9000 Series Access Carrier with AC Power Supply
Installation Instructions
Document Number 9000-A2-GN1D-90
November 2001
The 9000 Series Access Carrier with an AC power supply is a metal enclosure that
supports mounting of up to 14 Network Access Modules (NAMs).
It can be mounted in either a 19-inch or 23-inch cabinet or rack. Up to six carriers can be
installed in one standard 72-inch cabinet. All LEDs (light-emitting diodes) on the NAM(s)
are visible from the front of the access carrier. All I/O cables on the I/O card(s) are
accessed from the rear.

Package Checklist

In addition to the access carrier, verify that your package also contains the following:
Power supply (already installed) and power cord
Power supply fan tray (already installed)
Fan tray for NAMs (already installed)
Baffle for heat deflection, including extender brackets for installation in a 23-inch
rack, and associated screws
Alarm Relay Connector
Set of five filler panels with screws for any unused NAM slots and I/O slots
— Two panels that cover four slots
— Two panels that cover two slots
— One panel that covers one slot
Brackets with screws for installing the housing in a cabinet or rack (already mounted
in the 19-inch rack position)
When your equipment arrives, inspect it for physical damage and tighten any screws
that may have worked loose. Contact your sales representative immediately if there are
any signs of shipping damage, or if anything is missing from your package. Otherwise,
proceed with the installation.
