Inovance MD520 Series Commissioning Manual

General-purpose ac drive
Hide thumbs Also See for MD520 Series:
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MD520 Series and is the answer not in the manual?

Questions and answers

syah fares
February 18, 2025

could you please provide instruction on how to reset the inverter to its factory default setting

0
1 comments:
Mr. Anderson
May 14, 2025

To reset the Inovance MD520 Series inverter to factory default settings, set parameter FP-01 to one of the following values:

- Set FP-01 = 0: No action.
- Set FP-01 = 1: Restore parameters (excluding motor parameters and frequency reference) to factory settings.
- Set FP-01 = 503: Restore all parameters (including motor parameters) to factory settings, except FP-00, FP-01, and parameters in group FF.

This will reset the inverter according to the selected option.

This answer is automatically generated

0

Related Manuals for Inovance MD520 Series

Summary of Contents for Inovance MD520 Series

  • Page 2: Preface

    Preface About This Guide The MD520 series AC drive is a general‑purpose high‑performance current vector AC drive. It is designed to control and regulate the speed and torque of three‑phase AC asynchronous motors. It can be used to drive textile machines, paper making machines, wire drawing machines, machine tools, packaging machines, food machines, fans, water pumps, and other automated production equipment.
  • Page 3 U60.07/F7‑11= guide. 2024 U61.10/F7‑15= Deleted 4 Parameter List. ● 000.00/F7‑16=000.00 For complete information on parameters and fault codes, see MD520 Series General‑ Purpose AC Drive Parameter Guide. Version: A10 November Modified the following information: Version tag: F7‑10= 2023 Updated " 1.1 LED Operating Panel " on ●...
  • Page 4 Damage or secondary damage caused by force majeure (natural disaster, ● earthquake, and lightning strike) The maintenance fee is charged according to the latest Price List of Inovance. If otherwise agreed upon, the terms and conditions in the agreement shall prevail. For details, see the Product Warranty Card.

  • Page 5: Table Of Contents

    Table of Contents T T a a b b l l e e o o f f C C o o n n t t e e n n t t s s Preface ................1 Fundamental Safety Instructions .
  • Page 6 Table of Contents 2.2.22 (Optional) DO Settings ........... . 82 2.2.23 (Optional) Multi‑speed Reference Settings .

  • Page 7: Fundamental Safety Instructions

    Use this equipment according to the designated environment requirements. ● Damage caused by improper use is not covered by warranty. Inovance shall take no responsibility for any personal injuries or property damage ● caused by improper use. Safety Levels and Definitions Indicates that failure to comply with the notice will result in death or severe personal injuries.
  • Page 8 Fundamental Safety Instructions Unpacking Do not install the equipment if you find damage, rust, or signs of use on the equipment ● or accessories upon unpacking. Do not install the equipment if you find water seepage or missing or damaged ●...
  • Page 9 Fundamental Safety Instructions Handle the equipment with care during transportation and mind your steps to prevent ● personal injuries or equipment damage. When carrying the equipment with bare hands, hold the equipment casing firmly with ● care to prevent parts from falling. Failure to comply may result in personal injuries. Store and transport the equipment based on the storage and transportation ●...
  • Page 10 Fundamental Safety Instructions Cover the top of the equipment with a piece of cloth or paper during installation. This is ● to prevent unwanted objects such as metal chippings, oil, and water from falling into the equipment and causing faults. After installation, remove the cloth or paper on the top of the equipment to prevent over‑temperature caused by poor ventilation due to blocked ventilation holes.
  • Page 11 Fundamental Safety Instructions Before power‑on, check that the equipment is installed and wired properly and the ● motor can be restarted. Check that the power supply meets equipment requirements before power‑on to ● prevent equipment damage or a fire. After power‑on, do not open the cabinet door or protective cover of the equipment, ●...
  • Page 12 Fundamental Safety Instructions Perform routine and periodic inspection and maintenance on the equipment according ● to maintenance requirements and keep a maintenance record. Repair Equipment installation, wiring, maintenance, inspection, or parts replacement must be ● performed only by professionals. Do not repair the equipment with power ON. Failure to comply will result in an electric ●...
  • Page 13 Fundamental Safety Instructions Safety Label Description T12 Models T13 Models and Below Read through the safety instructions before operating the ● equipment. Failure to comply may result in death, personal injuries, or equipment damage. Do not touch the terminals or remove the cover with ●...

