- Page 1 MULTIPLE MULTIPLE MOWER - MOWER - Operation and Maintenance Manual Designed for the maintenance of green areas TRANSLATED INSTRUCTIONS 903280002~01 03/2022...
- Page 2 WGM Mower...
-
Page 3: Table Of Contents
2.14 LOCATION OF PICTOGRAMS ON THE MACHINE 2.15 SAFETY PRESCRIPTIONS 3 WGM MOWER UNLOADING AND UNPACKING 3.1 WGM MOWER PROTECTED BY HEAT SHRINK 3.2 THE WGM MOWER IN THE WOODEN CRATE 4 TECHNICAL SPECIFICATIONS 5. START-UP 5.1 WGM MOWER CENTRAL BODY ASSEMBLY 5.2 ASSEMBLING THE SIDE MOWER... - Page 4 9. ROUTINE MAINTENANCE 9.1 CHECKING AND REPLACING THE OIL IN THE GEARBOX UNIT 9.2 BLADE CHECK AND REPLACEMENT 9.3 REPLACING THE TRANSMISSION BELTS 10 GREASINGS 10.1 WGM MOWER SUPPORTS GREASING 10.2 CARDAN SHAFT 11 CLEANING 12 STORAGE AND WINTERING 13 SCRAPPING...
-
Page 5: Introduction
• deliver it to any new operator, user, maintenance technician, handler or owner (in case of change of ownership); In this way the WGM Mower can be used in the best way possible for all the functions for which it was designed and with maximum safety. -
Page 6: Declaration Of Conformity
CE DECLARATION OF CONFORMITY in accordance with Directive 2006/42/EC The company: Sicma S.p.a. - C.da Cerreto, 39 - 66010 Miglianico (Ch) - Italy Tel.: +39 0871 95841 - Fax: +39 0871 950295 e-mail: info@sicma.it - http://www.sicma.it declares under its own responsibility that the machine:... -
Page 7: General Delivery Notes
MULTIPLE MULTIPLE MOWER - MOWER - containers. In the event of damage or missing parts immediately inform SICMA or its Operation and Maintenance Manual local representatives, the carrier or its insurance agent, providing details and/or photos. The WGM Mower is delivered by SICMA fitted with the following equipment: 1 - PTO DRIVE SHAFT;... -
Page 8: Wgm Mower Identification And Manual Code
Write the number in a different safe place so that if this manual is lost or damaged, another copy can be requested from SICMA or from the nearest dealer by also stating the serial number visible in the marking. -
Page 9: Wgm Mower Main Parts
1.5 WGM MOWER MAIN PARTS Description Description Drawbar Left mower Cardan Joint Rear Mower Parking foot Adjustable wheels Central body Three-output unit Secondary cardan joints Right mower WGM Mower... -
Page 10: Safety
2.2 LIST OF RESIDUAL RISKS As SICMA has complied with all the directives, laws and regulations in force and has done everything possible to ensure the WGM Mower remains in line with the state of the art in terms of safety, there still exist, albeit only a few, residual risks: •... -
Page 11: Definitions
The critical area is that between the tractor and the equipment (PTO drive shaft area). ZERO ENERGY STATE The state to which the WGM Mower must be brought before performing any cleaning, lubrication and maintenance operation. The WGM Mower is at ZERO ENERGY STATE when it is positioned on level ground, disconnected from the cardan shaft and resting on its parking feet. -
Page 12: Operator Requisites
Personnel should use safety equipment and personal protective equipment during use and maintenance of the vehicle. The correct clothing to be worn during maintenance operations and during use of the WGM Mower is: • Gloves; • Overalls with elasticated wrists, ankles and waist;... -
Page 13: Intended Use
Any use different to that declared is to be considered improper. 2.12 REASONABLY PREDICTABLE INCORRECT USE It is possible that the operator could use the WGM Mower incorrectly. The incorrect methods of use are listed below. The operator must not: •... -
Page 14: Safety Devices
Ensure the good condition of the safety pictograms. If pictograms are damaged, they must be replaced with other original ones requested from the manufacturer and placed in the position indicated by the user and maintenance manual. 2.14 LOCATION OF PICTOGRAMS ON THE MACHINE WGM Mower... -
Page 15: Safety Prescriptions
Do not climb onto or sit on the machine CAUTION 4781043 Avoid pressurised fluid leaks. Consult Qt. 1 the technical manual for maintenance procedures. 4781721 Retro-reflector Qt. 2 HOOKING POINT 4781031 Qt. 2 Fixing point for lifting the machine. 5782832 Triangular retro-reflector Qt. 1 WGM Mower... - Page 16 Retro-reflector. Q.ty 2 GREASE 4781009 Indication for injection of lubri- Q.ty 4 cating grease. USE ONLY ENI LUBRICANTS For the hydraulic system: 4781093 oil ISO 46-68; For gears: Q.ty 1 oil 80W90; For greasing: LITHIUM grease EP -2 WGM Mower...
