Page 84 SERVICE MANUAL ADVANCE OVENS 13. CONSIDERATIONS REGARDING ITS DISPOSAL Product: Neutralise solutions with very dilute hydrochloric acid, flush effluent with plenty of water, controlling PH. Containers: Wash with plenty of water. Never use for other products. 14. INFORMATION FOR THE USER No special transport is required for this product.
  • Page 85 SERVICE MANUAL ADVANCE OVENS 15.18. DISPLAY STATE OF THE BURNER In order to display the state of the convection burner, a dot lights up in the upper left display whenever a flame is detected in the combustion box. 15.19. DISPLAY THERMOCOUPLE READING When Cool Down, is pressed for more than 5 seconds, the value of all the...
  • Page 86 SERVICE MANUAL ADVANCE OVENS – Differential TC (-20 - 20 ºC) – – Differential TN (-20 - 20 ºC) Use the Humidify button to scroll forward through the different probes and the Cool Down button to scroll back. Use the Time Selection Encoder to allocate the difference observed between the reading from the exterior probe (exterior thermometer) and the temperature shown on the display.
  • Page 87 SERVICE MANUAL ADVANCE OVENS 15.21.1. SECTIONS AND OPTIONS OF SETTINGS MENU. ELECTRIC/GAS This configures the oven as electric or gas. = [OPT] = [OP1] = [E-G] = [ELE] (Electric oven. Default setting) [GAS] (Gas oven) MODEL This configures the size of the oven. = [OPT] = [OP2] = [MOD]...
  • Page 88 SERVICE MANUAL ADVANCE OVENS The available inputs/outputs in the oven can be checked and tested individually. When in this mode, select the required input/output using the temperature selector. For outputs, use Humidifier to activate the output in question, and Cool Down deactivate it.
  • Page 89 SERVICE MANUAL ADVANCE OVENS No CC2 Cycles Number of CC2 cycles. DSI = [HIS], DSD = [CC2], DII+DID = value No VCN Cycles Number of VCN cycles. DSI = [HIS], DSD = [CCN], DII+DID = value No Ms/Mb Cycles Number of Ms/Mb cycles. DSI = [HIS], DSD = [CMS], DII+DID = value No VHM Cycles Number of VHM cycles.
  • Page 90 SERVICE MANUAL ADVANCE OVENS Reset Option to reset all log parameters. DSI = [HIS], DSD = [RST], DID = [INI] EXHIBITION Option allowing the oven to be set in Exhibition mode. To enter, press Humidifier. = [OPT] = [OP8] = [SHO] = [INI] To exit this mode, return to the SETTINGS...
  • Page 91 SERVICE MANUAL ADVANCE OVENS To display the version, press Humidifier, and view as follows: = [PPC] = [CVV] = [GG] To exit this mode, press Cool Down. GAS TYPE (ONLY AGC) As different types of gas are used (LPG B/P, NG) the Burner Fan Speeds should be adapted to obtain optimum combustion.
  • Page 92 SERVICE MANUAL ADVANCE OVENS TABLE OF DEFAULT BLOWER SPEEDS NATURAL GAS ( G20) LPG (B/P) ( G30/31) CITY GAS ( G-110 ) Start-up: 4000 Start-up: 4000 Start-up: ACG-061 Medium: 4200 Medium: 3600 Medium: Maximum: 6500 Maximum: 5400 Maximum: Start-up Speed: 5000 Start-up: 5000 Start-up: ACG-101...
  • Page 93 SERVICE MANUAL ADVANCE OVENS The oven operates in Mixed Mode at 250ºC. Every 30 seconds the direction of the fan is changed with R/L. Display: = value TC = 250 = M/P = R/L The true value of the thermocouples can be displayed by pressing Cool Down for 5 seconds.
  • Page 94 SERVICE MANUAL ADVANCE OVENS 15.22. TYPES OF FAULT When an error occurs: The bell rings intermittently. • • The code and error identification are displayed in the oven windows. If the START/STOP, button is pressed, the error message continues to be displayed but the bell stops •...