  • Page 14: Commissioning Tools

    Commissioning Tools Commissioning Tools LED Operating Panel Dimensions The following figures show the outline and installation dimensions of the LED operating panel. Figure 1‑1 Outline and installation dimensions of LED operating panel for T1 to T4 models (mm) Figure 1‑2 Outline and installation dimensions of LED operating panel for T5 to T12 models (mm) Components The LED operating panel can be used to view the operating status and fault...
  • Page 15 Commissioning Tools Figure 1‑3 Components Table 1–1 Description of the operating panel Description Name ‑ Status Indicator ① Secondary display area It displays the following information: ② Key test and auto‑tuning ● Fault and system status monitoring ● Station number, motoring status, and ●...
  • Page 16 Commissioning Tools Description Name Menu identification From left to right, the icons indicate the ⑧ basic menu, user‑defined parameter, modified parameter (with default values changed), and fault list. ‑ Program/Back key ⑨ ‑ Left shift key ⑩ ‑ OK key ⑪...
  • Page 17 Commissioning Tools Name Description Navigation key In the secondary display area, press the right or left navigation key to switch the display status. Primary display area: Basic menu, user menu, and calibration menu: On ● the monitoring interface, the down key is used as the potentiometer and the left and right keys are used to switch between monitored variables.
  • Page 18 Commissioning Tools Status indicator Table 1–3 Status indicator Status Indicator Description FWD indicator steady on The AC drive is running in the forward direction, or the reference direction is forward. REV indicator steady on The AC drive is running in the reverse direction, or the reference direction is reverse.
  • Page 19 Commissioning Tools Description Status Indicator DRIVE indicator steady on The station No. is displayed in the auxiliary display area. DRIVE indicator off The value displayed in the auxiliary display area is not the station No. AXIS indicator steady on The axis No. is displayed in the auxiliary display area.
  • Page 20 Commissioning Tools Description Status Indicator The primary display area displays the basic menu. Indicator steady The primary display area displays the user‑defined parameter menu. Indicator steady The primary display area displays the modified parameter (with the default Indicator steady value changed) menu. The primary display area displays the fault menu.
  • Page 21 Commissioning Tools Actual Actual Actual Actual Display Display Display Display Data Data Data Data ‑ ‑ ‑ ‑ ‑ ‑ ‑...

  • Page 22: Related Parameters

    Commissioning Tools Related Parameters Table 1–5 Parameters related to the operating panel Parameter Name Value Range Description rame fault Code F7‑01 MF.K key function 0: MF.K key disabled The MF.K key is a multi‑functional key. This 1: Forcibly change to operating parameter is used to set the function of the MF.K panel control key.
  • Page 23 Commissioning Tools Parameter Name Value Range Description rame fault Code F7‑03 Parameter 0x1F Bit 00: Running frequency (Hz) In the running state, you can view the 16 states of display 1 on LED Bit 01: Frequency reference the AC drive in real time by pressing the left or right operating panel (Hz) shift key on the LED operating panel.
  • Page 24 Commissioning Tools Parameter Name Value Range Description rame fault Code F7‑05 Parameter 0x0033 Bit 00: Frequency reference If a parameter needs to be displayed when the AC display at stop (Hz) drive stops, set its corresponding bit to 1. After Bit 01: Bus voltage (V) converting the binary number to a hexadecimal Bit 02: DI state...

  • Page 25: Parameter Settings

    Commissioning Tools Parameter Name Value Range Description rame fault Code FP‑02 Display of Bit 00: Group U This parameter is used to determine whether the function 0: Hidden parameter groups U, A, B, C, H, and L are displayed parameter groups 1: Displayed on the operating panel.
  • Page 26 Commissioning Tools Figure 1‑4 Modifying a parameter Press to return to a level‑2 menu when operating a level‑3 menu. The difference between the two keys is as follows: After you press , the system saves the parameter settings and then goes ●...

  • Page 27: Parameter View

    Commissioning Tools Parameter View Set FP‑02 to 11 and FP‑03 to 11 to view all parameters through the operating panel. The operation procedure is shown in the following figure. Figure 1‑5 Parameter view Display of Status Parameters The primary display area and the secondary display area are independent of each other and do not affect each other.
  • Page 28 Commissioning Tools Status interface: On the station number interface, press the left/right key to ● view the current device status. In this case, the DRIVE and AXIS indicators are both OFF, as shown below. The following states can be displayed: Reset (initializing): initializing after power‑on ■...

