Kohler PANACHE K-22106T-2 Installation Instructions Manual

·
Please read these instructions carefully to familiarize
yourself with the required tools, materials, and installation
sequences. Follow the sections that pertain to your
particular installation. This will help you avoid costly
mistakes. In addition to proper installation, read all
operating and safety instructions.
·
All information in these instructions is based upon the
latest product information available at the time of
publication. Kohler China reserves the right to make
changes in product characteristics, packaging, or
availability at any time without notice.
·
These instructions contain important care, cleaning, and
warranty information - please leave instructions for the
consumer .
ORDERING INFORMATION
PANACHE WF Toilet (HT100 MEC IWT) ..............K-22106T-2
Includes PANACHE Bowl ................................K-18154T-2
Includes ODEON Inwall Tank
W/O Iron Rack................................K-6286T-PN2
Includes PANACHE Toilet Seat
®
Includes P-Trap ....................................................1036901
PANACHE WF Toilet (HT100 MEC IWT)............K-22106T-S2
Includes PANACHE Bowl ................................K-18154T-2
Includes ODEON Inwall Tank
W/O Iron Rack .............................K-6286T-PNS2
Includes PANACHE Quiet-close Toilet Seat
®
Includes P-Trap ....................................................1036901
NOTES
·
Observe all local plumbing and building codes.
·
Shut off the water supply.
·
51mm (2") passageway.
·
Ensure that the new drain has the correct roughing-in
dimension.
·
Carefully inspect the new fixture for any sign of damage.
·
For new construction, refer to the dimensions in
for locating the shut-off valve.
·
Fixture dimensions are nominal and conform to tolerances
established by ASME Standards (A112.19.2-2013).
·
This product complies with GB 25502-2017. Water
Efficiency Grade 2.