  • Page 95 SERVICE MANUAL ADVANCE OVENS 15.23. ACRONYMS TC: Chamber probe TV: Steam output probe TN: Core probe IP: Door switch HALL: Gas control signal A.E.: Variator frequency input CC: Chamber heating M/P: Fan motor Start/Stop R/L: Fan motor direction of rotation (left/right) VCN: Condensation solenoid valve VHM: Humidifier solenoid valve Ms/Mb: Chimney motor...
  • Page 96 SERVICE MANUAL ADVANCE OVENS 16. USE OF ADVANCE AE & AG OVEN 16.1. AE & AG ELECTRIC OVEN CONTROL PANEL (until 01/01/2016) 1-Turning the oven on 2- Turning the oven off 3 - General information text 4 - Cooking mode selector switch 5 - Cooking mode display 6 - Temp.
  • Page 97 SERVICE MANUAL ADVANCE OVENS 16.2. AE & AG ELECTRIC OVEN CONTROL PANEL (from 01/01/2016) 1-Turning the oven ON “ ” 2 - Turning the oven 3 - General information text 4 - Cooking mode selector switch 5 - Cooking mode display 6 - Temp.
  • Page 98 SERVICE MANUAL ADVANCE OVENS 16.3. ON/OFF To start the oven, press and to switch it off, press OFF. Each time that the oven is switched on, the last-used values are displayed. If this is the first time the oven is switched on, the defect values are displayed.
  • Page 99 SERVICE MANUAL ADVANCE OVENS Regeneration  Controlled  Steam  Temperature selector button (3rd row) Selects operating temperature. Displays temperature setting selected • by user and true temperature of chamber (chamber probe). Time selector button (4th row) Selects operating time in hours and minutes. Displays time selected •...
  • Page 100 SERVICE MANUAL ADVANCE OVENS … Warnings (Door open, load food, • Errors: • • Oven mode (Cooking or Stopped). This information is always displayed unless any of the above points are being displayed. 16.5. SELECTION OF COOKING MODES By pressing the Cooking Mode selector, the mode selector option is activated.
  • Page 101 SERVICE MANUAL ADVANCE OVENS Convection Mixed Regeneration Controlled steam Steam Range [20÷300] ºC Range [20÷250] ºC Range [20÷180] ºC Range [35÷125] ºC Range [99 ºC] 160 ºC (default 140 ºC (default 120 ºC (default 80 ºC (default 99 ºC (default setting) setting) setting)
  • Page 102 SERVICE MANUAL ADVANCE OVENS Convection Mixed Regeneration Controlled steam Steam Range [20÷300] ºC Range [20÷250] ºC Range [20÷180] ºC Range [35÷125] ºC Range [99 ºC] 16.10. DELTA FUNCTION The Delta Function operates with a difference between the core temperature and the oven temperature (50 ºC default setting).
  • Page 103 SERVICE MANUAL ADVANCE OVENS 16.13. AUXILIARY FUNCTIONS (from 01/01/2016) The Auxiliary Function of the oven is selected by pressing the Auxiliary Function Selector. All the Auxiliary Options light up and the General Selector is turned until obtaining the required option. Confirm this value by pressing the Time Selector again or by pressing the General Option...
  • Page 104 SERVICE MANUAL ADVANCE OVENS Once the message DESCALE has been displayed, it will not disappear until descaling takes place, even though the TG temperature falls or if the oven is switched off. The message reappears when the oven is switched on. 16.16.2.
  • Page 105 SERVICE MANUAL ADVANCE OVENS To descale, apply the chemical product in the quantities indicated by the manufacturer. For the descaling process, we recommend using a phosphoric acid based product with a concentration of 30 - 40%. In this concentration, we recommend using 25% of the generator volume. In all cases, please observe chemical ’...
  • Page 106 SERVICE MANUAL ADVANCE OVENS will also be aborted. To access this option the oven should be switched on but in STOP mode. 16.22. CONFIGURE SYSTEM To access this option, the oven should be switched off. Function to access system configuration, where the following sections can be configured: Language: Select required language.
  • Page 107 SERVICE MANUAL ADVANCE OVENS To exit the menu, select the option EXIT, and return to normal operation of the oven. 16.23. SETTINGS (OVEN CONFIGURATION) This function is protected by a password, which can be accessed by pressing the buttons Configure System Delayed Programming for 5 seconds while the oven is switched off.