  • Page 29: Display Of Faults And Alarms

    Commissioning Tools different faults, whereas pressing the left/right key can switch among different menus. 2. Parameters in the primary display area When the AC drive is running, you can press to view status parameters. The status parameters displayed by default include running frequency, frequency reference, bus voltage, output voltage, and output current.
  • Page 30 In this case, see the parameter guide for troubleshooting or contact Inovance for technical support. Find the fault cause and rectify the fault based on the fault code displayed on the operating panel. Then reset the device.

  • Page 31: Driving The Motor With The Operating Panel

    Commissioning Tools Table 1–6 MF.K key parameter descriptions Parame Description Default Value Range rame ter Name Code F7‑01 MF.K key 0: MF.K key The MF.K key is a multi‑functional key. This function disabled parameter is used to set the function of the 1: Forcibly MF.K key.
  • Page 32 Commissioning Tools 1. Perform inspection before power‑on. Check the installation and wiring according to the installation guide. For detailed inspection, see the description of check operations before power‑on in the MD520 Series General‑Purpose AC Drive Installation Guide . 2. Press the power switch to power on the AC drive. 3.
  • Page 33 Commissioning Tools 6. Set motor parameters in group F1 according to the motor nameplate. ‑ ‑...
  • Page 34 Commissioning Tools Table 1–7 Motor parameters Parame Description Default Value Range rame ter Name Value Code F1‑00 Motor 0: Common A variable frequency motor can type asynchronous adjust its frequency and speed motor according to the load. When the 1: Variable voltage is low, the variable frequency frequency motor can reduce the...
  • Page 35 Commissioning Tools Parame Description Default Value Range rame ter Name Value Code F1‑03 0.01 A to Rated Model The rated motor current indicates 655.35 A (AC motor depend the current of the motor during drive power ≤ current normal operation, which usually 55 kW) refers to the line current.
  • Page 36 Commissioning Tools 9. Set F7‑01 to 4, and then press to enable the motor to jog reversely. 10. Press to start the motor. The motor shaft starts to rotate and accelerate, and the operating panel displays the current running frequency, as shown in the fol‑ lowing figure.

  • Page 37: Commissioning And Trial Run

    Commissioning and Trial Run Commissioning and Trial Run Commissioning Flowchart 2.1.1 Basic Commissioning Flowchart Figure 2‑1 Basic commissioning flowchart ‑ ‑...
  • Page 38 Commissioning and Trial Run Table 2–1 Basic commissioning flowchart Step Related Parameter Check before power‑on Power‑on Parameter initialization FP‑01 View the software version. F7‑10, F7‑11, F7‑15, F7‑16 Set motor parameters. F1‑00 to F1‑05 Note that you must set the motor type. Set encoder parameters.

  • Page 39: Commissioning Flowchart In V/F Control Mode

    Commissioning and Trial Run 2.1.2 Commissioning Flowchart in V/f Control Mode Figure 2‑2 Commissioning flowchart in V/f control mode ‑ ‑...

  • Page 40: Commissioning Flowchart In Svc/Fvc Control Mode

    Commissioning and Trial Run 2.1.3 Commissioning Flowchart in SVC/FVC Control Mode Figure 2‑3 Commissioning flowchart in SVC/FVC control mode ‑39‑...

  • Page 41: Commissioning Flowchart In Pmvvc Control Mode

    Commissioning and Trial Run 2.1.4 Commissioning Flowchart in PMVVC Control Mode Figure 2‑4 Commissioning flowchart in PMVVC control mode Commissioning Procedure 2.2.1 Inspection Before Power-on Check the following items before powering on the drive. ‑ ‑...

  • Page 42: Power-On

    Commissioning and Trial Run Table 2–2 Check items before power‑on Item Description Main circuit wiring The power supply voltage is correct (380–480 VAC; 50/60 Hz). The power supply input terminals and the AC drive input terminals (R/S/T) are connected properly. The motor input terminals and the AC drive output terminals (U/V/W) are connected properly.
  • Page 43 Commissioning and Trial Run Figure 2‑5 Display on the operating panel upon power‑on ‑ ‑...