-
Page 17: Wgm Mower Unloading And Unpacking
ATTENTION DANGER OF SWINGING AND CRUSHING!! • Lift the WGM Mower from the walkable surface of the means of transport to a maximum height of 30 cm, unless in the case of obstacles, so that it does not swing. -
Page 18: The Wgm Mower In The Wooden Crate
• Wear protective gloves and disassemble the wooden packaging with a dedicated tool; To move the WGM Mower, use a forklift with a capacity suitable for its weight chap. 4 ("TECHNICAL SPECIFICATIONS"). After securing the WGM Mower with ropes or chains, lift the equipment a few centimetres to check that it is correctly harnessed. -
Page 19: Technical Specifications
4 TECHNICAL SPECIFICATIONS Below is the table with the technical characteristics of the WGM Mower. MODEL WGM 48-48-60 WGM 60-60-72 WGM 72-72-72 WGM 84-84-84 TRANSPORT LENGTH (mm) 2300 (7 ft. 6 in.) 2500 (8 ft. 2 in.) 2650 (8 ft. 8 in.) 2900 (9 ft.6 in.) -
Page 20: Start-Up
The WGM Mower can only be moved if connected to the tractor. The operator and any assistants must have PPE (Personal Protection Equipment) available and use it as required. -
Page 21: Assembling The Side Mower
"POSITIONING OF HOLES ON SQUARE TUBES"; • Refit and tighten the bolts according to the "TIGHTENING TORQUES" table in Chap.15; • Connect the cardan joints (5). POSITION OF HOLES ON SQUARE TUBES GROUP 4860 6072 7272 8484 SIDE REAR WGM Mower... -
Page 22: Assembling The Rear Mower
5.4 MAIN CARDAN ENGAGEMENT (HOMOKINETIC) • Unscrew the knobs (9); • Push behind the protection (10); • Insert the cardan shaft (11) from the single joint side; • Reposition the protection (10); • Screw the knobs (9) back on; WGM Mower... -
Page 23: Connecting The Wgm Mower To The Tractor
5.5 CONNECTING THE WGM MOWER TO THE TRACTOR The SICMA multiple mowers are built to be associated with any tractor equipped with a dedicated tow bar and quick-connect hydraulic utilities. The machine can be connected to a tractor with a power take-off operated at 540 rpm and of suitable weight and power. -
Page 24: Cardan Shaft Connection
AX4 810 tractor stamped on the external protection pipe. • Insert the first hub of the drive shaft on the PTO of the WGM Mower while pressing the pin or safety collar of the fork; • Release it and reverse with the drive shaft until it engages with an audible “click”... -
Page 25: Road Transport
Articles 61 and 104 of the Highway Code prescribe that the maximum width of vehicles on roads is 2.55 metres. Consequently, of the 4 available sizes of the RG-BIO, only the first two sizes (WGM 48-48-60 and WGM 60-60-72 which have a maximum size of 2.30 and 2.50m) are authorised for road transport , in compliance with the other provisions of the Highway Code. -
Page 26: Adjustments
The multiple mower has three mower bodies and all bodies must be set at the same height to obtain an even mow. The working height of the mower bodies is determined by the position of the four wheels (6) of each individual mower. WGM Mower... -
Page 27: Adjusting The Belt Tension
Then perform the reverse procedure for reassembly. ATTENTION!! Never operate the WGM Mower without first repositioning all the protections in their original places. ATTENTION!! It is absolutely forbidden to engage the power take-off with the mower bodies raised. -
Page 28: Working