  • Page 108 SERVICE MANUAL ADVANCE OVENS 0 ÷ 10 (Default setting: 2 seconds)  TABLE OF DEFAULT CONVECTION BLOWER SPEEDS NATURAL GAS TOWN GAS LGP (B/P) Start-up: 4000 Start-up: 4000 Start-up: 4000 AG-061 Medium: 4200 Medium: 4200 Medium: 3600 Maximum: 6500 Maximum: 6500 Maximum: 5400 Start-up Speed: 5000 Start-up: 5000...
  • Page 109 SERVICE MANUAL ADVANCE OVENS M50 Drain. Manu Option permitting the drainage of the boiler. To start, press the button on the wheel. Press again to abort the operation. If the user does not abort, the drainage will automatically stop when the level falls below minimum M51 Back Returns to previous menu...
  • Page 110 SERVICE MANUAL ADVANCE OVENS Resistance Door contactor Maximum level probe Minimum level probe Gas control signal HALL. To read the burner blower input, first activate the output with the blower speed selected. (only in gas ovens). Outputs for testing Chamber heating (CC1) Chamber heating (CC2) Fan on Fan direction...
  • Page 111 SERVICE MANUAL ADVANCE OVENS M3 H Prg Regen - Total hours of operation in Regeneration mode. - Total hours of operation in Controlled Steam mode. M4 H Prg CtrlSt M5 H Prg Steam - Total hours of operation in Steam mode. M6 CC1 Cycles - Number of CC1 cycles.
  • Page 112 SERVICE MANUAL ADVANCE OVENS 16.24. TYPES OF FAULT ERROR DESCRIPTION CONSEQUENCE Camera probe broken. TC E1 SENSOR TC The oven is completely disabled. out of range [-5 ÷ 330 ºC]. Core probe TN damaged. E2 SENSOR TN TN out of range [-10 ÷ 330 The spike and delta function is disabled.
  • Page 113 SERVICE MANUAL ADVANCE OVENS Chamber ignition control E14 BLOWER Q1 (only AG) blocked. This occurs after The oven is completely disabled. 3 failed ignition attempts. - Fault in the chamber ignition control. E15 FAULT Q1 (only AG) - SV gas is not activated. The oven is completely disabled.
  • Page 114 When the screen is switched on, the Initial Screen is displayed, unless the oven was switched off in Fagor Easy or Exhibition mode, in which case the screen for the corresponding mode is displayed. The parameters displayed on screen correspond to those used for the last operation, using the default values if this is the first time the oven is switched on or in order to re-establish the factory parameters.
  • Page 115 SERVICE MANUAL ADVANCE OVENS The screen is shown below in off mode, with the configuration selected by the user, who can select whether they wish to view the date and/or time in addition to the required text. If the screen remains in OFF mode for 5 minutes, the back-light will automatically switch off. To re-activate it, just touch the screen.
  • Page 116 898 in time (9:38 displayed) • Fagor Cooking (7th row 3rd button): Press this button to go to the oven automatic operating mode. This includes recipes programmed at the factory, divided into families, together with personal user-defined programmes.
  • Page 117 SERVICE MANUAL ADVANCE OVENS 17.2. ON/OFF The oven is switched on/off with the main ON/OFF switch. Each time that the oven is switched on, the last-used values are displayed. If this is the first time the oven is switched on, the defect values are displayed. When the oven is switched on, it adopts the last used parameters.
  • Page 118 SERVICE MANUAL ADVANCE OVENS 17.5. TEMPERATURE SELECTION This section shows the true chamber temperature and that selected by the user. The temperature shown on the left side of the screen is the true temperature in the chamber. The temperature shown on the right side of the screen shows the temperature selected by the user. The range of temperatures for each operating mode is shown below: Convection: Range (20 ÷...
  • Page 119 SERVICE MANUAL ADVANCE OVENS 17.7. PREHEATING To preheat the oven it must be switched off and the required temperature must be higher than the temperature in the chamber. Select the operating mode. Select the required oven temperature. Press time / spike / Delta display Select time 0 and press OK.