  • Page 44: Parameter Initialization

    Commissioning and Trial Run 2.2.3 Parameter Initialization Parame Parame Value Range Description fault Code Name This parameter is used to set the action upon parameter initialization of the AC drive. 0: No operation The AC drive does not perform any operation. 1: Restore parameters (excluding motor parameters) to factory settings 0: No action...

  • Page 45: Motor Parameter Settings

    Commissioning and Trial Run 2.2.5 Motor Parameter Settings Parame Parameter Value Range Description Name Code 0: Common A variable frequency motor can adjust its frequency and speed according asynchronous to the load. When the voltage is low, it can reduce the frequency and start motor reliably.
  • Page 46 Commissioning and Trial Run Parame Parameter Value Range Description Name Code The leakage inductance of the asynchronous motor is caused by the 0.01 mH to Leakage leakage flux of motor winding. In the winding of the motor, when current 655.35mH (power ≤ inductive is introduced, magnetic flux will be generated.

  • Page 47: Motor Parameter Auto-Tuning

    Commissioning and Trial Run Parame Parameter Value Range Description Name Code Encoders are classified into incremental encoders and absolute encoders. An incremental encoder converts displacement into periodic electrical ● 0: ABZ incremental signals, which are then converted into pulses that are counted. That is, encoder the magnitude of displacement is expressed as the number of pulses.

  • Page 48: Command Source Settings

    Commissioning and Trial Run Parame Parame Default Value Range Description ter Code Name F1‑37 Auto‑ 0: No auto‑tuning 0: No operation tuning 1: Asynchronous Auto‑tuning is not performed. mode motor static auto‑ 1: Static auto‑tuning on partial parameters of asynchronous tuning motor 2: Dynamic auto‑...
  • Page 49 Commissioning and Trial Run Parame Parameter Default Value Range Description Name Code F0‑02 Operation 0: Operating It is used to determine the input channel of the AC drive control command panel commands, such as run, stop, forward run, reverse run, and jog source 1: Terminal operation.

  • Page 50: Frequency Source Settings

    Commissioning and Trial Run 2.2.8 Frequency Source Settings Parame Parameter Default Value Range Description Name Code F0‑03 Main 0: Digital setting 0: Digital setting (non‑retentive upon power failure) frequency (non‑retentive The initial value of the frequency is the value of F0‑08 (Preset source X upon power frequency).
  • Page 51 Commissioning and Trial Run Parame Parameter Default Value Range Description Name Code Contin Continued Contin Continued Continued 7: Simple PLC Simple PLC is a multi‑reference used to control the running time and acceleration/deceleration time. Parameters FC‑00 to FC‑15 are used to set the values of each frequency. FC‑18 to FC‑49 are used to set the running time and acceleration and deceleration time of each frequency.

  • Page 52: Control Mode Settings

    Commissioning and Trial Run 2.2.9 Control Mode Settings Parame Parameter Default Value Range Description Name Code 0: Sensorless vector control (SVC) It is an open‑loop vector control mode, which is applicable to high‑performance control applications. In this case, one AC drive can drive only one motor. This mode applies to such loads as machine tools, centrifuges, wire drawing machines, and injection molding machines.

  • Page 53: Optional) V/F Parameter Settings

    Commissioning and Trial Run 2.2.10(Optional) V/f Parameter Settings Param Parameter Default Value Range Description eter Name Code 0: Linear V/f curve The output voltage changes linearly with the output frequency when the frequency is lower than the rated frequency. This curve applies to general mechanical transmission applications such as acceleration of high‑inertia fans, punch presses, centrifuges, and water pumps.

  • Page 54: Optional) Svc Parameters Settings

    Commissioning and Trial Run 2.2.11(Optional) SVC Parameters Settings Param Parameter Value Default Parameter Code eter Name Range Code F2‑00 Speed loop 1–300 Asynchronous This is the PID control parameter Kp for the speed loop, which proportional motor: 30 affects the response to the motor speed. A larger Kp value gain 1 Synchronous indicates higher adjustment sensitivity and adjustment intensity.

