- Page 1 INFLATABLE STANDUP PADDLE BOARD USER MANUAL...
- Page 2 For your own safety and that of your equipment, make sure to take the following precautions. Failure to follow warning notices and instruction may result in property damage, serious injury or WARNING death. GENERAL PADDLING INFORMATION This manual has been compiled to help you operate your Inflatable Stand Up Paddle Board (Hereinafter referred to as ISUP) with safety and pleasure.
-
Page 3: Product Serial Number
WARNING LABEL INSTRUCTIONS MANDATORY INSTRUCTION • Wear personal flotation device • Read instructions first • Fully inflate all air chambers • Numbers of users • Max. load capacity • Safe distance to shore 150 m (492.1’) 130kg 286lbs PROHIBITION INSTRUCTION •... - Page 4 TOURING ALL AROUND TOURING RACING MODEL CORAL TOURING HYPER HYPER BREEZE VAPOR FUSION MONSTER CORAL BEAST MAGMA ATLAS RACE RACE BT-21HY01 BT-21HY02 BT-21BRP BT-21VAP BT-21FUP BT-21MOP BT-21BEP BT-21MAP BT-21ATP BT-21RA01 BT-21RA02 BT-22CTP BT-22COP SIZE 11‘6“ 11‘6“ 12‘6“ 9'10" 10'4" 10'10"...
- Page 5 RACING RIVER SURF WINDSURF MULTI-PERSON FITNESS FISHING Yoga Dock BT-19YD Outer Diameter: 290cm/9'6" Inner Diameter: 170cm/67" Thickness: 12cm/4.7” DHYANA 18 PSI RECOMMENDED INFLATION 1.25 BAR WARNING: KEEP UNDER SHADE WHEN NOT IN USE WITH A WORKING PRESSURE LESS THAN 10 PSI. 45°...
- Page 6 D-ring Cargo bungee cord Added Chamber Bungee cord stopper Heavy-duty neoprene carry handle EVA deck High pressure recessed valve Bungee cord stopper 95kg Cargo bungee 209lbs NO PROTECTION AGAINST DROWNING cord AUCUNE PROTECTION CONTRE LA NOYADE KEIN SCHUTZ GEGEN ERTRINKEN SIN PROTECCIÓN CONTRA EL AHOGAMIENTO SWIMMERS ONLY LES NAGEURS SEULEMENT...
- Page 7 ACCESSORIES STANDARD Double-Action Pump - Center Fin Zip Backpack LIQUID AIR V1 (Mega x 5/ (Mega/Airship Race/ Super Trip Tandem x 2) Super Trip Tandem x 2/ (Coral/Beast/Magma/Atlas/Hyper/Coral Touring/ Wave x 3/ Blade x 2) Race/Race Elite comes with LIQUID AIR V2) Cargo Bungee Cord (except Wave) (Hyper x 2) W O N D E R...
- Page 8 INSTRUCTION FOR ASSEMBLING AND DISASSEMBLING INFLATION Push valve button in and turn 90 Open the valve cap by twisting counter-clockwise. Ensure the degrees. valve is clear from debris, sand, or dirt before releasing. UP POSITION UP POSITION DOWN POSITION DOWN POSITION Valve button popping up to the Valve button locked in “DOWN “UP position”...
- Page 9 LIQUID AIR V1 Easy Inflation – Switch to Fast Inflation – Use DOUBLE ACTION position by closing SINGLE ACTION position the air-tap to pump the by removing the air-tap for board up to 7-10 psi. easier inflation. LIQUID AIR V2 Fast Inflation –...
-
Page 10: Fin Installation
Warning: Do not leave your board under direct sunlight as this may cause over-inflation. Please keep the board under shade when not in use with a working pressure NO MORE THAN 10psi, or leave your board in a cool dry place. Remember to check the air pressure before and after use, and deflate your board when necessary. - Page 11 Press & Click Fin System ( WAVE ) PRESS - Keep pressing SLOT IN - Align the fin SNAP - Lock the fin in base into the fin box slot the button on the rear place with the snap. and slide to the front edge. and push the fin down.
- Page 12 DEFLATION Valve Open – Open the valve cap and twist the valve button for “DOWN POSITION”. Ensure the valve is clear from debris, sand, or dirt before releasing. Deflate (by hands) – Roll the board from nose to tail to squeeze the air out. (for LIQUID AIR V1 only）...
-
Page 13: Paddle Assembly
NOTE: For RACE board, we still recommend rolling your board around the pump. Alternatively, please fold in the dotted line as below (Fig. A) to avoid bending the side rail pads. TIP: Start to fold from here. (Fig. A) PADDLE ASSEMBLY Front Front Correct... - Page 14 Ensure the center line of the scale is aligned with the indicator on clamp. CLAMP SYSTEM Adjust tightness by rotating the hasp to reduce any play. SPRING PIN SYSTEM Secure spring pin. NOTE: Always drain the water left in the paddle shaft after each use.
- Page 15 HOW TO WEAR A SAFETY LEASH WAIST RIVER LEASH B0303025 ANKLE COIL LEASH B0303023 SURF LEASH B0303024 STANDARD LEASH B0302765 STANDARD LEASH INSTALLATION COIL/SURF/RIVER LEASH INSTALLATION...
-
Page 16: Faqs (Frequently Asked Questions)
HOW TO TAKE CARE OF ISUP BOARD DO’S DON’TS DON’T USE AN AIR CLEANING COMPRESSOR Clean the board after You can easily over-inflate each use with freshwater the board by using an air and mild soap. compressor and void the warranty. -
Page 17: Supplies Required
HOW TO REPAIR A CUT OR PUNCTURE IN YOUR INFLATABLE BOARD SUPPLIES REQUIRED • Glue (AQUASEAL® is recommended) • Acetone or methyl ethyl ketone (M.E.K.) • Hairdryer • Brush • Tape Glue • Spatula or spoon • Towel (Not provided in the SUP board package) 1. - Page 18 5. Apply the patch starting on one side and move towards the other side Be careful not to trap any air bubbles. 6. Use a hairdryer to gently heat the area to ensure a good bond between the patch and the board. Use a metal spatula or spoon and firm pressure to ensure a good bond and to remove any air bubbles.
- Page 19 Rubber Ring 3. Check the rubber ring to make sure that it is in the correct position, tight around the valve and there is no debris in the way 4. Be sure the pin spring is functioning properly and that there are no cracks along the edges 5.
-
Page 20: Warranty
WARRANTY AM warrants this product to be free from major defects in material or workmanship to the original purchaser for a period of one (1) Year from the date of purchase. This warranty is subject to the following YEAR YEAR limitations 1.