  • Page 120 SERVICE MANUAL ADVANCE OVENS By pressing the Time/Spike/Delta display buttons, the values are selected numerically. When the true temperature of the core reaches the selected value, an acoustic warning is heard. To switch off the alarm, press the START/STOP button or open the door. If the door is not opened, or if the START/STOP, button is not pressed, the acoustic warning is repeated for 30 seconds every 3 minutes, up to a maximum of 15 minutes.
  • Page 121 SERVICE MANUAL ADVANCE OVENS If the operation is cancelled, the oven switched off, there is a power failure or the appliance is disconnected, the next time it is switched on, the machine indicates that the wash was interrupted, and a rinse cycle is run to remove any soap that may be left in the chamber.
  • Page 122 SERVICE MANUAL ADVANCE OVENS Sub-rinse • 30 sec activated (drainage closes) and CV activated until TG reaches 70 ºC. ” • 50 sec activated 50 5 min ” • 90 sec activated, < 65 ºC, D/I, (wash pump motor) (8 ”...
  • Page 123 SERVICE MANUAL ADVANCE OVENS MEDIUM WASH Before starting to wash, the oven displays the message INSERT SOAP, and waits for user confirmation before continuing with the wash cycle. The TFT displays the title of the wash programme together with the current cycle and the time remaining, operating as follows: Steam mode (99 ºC): 5 minutes.
  • Page 124 SERVICE MANUAL ADVANCE OVENS INTENSE WASH Before starting to wash, the oven displays the message INSERT SOAP, and waits for user confirmation before continuing with the wash cycle. The TFT displays the title of the wash programme together with the current cycle and the time remaining, operating as follows: Steam mode (99 ºC): 5 minutes.
  • Page 125 SERVICE MANUAL ADVANCE OVENS SEMI-AUTOMATIC WASH The TFT displays the title of the wash programme together with the current cycle and the time remaining, operating as follows: Steam: 10 min. Mc. operates • The following message is displayed: SPRAY WITH DESCALER until opening and closing the •...
  • Page 126 SERVICE MANUAL ADVANCE OVENS 17.12.2. DELAYED PROGRAMME The delayed programme allows you to programme the oven to cook and be washed at the time you require. 1. Select menu option. 2. Select delayed programming option. 3. Select time by pressing 4.
  • Page 127 SERVICE MANUAL ADVANCE OVENS This function is used to access the descaling cycle. 1. Press the descaling button. 2. Select time (30 - 480 min.) 120 min. default setting. 3. Warning SPRAY DESCALER (3 minutes). 4. Insert descaler in steam generator (rear section of the oven). 5.
  • Page 128 1. Connect the USB memory stick to the oven when it is switched off. 2. Switch on the oven. 3. Confirm the option START HACCP. 4. After the message END HACCP DOWNLOAD switch off the oven. 5. Remove the USB memory stick. 6. Process the information in the Fagor HACCP application. 04/02/2020...
  • Page 129 SERVICE MANUAL ADVANCE OVENS 17.13. CONFIGURE SYSTEM 17.13.1. LANGUAGE This allows you to select between 27 different languages. Spanish is the default language. 1. Press the language button 2. Select the required language Hindi Arabic Spanish Thai English Korean Italian Dutch French Russian...
  • Page 130 SERVICE MANUAL ADVANCE OVENS 17.13.2. DATE TIME This allows you to update the date and time. 1. Press the button, programme time and date. 2. Press the time button and select the time using the up /down buttons.  3. Press the date button and select the date using the up /down buttons.
  • Page 131 However the user can enter a total number of recipes dependent on the available memory (undefined). Each of the sections contains various recipes invented by the FAGOR INDUSTRIAL chefs. 1. Press any option. 2. Select the required recipe.
  • Page 132 SERVICE MANUAL ADVANCE OVENS Cuttlefish  Steam: 12 minutes 99 ºC. • Poultry: This includes all the recipes belonging to the Poultry group, whether pre-programmed or personally programmed. The pre-programmed recipes include: Chicken  Steam: 10 minutes 90 ºC. • Mixed 20%: Spike 80 ºC at 220 ºC •...