  • Page 55: Optional) Fvc Parameter Settings

    Commissioning and Trial Run Param Parameter Value Default Parameter Code eter Name Range Code F2‑05 Switchover F2‑02 to 10.00 Hz The speed loop PI parameters are divided into low‑speed and frequency 2 F0‑10 high‑speed groups. If the running frequency is lower than F2‑02 (switching frequency 1), the speed loop PI adjustment parameters are F2‑00 and F2‑01.
  • Page 56 Commissioning and Trial Run Parame Parameter Name Value Range Default Parameter Code Code F2‑00 Speed loop 1–300 Asynchro This is the PID control parameter Kp for the speed loop, proportional gain 1 nous motor: which affects the response to the motor speed. A larger Kp value indicates higher adjustment sensitivity and Synchro adjustment intensity.
  • Page 57 Commissioning and Trial Run Parame Parameter Name Value Range Default Parameter Code Code F2‑05 Switching F2‑02 to F0‑10 10.00 Hz The speed loop PI parameters are divided into low‑speed frequency 2 and high‑speed groups. If the running frequency is lower than F2‑02 (switching frequency 1), the speed loop PI adjustment parameters are F2‑00 and F2‑01.

  • Page 58: Optional) Pmvvc Parameters Settings

    Commissioning and Trial Run 2.2.13(Optional) PMVVC Parameters Settings Parame Parameter Value Range Default Description Name Code F0‑01 Motor 1 0: SVC 0: Sensorless vector control (SVC) control 1: FVC It is an open‑loop vector control mode, which is applicable mode 2: V/f to high‑performance control applications.
  • Page 59 Commissioning and Trial Run Parame Parameter Value Range Default Description Name Code F1‑37 Auto‑tuning 0: No operation ‑ mode 1: Static auto‑tuning on partial parameters of asynchronous motor 2: Dynamic auto‑tuning of asynchronous motor 3: Static auto‑tuning on all parameters of asynchronous motor 4: Inertia auto‑tuning 5: Dead zone auto‑...

  • Page 60: Acceleration/Deceleration Time Settings

    Commissioning and Trial Run 2.2.14Acceleration/Deceleration Time Settings Parame Parameter Default Value Range Description Name Code 0.0s to 6500.0s This parameter indicates the time required for the output frequency to increase from 0 to the base frequency for acceleration/deceleration time (F0‑25). When the motor accelerates, the rising rate of the frequency reference Accelera F0‑17...

  • Page 61: Optional) Startup Mode Settings

    Commissioning and Trial Run 2.2.15(Optional) Startup Mode Settings Parame Parameter Default Value Range Description Name Code F6‑00 Startup mode 0: Direct start 0: Direct start 1: Flying start This mode is applicable to most load conditions. Startup with 2: Vector pre‑ the startup frequency is applicable to load hoisting excited start (AC applications such as elevators and cranes.

  • Page 62: Optional) Startup Frequency Settings

    Commissioning and Trial Run 2.2.16(Optional) Startup Frequency Settings Parame Parameter Default Value Range Description Name Code 0.00 Hz This parameter defines the startup frequency for direct start Startup of the AC drive. When the startup frequency is higher than the F6‑03 0.00 Hz to 10.00 Hz frequency...

