Summary of Contents for Aqua-Marina BT-23VAP
- Page 1 I N F L A T A B L E STANDUP PADDLE BOARD USER MANUAL...
- Page 2 For your own safety and that of your equipment, make sure to take the following precautions. Failure to follow warning notices and instruction may result in property damage, serious injury or WARNING death. GENERAL PADDLING INFORMATION This manual has been compiled to help you operate your Inflatable Stand Up Paddle Board (Hereinafter referred to as ISUP) with safety and pleasure.
- Page 3 WARNING LABEL INSTRUCTIONS MANDATORY INSTRUCTION • Wear personal flotation device • Read instructions first • Fully inflate all air chambers • Numbers of users • Max. load capacity • Safe distance to shore 150 m (492.1’) 130kg 286lbs PROHIBITION INSTRUCTION •...
- Page 4 RACING MODEL CORAL TOURING HYPER HYPER BREEZE VAPOR FUSION MONSTER CORAL BEAST MAGMA ATLAS RACE RACE BT-23CTPR BT-23HY01 BT-23HY02 BT-23BRP BT-23VAP BT-23FUP BT-23MOP BT-23COPR BT-23BEP BT-23MAP BT-23ATP BT-21RA01 BT-21RA02 BT-23CTPN BT-23COPN SIZE 11‘6“ 11‘6“ 12‘6“ 9'10" 10'4" 10'10" 12'0" 10'2"...
- Page 5 RIVER SURF WINDSURF MULTI-PERSON FITNESS FISHING Yoga Dock BT-23YD Outer Diameter: 290cm/9'6" Inner Diameter: 170cm/67" Thickness: 12cm/4.7” RECOMMENDED 18 PSI INFLATION 1.25 BAR WARNING: KEEP UNDER SHADE WHEN NOT IN USE WITH A WORKING PRESSURE LESS THAN 10 PSI. 45° LOCK SUPER SUPER...
- Page 6 Fore Keel D-ring Cargo Bungee Cord EVA Footpad Added Chamber Heavy-duty Neoprene Carry Handle High Pressure Recessed Valve Cargo Bungee Cord D-ring Kick Pad Fin Box High Pressure Recessed Valve Leash D-ring Actual configuration may vary upon different models.
- Page 7 ACCESSORIES STANDARD Zip Backpack Double-action Pump (Mega x 5/ (Mega/Airship Race/ Super Trip Tandem x 2) Super Trip Tandem x 2/ Wave x 3/ Blade x 2) Cargo Bungee Cord (except Wave) Repair Kit Leash (except Super Trip/ Super Trip Tandem/Mega/ Airship Race/Peace/Yoga Dock) *Actual configuration may vary upon different models.
- Page 8 INSTRUCTION FOR ASSEMBLING AND DISASSEMBLING INFLATION Open the valve cap by twisting Push valve button in and turn 90 counter-clockwise. Ensure the degrees. valve is clear from debris, sand, or dirt before releasing. UP POSITION UP POSITION DOWN POSITION DOWN POSITION Valve button popping up to the Valve button locked in “DOWN “UP position”...
- Page 9 LIQUID AIR V1 Fast Inflation – Use DOUBLE Easy Inflation – Switch to SINGLE ACTION position ACTION position by closing the air-tap to pump the by removing the air-tap for board up to 7-10 psi. easier inflation. LIQUID AIR V2 Fast Inflation –...
-
Page 10: Fin Installation
Warning: Do not leave your board under direct sunlight as this may cause over-inflation. Please keep the board under shade when not in use with a working pressure NO MORE THAN 10psi, or leave your board in a cool dry place. Remember to check the air pressure before and after use, and deflate your board when necessary. - Page 11 Swift Attach Fin System ( CORAL / BEAST / MAGMA / ATLAS / CORAL TOURING / HYPER / WAVE / DHYANA ) SLOT IN - Align the fin PRESS - Keep pressing SNAP - Lock the fin in base into the fin box slot the lever on the rear and place with the snap.
- Page 12 DEFLATION Valve Open – Open the valve cap and twist the valve button for “DOWN POSITION”. Ensure the valve is clear from debris, sand, or dirt before releasing. (for LIQUID AIR V1 only） Deflate (by hands) – Roll the Deflate (by pump) – Use the pump board from nose to tail to on “DEFLATE”...
-
Page 13: Paddle Assembly
YOGA DOCK INSTRUCTION YOGA DOCK and DHYANA Connection Each DHYANA yoga board can be connected to this YOGA DOCK by three straps. For each strap, follow connection instruction shown below. 1. Link up the clasp (a) with D-ring (b) on the board. Thread the strap through D-ring (c) on the dock. - Page 14 Ensure the center line of the scale is aligned with the indicator on clamp. CLAMP SYSTEM Adjust tightness by rotating the hasp to reduce any play. SPRING PIN SYSTEM Secure spring pin. NOTE: Always drain the water left in the paddle shaft after each use.
- Page 15 HOW TO WEAR A SAFETY LEASH WAIST RIVER LEASH B0303025 ANKLE COIL LEASH B0303930 SURF LEASH B0303024 STANDARD LEASH B0303929 STANDARD LEASH INSTALLATION COIL/SURF/RIVER LEASH INSTALLATION...
-
Page 16: Faqs (Frequently Asked Questions)
HOW TO TAKE CARE OF ISUP BOARD DO’S DON’TS DON’T USE AN AIR CLEANING COMPRESSOR Clean the board after You can easily over-inflate each use with freshwater the board by using an air and mild soap. compressor and void the warranty. - Page 17 HOW TO REPAIR A CUT OR PUNCTURE IN YOUR INFLATABLE BOARD SUPPLIES REQUIRED • Glue (AQUASEAL® is recommended) • Acetone or methyl ethyl ketone (M.E.K.) • Hairdryer • Brush • Tape Glue • Spatula or spoon • Towel (Not provided in the SUP board package) 1.
- Page 18 5. Apply the patch starting on one side and move towards the other side Be careful not to trap any air bubbles. 6. Use a hairdryer to gently heat the area to ensure a good bond between the patch and the board. Use a metal spatula or spoon and firm pressure to ensure a good bond and to remove any air bubbles.
- Page 19 Rubber Ring 3. Check the rubber ring to make sure that it is in the correct position, tight around the valve and there is no debris in the way 4. Be sure the pin spring is functioning properly and that there are no cracks along the edges 5.
-
Page 20: Warranty
WARRANTY AM warrants this product to be free from major defects in material or workmanship to the original purchaser for a period of 2-year (board ONLY) from the date of purchase. This warranty is subject to the YEAR YEAR following limitations. 1.