  • Page 133 SERVICE MANUAL ADVANCE OVENS Spinach  Steam: 6 minutes 99 ºC. • Frozen broccoli  Steam: 8 minutes 99 ºC. • Cakes and pastries: This includes all the recipes belonging to the Cakes and pastries group, whether pre-programmed or personally programmed. The pre-programmed recipes include: Sponge cake ...
  • Page 134 SERVICE MANUAL ADVANCE OVENS • When Start is pressed, the oven is heated with the function established in the first phase, 30 degrees above the setting for the first phase (note that the upper limit established for this operating mode can never be exceeded), and the buzzer sounds when the temperature in question is reached.
  • Page 135 SERVICE MANUAL ADVANCE OVENS Edit conditions and steps in recipe. Confirm save recipe. To create a new programme, select all the parameters (Mode, Function, Humidity, Temperature, Time and Fan Power/Speed for each phase (1 to 9) required in the programme, assign the required name using a key enabled for this purpose (See fig.5) and indicate the family to which it belongs.
  • Page 136 SERVICE MANUAL ADVANCE OVENS 17.14.2. EDIT RECIPE Allows an existing recipe to be copied or modified. To do so, once the recipe has been edited and the required changes made, it is possible to save the recipe. The recipe will be modified with the name it already had or it can be saved with a new name in the required recipe group.
  • Page 137 (USB), all the recipes on the USB memory stick will be copied and the existing recipes stored on the oven will be deleted 17.15. FAGOR EASY FAGOR EASY option on the start screen enables you to obtain a simple setting of the screen.
  • Page 138 SERVICE MANUAL ADVANCE OVENS 17.16. SAT MENU The options available to the SAT technician and the internal operator for the configuration or inspection of the oven are shown below. To enter, while the oven is in Convection or Mixed mode, enter 989 in temperature value and 898 in time value. Blower speed (only for gas ovens): Option to indicate the speed of each blower in gas ovens, between 0 and •...
  • Page 139 SERVICE MANUAL ADVANCE OVENS Start-up: 4000 Start-up: 4000 Start-up: 4000 Medium: Tg>90ºC, - Medium: 5000 Medium: Tg>90ºC, - APG-061 15%Max Maximum: 5000 15%Max Maximum: 5000 Maximum: 4300 Start-up Speed: 5000 Start-up: 5000 Start-up: 5000 Medium: Tg>90ºC, - Medium: 6600 Medium: Tg>90ºC, - APG-101 15%Max Maximum: 6600...
  • Page 140 SERVICE MANUAL ADVANCE OVENS • Control panel mode Only the interface and outputs RG and LZ operate, all other inputs/outputs are disabled and all errors are ignored. The values of the TC and TN probes are fixed. Wash Mode The oven runs the intense wash programme and continues in this cycle until •...
  • Page 141 There is an option to reset the log by pressing START/STOP for 5 seconds. The data can also be reset one by one. To do so press the Screen ON button for 5 seconds Settings: To enter this mode for internal use by Fagor Industrial, a sequence must be entered “...
  • Page 142 SERVICE MANUAL ADVANCE OVENS Reliability programme 1 This is the sequence which should be repeated: o 8 hours Convection Mode at 120 ºC o 8 hours Mixed Mode at 110 ºC o 8 hours Steam Mode Display: True operating parameters Reliability programme 2 The oven will operate in Convection Mode at 100 ºC.
  • Page 143 SERVICE MANUAL ADVANCE OVENS Chimney motor (Ms/Mb). Main supply relay (RG). Fan (VE). Oven lighting (LZ). Drainage pump (VAC). Wash pump (Mba). Drainage motor (Mc/Ma). Water inlet solenoid valve (VDV). Steam heating (CV1). Steam heating (CV2). Warning bell (TA). • All outputs are in by default in OFF mode.
  • Page 144 SERVICE MANUAL ADVANCE OVENS It is only possible to operate in Convection mode “E6 CALIBRATION” DESCRIPTION It was not possible to calibrate in 15 minutes. CONSEQUENCE The oven continues to function normally. “ ” E7 ERROR AE (disabled) DESCRIPTION AE inlet does not work The connection has been cut off The motor does not start within 10 seconds of a start request.