  • Page 63: Stop Parameter Settings

    Commissioning and Trial Run 2.2.18Stop Parameter Settings Param Parameter Name Value Range Default Parameter Code eter Code F6‑10 Stop mode 0: Decelerate 0: Decelerate to stop to stop After the stop command becomes active, the AC drive 1: Coast to decreases the output frequency based on the deceleration stop time, and stops when the frequency is reduced to 0.
  • Page 64 Commissioning and Trial Run Table 2–3 Descriptions of DIP switches S1 to S3 DIP Switch DIP Switch Status Function Diagram Voltage mode with the range of 0 VDC to 10 VDC for AI2 Temperature mode for AI2 Set the temperature sensor type through F9‑75.
  • Page 65 Commissioning and Trial Run Table 2–4 Related parameters Param Parameter Value Default Description eter Name Code F4‑13 Minimum ‑10.00 V to F4‑15 0.00 V These parameters define AI curve 1. F4‑13 and F4‑15 input of AI are interlocked. curve 1 F4‑14 Percentage ‑100.0% to +100.0%...
  • Page 66 Commissioning and Trial Run Param Parameter Value Default Description eter Name Code F4‑23 Minimum ‑10.00 V to F4‑25 ‑10.00 V These parameters define AI curve 3. F4‑23 and F4‑25 input of AI are interlocked. curve 3 F4‑24 Percentage ‑100.0% to +100.0% ‑100.0% corresponding to minimum...
  • Page 67 Commissioning and Trial Run Param Parameter Value Default Description eter Name Code F4‑33 AI curve Ones position: AI1 curve The ones to hundreds positions of this parameter are selection selection used to select curves for terminal AIx (x is 1 to 3). 1: Curve 1 (2 points, see F4‑13 to F4‑16) 2: Curve 2 (2 points, see...
  • Page 68 Commissioning and Trial Run Param Parameter Value Default Description eter Name Code A6‑00 Minimum ‑10.00 V to A6‑02 0.00 V These parameters define AI curve 4. A6‑00 and A6‑02, input of AI A6‑04 and A6‑06 are interlocked. curve 4 A6‑01 Percentage ‑100.0% to +100.0% 0.0%...
  • Page 69 Commissioning and Trial Run Param Parameter Value Default Description eter Name Code A6‑08 Minimum ‑10.00 V to A6‑10 ‑10.00 V These parameters define AI curve 5. A6‑08 and A6‑10, input of AI A6‑12 and A6‑14 are interlocked. curve 5 A6‑09 Percentage ‑100.0% to +100.0% ‑100.0%...
  • Page 70 Commissioning and Trial Run Param Parameter Value Default Description eter Name Code A6‑28 AI3 jump point ‑100.0% to +100.0% 0.0% This parameter defines the AI3 jump point. If the input is within the range from A6‑28 ‑ A6‑29 to A6‑28 + A6‑29, the value of the AI3 jump point (A6‑28) will be output.
  • Page 71 Commissioning and Trial Run Param Parameter Value Default Description eter Name Code A6‑34 AI polarity Ones position: AI1 ‑ selection 0: Normal value 1: Absolute value 2: Opposite to the normal value 3: Opposite to the absolute value Tens position: AI2 0: Normal value 1: Absolute value 2: Opposite to the...
  • Page 72 Commissioning and Trial Run Param Parameter Value Default Description eter Name Code A6‑40 Low level 1.0 V to 4.5 V 3.0 V This parameter defines the threshold for judging low judgment level when the AI is used as the DI. threshold when AI uses as DI...

  • Page 73: Optional) Ao Settings

    Commissioning and Trial Run 2.2.20(Optional) AO Settings Parameter Parameter Name Default Value Range Description Code AO1 output function 0: Running frequency See below. F5‑07 selection 1: Frequency reference 2: Output current 3: Output torque (absolute value) 4: Output power 5: Output voltage 6: Pulse input 7: AI1 8: AI2...
  • Page 74 Commissioning and Trial Run Value Function Range Count value 0 to maximum count value. The value 100% corresponds to FB‑08. Communication setting 0.0% to 100.0%. The value 100% corresponds to AO communication setting. Motor speed 0 to speed corresponding to the maximum output frequency. The value 100.0% corresponds to the maximum frequency (F0‑10).

  • Page 75: Optional) Di Settings

    Commissioning and Trial Run 2.2.21(Optional) DI Settings Parame Parameter Name Default Value Range Description Code F4‑00 DI1 function 0: No function 28: Length reset selection 1: Forward run (IN1) 29: Torque control inhibited descrip 2: Reverse run (IN2) 30: Pulse frequency input tions F4‑01 DI2 function...
  • Page 76 Commissioning and Trial Run Parame Parameter Name Default Value Range Description Code Contin Continued Contin Continued Continued 70: Control channel selection 76: Motor selection terminal 2 71: Setting channel selection 77: Running permission (reserved) 78: Forward running permission 72: Terminal module A/B 79: Reverse running permission selection 80: Set RFG input to zero...
  • Page 77 Commissioning and Trial Run 6: Function as UP key for frequency adjustment The terminal is used to increase the frequency when the frequency is set through the terminal. Activating the terminal is equivalent to pressing and holding the increment key. Deactivating the terminal is equivalent to releasing the increment key. 7: Function as DOWN key for frequency adjustment The terminal is used to decrease the frequency when the frequency is set through the terminal.
  • Page 78 Commissioning and Trial Run 19: Clear data set by UP/DOWN key or by terminal functioning as UP/DOWN key When the main frequency is set through the operating panel, activating the terminal clears the frequency that is set by the increment or decrement key on the operating panel or the terminal functioning as UP/DOWN keys and resumes the frequency reference to the value specified by F0‑08.
  • Page 79 Commissioning and Trial Run 32: Immediate DC braking The terminal is used to switch the drive to the DC braking state. DC braking means the drive outputs direct current to the stator winding of the asynchronous motor to form a static magnetic field, enabling the motor to brake with energy consumption. In this state, the rotor cuts the static magnetic field to generate braking torque, which stops the motor quickly.
  • Page 80 Commissioning and Trial Run 2 applies when DI1 is active and DI2 is inactive; motor 3 applies when DI1 is inactive and DI2 is active; motor 4 applies when DI1 and DI2 are both active. 42: Reserved 43: PID parameter switchover If the PID parameter switchover condition is set to "Switchover by DI"...
  • Page 81 Commissioning and Trial Run 49: Decelerate to DC braking The terminal is used to make the AC drive decelerate to the start frequency of DC braking for stop (F6‑11) and then enter the DC braking state. 50: Clear the current running time The terminal is used to clear the current running time of the drive.
  • Page 82 Commissioning and Trial Run 70: Control channel selection The terminal is used to select one of two user‑defined command channels. Value 0 represents channel 1, and value 1 represents channel 2. 71: Setting channel selection (reserved) 72: Terminal module A/B selection The terminal is used to select one of two terminal modules.

