UM-WI-056
DA16200 DA16600 FreeRTOS Getting Started Guide
ENCRYPTION ?
1. TKIP (CAUTION: Unsupported 802.11N Mode)
2. AES(CCMP)
3. TKIP/AES(CCMP)
ENCRYPTION ? [1/2/3/Quit] : 2
PSK-KEY(ASCII characters 8~63 or Hexadecimal characters 64) ? [Quit]
[123456789|123456789|123456789|123456789|123456789|123456789|1234]
:**********
Do you want to set advanced WiFi configuration ? [No/Yes/Quit] (Default No) :
============================================
SSID : TEST AP
CHANNEL : AUTO(ACS)
AUTH : WPA2
ENCRYPTION: AES(CCMP)
PSK KEY : 123abc456
KEY TYPE : ASCII
WIFI MODE : 11b/g/n
============================================
WIFI CONFIGURATION CONFIRM ? [Yes/No/Quit] : Y
IP ADDRESS ? [Quit] (Default 10.0.0.1) :
SUBNET ? [Quit] (Default 255.255.255.0) :
GATEWAY ? [Quit] (Default 10.0.0.1) :
============================================
[WLAN1]
IP ADDRESS: 10.0.0.1
SUBNET : 255.255.255.0
GATEWAY : 10.0.0.1
============================================
IP CONFIGURATION CONFIRM ? [Yes/No/Quit] : Y
DHCP SERVER CONFIGURATION ? [Yes/No/Quit] : Y
DHCP SERVER LEASE IP Count(MAX 10) ? [Quit] (Default 10) :
DHCP SERVER LEASE TIME(60 ~ 86400 SEC) ? [Quit] (Default 1800) :
============================================
[DHCP SERVER]
Start IP : 10.0.0.2
END IP : 10.0.0.11
LEASE TIME: 1800
============================================
DHCP SERVER CONFIGURATION CONFIRM ? [Yes/No/Quit] : Y
Configuration OK
. done
Once all settings are made, the configuration is saved, and the system reboots. A message is printed
that Soft AP mode started successfully:
Reboot...
Wakeup source is 0x0
[dpm_init_retmemory] DPM INIT CONFIGURATION(1)
******************************************************
* DA16200 SDK Information
* ---------------------------------------------------
*
* - CPU Type
* - OS Type
* - Serial Flash
* - SDK Version
* - F/W Version
* - F/W Build Time : Aug 26 2021 22:58:01
* - Boot Index
User Manual
CFR0012
Enter 2 to select AES encryption.
Enter the password for the AP.
Enter N to skip this step.
Enter Y to confirm the WIFI
configuration.
Enter to select the default IP Address.
Enter to select the default Subnet.
Enter to select the default Gateway.
Enter Y to confirm the IP configuration.
Enter Y to confirm the DHCP Server
configuration.
Enter to select the default Lease Count.
Enter to select the default Lease Time.
: Cortex-M4 (120 MHz)
: FreeRTOS 10.4.3
: 4 MB
: V3.1.3.0 GEN
: FRTOS-GEN01-01-15129-000000
: 0
Revision 1.9
27 of 108
N
Enter Y to confirm the configuration.