  • Page 145 SERVICE MANUAL ADVANCE OVENS CONSEQUENCE The oven is completely disabled. “ ” E15 FAULT Q1 (Only gas ovens) DESCRIPTION Fault in the chamber ignition control SV gas is not activated. Not possible to unlock ignition control. CONSEQUENCE The oven is completely disabled. “...
  • Page 146 SERVICE MANUAL ADVANCE OVENS DESCRIPTION Communication error. The boiler card does not respond. CONSEQUENCE It is only possible to operate in Convection mode “ ” E27 BMF GAS CONNEX (Only gas ovens) DESCRIPTION Communication error. The gas card does not respond. CONSEQUENCE The oven is completely disabled 17.18.
  • Page 147 SERVICE MANUAL ADVANCE OVENS 18. OVEN CONTROL VIEWER CONTROL 12 V DISPLAY ADVANCE CONCEPT STEAM + WASH MAIN CONTROL GENERATOR CONTROL CONTROL 12V DISPLAY ADVANCE CONTROL STEAM CARD CARD CONTROL CARD CONTRO HEATING CHAMBE ADVANCE PLATFORM PLUS BMF COMMUNICATION 04/02/2020...
  • Page 148 SERVICE MANUAL ADVANCE OVENS 18.1. ACE & ACG DISPLAY Chamber temperature selector ⇒ Time / core temperature selector switch ⇒ Chamber temperature display (Setting + True) ⇒ Time / core temperature display (Setting + True) ⇒ ⇒ Buzzer ⇒ Interface with membrane keyboard ⇒...
  • Page 149 SERVICE MANUAL ADVANCE OVENS 19. MAIN COMPONENTS 19.1. FREQUENCY VARIATOR OF FAN MOTOR Programmer keypad 04/02/2020...
  • Page 150 SERVICE MANUAL ADVANCE OVENS To check the frequency variator of the chamber turbine motor, measure the following voltages: Electronic Card Contact, Frequency Variator Contact: Voltage Input ≈ ÷ 230 V AC Output to motor ≈ ÷ 215 V AC ≈ ÷...
  • Page 151 SERVICE MANUAL ADVANCE OVENS FREQUENCY VARIATOR PARAMETERS “ ” “ ” “ ” To access the frequency variator parameters, press . To exit this option, press again. If any of the Basic “ ” level values are modified, level must be programmed again. 04/02/2020...
  • Page 152 SERVICE MANUAL ADVANCE OVENS 19.1.1. FREQUENCY VARIATOR PARAMETERS Value Parameter Definition Elec Elec+Gas Elec+Gas Elec+Gas Start P0010 programming Value in kW 50 P0100 P0304 Vn (V) P0305 IN (A) P0307 PN (kW) 0.37 0.37 0.37 0.37 0.37 0.37 P0310 Fn (Hz) P0311 rpm (Nom) 1400...
  • Page 153 SERVICE MANUAL ADVANCE OVENS 20. ELECTRICAL DIAGRAM 20.1. ELECTRICAL CIRCUIT DIAGRAM FOR ELECTRIC OVEN (until 01/01/2016) 04/02/2020...
  • Page 154 SERVICE MANUAL ADVANCE OVENS 20.2. ACE ELECTRICAL CIRCUIT DIAGRAM (from 01/01/2016) 04/02/2020...
  • Page 155 SERVICE MANUAL ADVANCE OVENS 20.3. ELECTRICAL CIRCUIT DIAGRAM FOR GAS OVEN (until 01/01/2016) 04/02/2020...
  • Page 156 SERVICE MANUAL ADVANCE OVENS 20.4. ELECTRICAL CIRCUIT DIAGRAM FOR GAS OVEN (from 01/01/2016) 04/02/2020...
  • Page 157 SERVICE MANUAL ADVANCE OVENS 20.5. ELECTRICAL DIAGRAMS LEGEND 04/02/2020...
  • Page 158 FAGOR INDUSTRIAL S. COOP. Santxolopetegi auzoa, 22 20560 Oñati, Gipuzkoa (Spain) Tel. (+34) 943 71 80 30 info@fagorindustrial.com www.fagorindustrial.com Service Manual...
