EN
BLUEDRIVEX /X
PRO POWERFIN
PF-240X
PF-240XP
USERMANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BLUEDRIVE X and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Aqua-Marina BLUEDRIVE X

  • Page 1 BLUEDRIVEX /X PRO POWERFIN PF-240X PF-240XP USERMANUAL...
  • Page 2 CREATED FOR WATER LOVERS WHO WANT IT ALL! SUP Boarding Kayaking Snorkelling Scuba-diving A M Official Site A M H O W -TO Guide A M Service Center List...
  • Page 3: Table Of Contents

    2. Assembling the BLUEDRIVE X /X PRO to SUP or kayak 3. How to use the remote control when BLUEDRIVE X /X PRO is used on SUP or kayak Using the BLUEDRIVE X /X PRO for Snorkeling, Diving or Swimming .
  • Page 4 SAFETYWARNINGS Please read the instructions carefully before use and operate according to the instructions. • This product provides power for aquatic leisure products. It can only be used in water, not for other purposes. • This product can only be used in water. D o not allow the product to rotate in the air to avoid motor burnout due to excessive heating.
  • Page 5 • D o not use this equipment in sandy water or waters with similar physical properties. • D o not use this equipment in case of any damage or malfunction. • The product buoyancy is affected by the geographical location, temperature, depth, and water flow, and may sink when the product is released.
  • Page 6: Introduction

    Highly intelligent and equipped for a multitude of adventures, this all-in-one kit opens the doors to endless possibility in the water. Created for water lovers who want it all. The BLUEDRIVE X is ready to be your SUP, kayaking, swimming, snorkelling, diving and more companion.
  • Page 7: Partsand Technical Specifications

    III. PARTSAND TECHNICAL SPECIFICATIONS 3.1 PART LIST Main unit x 1 Locating pin x 2 Headlamp x 1 Charger x 1 Left handle top cover x 1 USB data cable x 2 Handle bracket x 1 Watch strap x 1 Quick-release spare screw x 2 Safety rope x 1 Remote control x 1...
  • Page 8 3.2 TECHNICAL SPECIFICATIONS Product Model PF-240X PF-240XP 3.5 kg / 7.7 lbs 4.3 kg / 9.5 lbs Weight 432 x 367 x 170 mm 515.5 x 367 x 170 mm Dimension 10m / 3h 10m / 3h Waterproof Depth Speed (km/h) Duration (min) Speed (km/h) Duration (min)
  • Page 9: Bluedrive X /X Pro In Use

    I V. BLUEDRIVEX /X PROINUSE 4.1 SUMMARY This section applies to the proper use of BLUEDRIVE X/ X PRO. Please follow each of the steps carefully in order to start your BLUEDRIVE X/ X PRO. Once the device is set up, go to the relevant section with your activity as follows: For the use on a SUP or kayak, go to section V.
  • Page 10: Preparing The Bluedrive X /X Pro

    4.2 PREPARING THE BLUEDRIVE X /X PRO Step 1: Open the battery compartment cover, remove the battery plug cover. LOCK OPEN Battery Compartment Cover Step 2: Install the battery into the battery compartment. Install the lower battery upside down by pulling up the handle at the bottom of the battery, direct the battery socket towards the bottom of the battery compartment, and then return the handle to a flattened state.
  • Page 11 Battery Plug Cover Main Unit Step 4: First, inspect whether the waterproof ring 1 on the battery compartment cover is installed properly. Align the four concave clips of the battery compartment cover with the convex clips of the main unit, and then rotate clockwise to lock.
  • Page 12: Charging The Bluedrive X Battery With The Battery Charger

    Charging the BLUEDRIVE X battery with the battery charger Warning: 1. Be sure to fully charge the battery before the first use. 2. Before removing the battery from the main unit, please turn off the machine with the remote control first to ensure the product is stopped.
  • Page 13: Charging The Remote Control

    Charging the remote control Warning: 1. Before charging, please confirm that the remote control is off. 2 . D o not operate the remote control while charging. Step 1: Remove the silicone cover of the charging interface at the bottom of the remote control in the direction of the arrow.
  • Page 14: Charging The Nose Illuminating System

    Charging the nose illuminating system Warning: 1. Before charging, make sure that the headlamp is off. 2 . D o not operate the headlamp while charging. Step 1: Rotate the headlamp anticlockwise and remove it from the main unit. Step 2: Please use D C 5V 1A power adapter (not provided) or standard USB charger for charging. Connect the magnetic connector of the USB data cable to the headlamp, and insert the other end into the USB charging port.
  • Page 15: Remote Control Pairing

    4.6 Remote control pairing When there are multiple PF-240X (P) units nearby, to avoid mutual interference, one-to-one control can be realized through pairing operation. Step 1: Remove the battery of the main unit. Step 2: Press the ON/OFF “ ” button on the remote control to start, press the ON/OFF “ ” button and the “+”...
  • Page 16: Usingthebluedrivex/Xpro Onsuporkayak

    V . USINGTHEBLUEDRIVEX/X PRO ONSUPORKAYAK...
  • Page 17: Contents Of Bluedrive X /X Pro Used On Sup Or Kayak

    5.1 Contents of BLUEDRIVE X /X PRO used on SUP or Kayak Main unit x 1 Headlamp x 1 Battery (PF-240X x 1,PF-240XP x 2) Remote control x 1 Watch strap x 1 Fin box connector x 1 Locating pins x 2 5.2 Assembling the BLUEDRIVE X /X PRO to SUP or kayak...
  • Page 18 Step 3: Align the fin box connector rail B with the fin box on SUP/KAYAK (not provided), slide the connector onto the fin box along the rail, and then insert the locating pin to hole B for locking. Rail B Fin Box Connector Fin Box...
  • Page 19: How To Use The Remote Control When Bluedrive X /X Pro Is Used On Sup Or Kayak

