Please read these instructions carefully to familiarize
yourself with the required tools, materials, and installation
sequences. Follow the sections that pertain to your
particular installation. This will help you avoid costly
mistakes. In addition to proper installation, read all
operating and safety instructions.
·
All information in these instructions is based upon the
latest product information available at the time of
publication. Kohler China reserves the right to make
changes in product characteristics, packaging, or
availability at any time without notice.
·
These instructions contain important care, cleaning, and
warranty information -
consumer
.
ORDERING INFORMATION
HARKEN 2PC Toilet 305mm W/ QC Seat.............K-22696T-S
Includes HARKEN 2PC Bowl 305mm ................K-22698T
Includes HARKEN 2PC Tank 305mm ........K-22699T-ST3
Includes HARKEN QC Seat ...............................K-22697T
HARKEN 2PC Toilet 400mm W/ QC Seat.............K-20826T-S
Includes HARKEN 2PC Bowl 400mm ................K-20827T
Includes HARKEN 2PC Tank 400mm ........K-22699T-ST4
Includes HARKEN QC Seat ...............................K-22697T
NOTES
·
Observe all local plumbing and building codes.
·
Shut off the water supply.
·
Seat post holes are on 140mm centers.
·
Ensure that the new drain has the correct roughing-in
dimension. This toilet has a 305/400mm roughing-in
dimension.
See Roughing-in
·
Closet flange must be 305/400mm on-center from wall.
·
Carefully inspect the new fixture for any sign of damage.
·
For new construction, refer to the dimensions in
installation step
for locating the shut-off valve.
·
Fixture dimensions are nominal and conform to tolerances
established by ASME Standards (A112.19.2-2018).
·
This product complies with GB25502-2017. Water
Efficiency Grade 1.