  • Page 83: Optional) Do Settings

    Commissioning and Trial Run 2.2.22(Optional) DO Settings Parame Parameter Name Default Value Range Description ter Code F5‑04 DO1 output 0: No output 23: Running 2 at zero speed See below. function selection 1: AC drive in operation (output at stop) 2: Fault output 24: Cumulative power‑on time F5‑05...
  • Page 84 Commissioning and Trial Run 3: Frequency level detection FDT1 output The terminal outputs an active signal when the running frequency exceeds the frequency detection value. It stops outputting the active signal when the running frequency falls below the result of the detection value minus the FDT hysteresis (F8‑19 x F8‑20).
  • Page 85 Commissioning and Trial Run In a wobble process, the terminal outputs an active signal when the set frequency exceeds the upper or lower limit of the frequency and the output frequency reaches the upper or lower limit of the frequency. 14: Torque limited The terminal outputs an active signal when the output torque of the AC drive reaches the toque limit in the speed control mode.
  • Page 86 Commissioning and Trial Run The terminal outputs an active signal when the running frequency exceeds the frequency detection value and stops outputting the active signal when the running frequency is lower than the result of the detection value minus the frequency detection hysteresis (F8‑28 x F8‑29).
  • Page 87 Commissioning and Trial Run When the output current of the drive is within the zero current range for a duration longer than that defined by F8‑35 (zero current detection delay), the terminal outputs an active signal. Zero current detection range: 0 to F8‑34 x F1‑03 35: Module temperature reached The terminal outputs an active signal when the drive unit heatsink temperature (F7‑...

  • Page 88: Optional) Multi-Speed Reference Settings

    Commissioning and Trial Run 2.2.23(Optional) Multi-speed Reference Settings Parameter Parameter Default Value Range Description Code Name FC‑00 Multi‑ 0.0% ‑100.0% to These parameter indicates the frequency reference of each reference 0 +100.0% speed. FC‑00 to FC‑15 correspond to a total of 16 frequency setpoints, which are percentages of the maximum frequency.

  • Page 89: Optional) Relay Output Settings

    Commissioning and Trial Run 2.2.24(Optional) Relay Output Settings Parameter Name Value Range Description rame fault Code F5‑02 Output function selection 0: No output of control panel relay 1: AC drive in operation 24: Cumulative power‑on 2: Fault output time reached F5‑03 Output function selection 3: Frequency level detection 25: Frequency level detection...
  • Page 90 Commissioning and Trial Run 2: Fault output The terminal outputs an active signal when the AC drive stops due to a fault. 3: Frequency level detection FDT1 output The terminal outputs an active signal when the running frequency exceeds the frequency detection value.
  • Page 91 Commissioning and Trial Run 13: Wobble frequency limited In a wobble process, the terminal outputs an active signal when the set frequency exceeds the upper or lower limit of the frequency and the output frequency reaches the upper or lower limit of the frequency. 14: Torque limited The terminal outputs an active signal when the output torque of the AC drive reaches the toque limit in the speed control mode.
  • Page 92 Commissioning and Trial Run The terminal outputs an active signal when the running frequency exceeds the frequency detection value and stops outputting the active signal when the running frequency is lower than the result of the detection value minus the frequency detection hysteresis (F8‑28 x F8‑29).
  • Page 93 Commissioning and Trial Run When the output current of the drive is within the zero current range for a duration longer than that defined by F8‑35 (zero current detection delay), the terminal outputs an active signal. Zero current detection range: 0 to F8‑34 x F1‑03 35: Module temperature reached The terminal outputs an active signal when the drive unit heatsink temperature (F7‑...