    5.3 How to use the remote control when BLUEDRIVE X /X PRO is used on SUP or kayak Step 1: Attach the remote control to the silicone watch strap. Remote Control Watch Strap Step 2: Press the ON/OFF button “”, and the remote control display will display the remote control power and the main unit power, indicating that the unit has started successfully.
  • Page 20: Usingthebluedrivex /X Profor Snorkeling,Divingor Swimming

    VI. USINGTHEBLUEDRIVEX /X PROFOR SNORKELING,DIVINGOR SWIMMING 6.1 Contents of BLUEDRIVE X /X PRO used for snorkeling, diving or swimming Main unit x 1 Headlamp x 1 Left handle top cover x 1 Handle bracket x1 Quick-release spare screws x 2...
  • Page 21: Assembling The Handheld Terminal

    Assembling the handheld terminal Handle assembly Left Right Step 1: Align the left handle with the left slot of the handle bracket, and then insert the top cover of the left handle into the left handle and screw clockwise. Step 2: Align the right handle with the right slot of the handle bracket, and then insert the remote control base into the right handle and screw clockwise.
  • Page 22 6.2.3 Remote control assembly Step 1: Install the remote control vertically. When the remote control latch makes a “click” sound, it is locked in place. Step 2: To remove, press the remote control latch outward, and then take out the remote control. Remote Control Latch 6.2.4 How to attach an action camera Please make sure your action camera (*not included) is waterproof to avoid damage caused by...
  • Page 23: How To Manipulate The Bluedrive X /X Pro While Snorkeling, Diving Or Swimming

    6.3 How to manipulate the BLUEDRIVE X /X PRO while snorkeling, diving or swimming Step 1: Long press the ON/OFF “” button of the remote control for 3 seconds, and the screen of remote control will flash 5 times, then the screen will display the remote control power and main unit power, indicating that the unit started successfully.
  • Page 24: How To Use The Nose Illuminating System

    Step 2: Press the trigger ( ON OFF switch ) on the right handle, and the display screen will show “ ”and the unit will run at default low speed. Double click to shift the gear. Trigger (Function “ ” Switch) •...
  • Page 25: Maintenance After Using Bluedrivex /X Pro

    VII. MAINTENANCE AFTER USING BLUEDRIVEX /X PRO 7.1 Cleaning To maintain good performance, please refer to the following steps for maintenance after each use: Step 1: Completely immerse the product in a container full of clean water (not sea water) for about 30 minutes.
  • Page 26: Troubleshooting

    Troubleshooting Problem Solving If the propeller is entangled in foreign matters, the tail cylinder of the main unit can be removed for cleaning. • Make sure to clean only when the power is off and the battery is removed. • Be careful not to scratch your fingers when cleaning foreign matters on the propeller.
  • Page 27: Packingandtransportationof Bluedrivex /X Pro

    Watch Strap 8.2 Travelling by air For information on transporting the BLUEDRIVE X / X PRO including battery by plane, please contact your operating airline. Li-ion batteries are subject to specific rules by airline authorities. Some airlines do not allow transporting Dive Scooters or batteries, so check in advance of travel.
  • Page 28: Battery Use&Careinformation

    IX. BATTERY USE&CAREINFORMATION Your BLUEDRIVE X/ X PRO works with a Li-Ion battery, that needs to be handled with care. Please read this manual carefully and follow the instructions below to prevent accidents and injuries. 9.1 BATTERY USE To ensure proper use of battery, read the following: •...
  • Page 29 • D o not charge the battery in temperatures above 45ºC (113ºF) as significant off gassing may occur. • Keep the battery and BLUEDRIVE X/ X PRO in a dry and shadowy spot when not in use. Always connect the charger to the battery first and then plug the charger into the mains.
  • Page 30: Important Safety Precautions And Warnings

    X. IMPORTANT SAFETY PRECAUTIONS AND WARNINGS • Children under the age of 14 should not be allowed to operate the BLUEDRIVE X/ X PRO. Note that only healthy and experienced swimmers are allowed to use BLUEDRIVE X/ X PRO. • D o not use BLUEDRIVE X/ X PRO while tired or under the influence of alcohol, drugs or medication.
  • Page 31 • Be careful not to hit other items when diving with the BLUEDRIVE X/ X PRO. Make sure to stay away from boats, bridges, rocks or any items which could hurt you. PAY SPECIAL ATTENTION WHEN DIVING • If you are not trained/certified in scuba, you should not use the BLUEDRIVE X/ X PRO below 3m (10ft) depth.
  • Page 32 • You will extend the lifespan of your battery if you do not expose it to hot environments for long periods of time. • Always keep the BLUEDRIVE X/ X PRO out of direct sunlight when not in use. TROUBLESHOOTING...
  • Page 33: Warranty Terms

    XI. WARRANTY TERMS Product warranty is one year after purchase. Any modification, usage outside the intended scope, or damage caused by improper operation not in accordance with this manual with void your warranty and will not be under the scope of the below terms. This warranty is subject to the following limitations: 1.
  • Page 34 w w w . a q u a m a r i n a . c o m...

This manual is also suitable for:

Bluedrive x proPf-240xPf-240xp