Make sure that there are no ties to prevent movement. NOTE!! Before using the WGM Mower, read this entire sequence in order to be prepared in time for any eventuality. It is good practice to start the equipment in reduced normal conditions especially in cold environments, to allow the system to run-in and to prevent equipment malfunctioning. -
Page 29: Stops
TRANSPORT"); • Climb onto the tractor and release the hand brake; • Start the tractor; • Bring the WGM Mower into the warehouse, ensuring when handling that there are no persons, animals or objects exposed to danger; WARNING!! Check that the access lanes of the places where the machinery is kept comply with the dimensional requirements (height, length and width) indicated in Chap. -
Page 30: Temporary Stop
(see Par. 5.5 "CONNECTING THE WGM MOWER TO THE TRACTOR); • Remove the locking pin of the tractor joint with that of the WGM Mower drawbar; • Make sure that the locking pins with the relative cotter pins are inserted correctly in the housings located on the telescopic arms of the side and rear mowers (see par. -
Page 31: Routine Maintenance
Before performing maintenance, read this entire section to be prepared for all possible events. WARNING DANGER OF TIPPING OVER!! Make sure that the equipment (tractor and WGM Mower) is stable before performing any maintenance (the limit of maximum tilt of the land should be 3°). -
Page 32: Checking And Replacing The Oil In The Gearbox Unit
Remove paint with suitable products and then wash the surfaces and let them dry. SICMA INFORMS THAT ANY CHANGES OR ALTERATION TO THE WGM MOWER, OR ANY OPERATION PERFORMED AND NOT STRICLTY REPORTED IN THIS MANUAL, ESPECIALLY THE NON- COMPLIANCE WITH SAFETY INSTRUCTIONS, NOT ONLY VOID THE WARRANTY, BUT ALSO SICMA FROM ANY RESPONSIBILITY FOR DAMAGE TO PROPERTY AND PERSONS. -
Page 33: Replacing The Transmission Belts
Not mounting the original blades may result in abnormal vibrations of the machine. WARNING! Sicma disclaims all liability from harm that may arise from non- compliance with the requirements described above. 9.3 REPLACING THE TRANSMISSION BELTS Frequently check the state of wear of the belts (every 30 working hours) and replace them all even if one or both are deteriorated. -
Page 34: Cardan Shaft
WGM Mower as shown in the figure; To obtain perfect operation of the machine it is necessary to check frequently (at least every 50 hours of work) that the blades of the WGM Mower are all in a good condition and perfectly fixed by the tightening bolts as indicated in the "TIGHTENING TORQUES"... -
Page 35: Scrapping
15 TIGHTENING TORQUES TABLE Check the tightness of nuts and bolts daily. If necessary, replace them by repositioning them (screws, washers, nuts) respecting the disassembly sequence. TIGHTENING TORQUES Bolt class Threading 10.9 Lb-ft Lb-ft WGM Mower... -
Page 36: Trouble-Shooting Table
• Request can be found in the exploded view of the spare parts; • Requested quantity. Given the particular stress to which the equipment is subjected and for safety reasons, if pieces are replaced, only use original spare parts. WGM Mower... -
Page 37: Warranty
Manufacturer or the Retailer from liability for malfunctions or accidents. The removal or the modification of guards and protections relieves the Manufacturer from all liability due to damage/injury caused to objects and/ or persons. WGM Mower... -
Page 38: Notes
20 NOTES _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ WGM Mower... - Page 39 WGM Mower...
- Page 40 Sicma S.p.A Contrada Cerreto, 39 66010 Miglianico (Chieti) – Italy Tel. +39 0871 958 41 – www.sicma.it WGM Mower...