  • Page 94: Function Commissioning

    Commissioning and Trial Run Function Commissioning 2.3.1 PMVVC Function Commissioning (for Synchronous Motors Only) Commissioning flowchart Figure 2‑6 PMVVC control mode commissioning flowchart ‑93‑...
  • Page 95 Commissioning and Trial Run Commissioning procedure 1. Set F0‑01 (control mode) to 2 (V/f control). Set F1‑00 (motor type) to 2 (permanent magnet synchronous motor). 2. Set the motor‑related parameters F1‑01 to F1‑05. 3. Set F1‑37 (auto‑tuning selection) to 12 (no‑load dynamic auto‑tuning) or 11 (static auto‑tuning).
  • Page 96 Commissioning and Trial Run Parame Parameter Default Value Range Set Value Name Code F1‑05 1 RPM to 65535 RPM Rated motor Model Model dependent speed dependent F1‑37 Auto‑tuning 0: No operation mode 1: Static auto‑tuning on partial parameters of asynchronous motor 2: Dynamic auto‑tuning of asynchronous motor 3: Static auto‑tuning on all...

  • Page 97: Troubleshooting

    Figure 3‑1 Display of faults Do not repair or modify the AC drive by yourself. In case of any fault that cannot be rectified, contact the agent or Inovance for technical support. 3.1.2 Start After Fault Occurrence View the current fault code, fault subcode, fault information, minor fault code, minor fault subcode, minor fault information, warning code, warning subcode, warning information through the operating panel.
  • Page 98 Troubleshooting Table 3–1 Fault view and start method after fault occurrence Stage Solution Description In faulty status Fault record 1: View the current fault code, View the record through H0‑00 to H0‑53. fault subcode, fault information, minor fault code, minor fault subcode, minor fault information, warning code, warning subcode, warning information through the operating panel.
  • Page 99 Troubleshooting Stage Solution Description Reset mode to 1. Set any of F4‑00 to F4‑09 to 9 (fault reset). clear faults 2. Verify that F7‑02 is set to 1 (default value), Press the STOP/RES key on the operating panel. indicating that the STOP/RES key is available in any operating mode.

  • Page 100: Common Troubleshooting

    Re‑connect the 8‑pin and 40‑pin disconnected from the flat cables. driver board and operating panel. The pre‑charge resistor Contact the agent or Inovance for of the AC drive is technical support. damaged. The control board or the operating panel is faulty.
  • Page 101 Replace the fan or clean the air frequently. damaged, or the air duct duct. is blocked. Devices (thermistor or Contact the agent or Inovance for other devices) inside the technical support. AC drive are damaged. The motor does The wiring between the...
  • Page 102 The jumper between OP Secure the jumper between OP and +24 V becomes and +24V. loose. The control board is Contact the agent or Inovance for faulty. technical support. The motor speed The encoder is faulty. Replace the encoder disk and...

  • Page 103: Troubleshooting Of Trial Run In Different Control Modes

    Troubleshooting 3.1.4 Troubleshooting of Trial Run in Different Control Modes SVC mode (F0‑01= 0 (default)) ● In this mode, the drive controls the motor speed and torque without an encoder for speed feedback. Auto‑tuning on motor parameters is required to obtain the motor parameters.
  • Page 104 Troubleshooting Table 3–4 Troubleshooting in FVC mode Problem Solution Overload or overcurrent Set the encoder resolution (PPR), encoder type and encoder fault detected during direction correctly. startup Overload or overcurrent is Set motor parameters F1‑01 to F1‑05 according to the motor detected during motor nameplate.

  • Page 105: List Of Faults And Alarms

    (F3‑18, default: 150%) properly by the step value of 10%. The permissible minimum value is 50%. List of Faults and Alarms For complete information on fault and alarm codes, see MD520 Series General‑ Purpose AC Drive Parameter Guide. ‑ ‑...
  • Page 106 *19011715B01*...

Table of Contents

Save PDF
