Summary of Contents for Aqua-Marina AM-20NU
- Page 1 AM-20NU INFLATABLE STANDUP PADDLE BOARD USER MANUAL...
- Page 2 For your own safety and that of your equipment, make sure to take the following precautions. Failure to follow warning notices and instruction may result in property damage, serious injury or WARNING death. GENERAL PADDLING INFORMATION This manual has been compiled to help you operate your Inflatable Stand Up Paddle Board (Hereinafter referred to as ISUP) with safety and pleasure.
-
Page 3: Product Serial Number
WARNING LABEL INSTRUCTIONS MANDATORY INSTRUCTION • Wear personal flotation device • Read instructions first • Fully inflate all air chambers • Numbers of users • Max. load capacity • Safe distance to shore 150 m (492.1’) 140kg 308lbs PROHIBITION INSTRUCTION •... -
Page 4: Specification
SIZE VOLUME MAX. RIDER WGT MAX. AIR PRESSURE 10‘6“ x 32“ x 6“ Specially Designed NUTS 300 L 308 LBS / 140 KG 18 PSI 320 x 81 x 15cm Slide-in Center Fin AM-20NU ACCESSORY Heavy Duty Slide-in Center Fin... - Page 5 INSTRUCTION FOR ASSEMBLING AND DISASSEMBLING Pump Set Up And Inflation Connect the pump hose to the gauge housing and secure it tightly. * Pump is not included in the package. 1. Release the valve cover by twisting counter-clockwise. Ensure the valve is clear from debris, sand, or dirt before releasing.
- Page 6 Inflate Faster With Less Effort • Use full range of the pump cylinder while keeping your arms extended. • Bend your knees and use the body weight. SINGLE DOUBLE ACTION ACTION 1. Use DOUBLE ACTION mode by closing the air-tap to pump the board up to 7 psi.
- Page 7 Slide-in Center Fin Installation Once the board is inflated, slide in the Center Fin to the fin box and secure the push-in pin. Deflation To deflate your board, follow the instructions below. 1. Release valve cap by twisting counter-clockwise. Ensure the valve is clear from debris, sand, or dirt before releasing.
- Page 8 HOW TO REPAIR A CUT OR PUNCTURE IN YOUR INFLATABLE BOARD SUPPLIES REQUIRED • Glue (AQUASEAL® is recommended) • Acetone or methyl ethyl ketone (M.E.K.) • Hairdryer • Brush • Tape Glue • Spatula or spoon • Towel (Not provided in the SUP board package) 1.
- Page 9 5. Apply the patch starting on one side and move towards the other side Be careful not to trap any air bubbles. 6. Use a hairdryer to gently heat the area to ensure a good bond between the patch and the board. Use a metal spatula or spoon and firm pressure to ensure a good bond and to remove any air bubbles.
- Page 10 Rubber Ring 3. Check the rubber ring to make sure that it is in the correct position, tight around the valve and there is no debris in the way 4. Be sure the pin spring is functioning properly and that there are no cracks along the edges 5.
-
Page 11: Faqs (Frequently Asked Questions)
FAQs (Frequently Asked Questions) Q: How much air should I pump into my board, and how long does it take to inflate? A: The maximum pressure is 18 PSI , any higher you risk over inflating and damage. Depending on the size of your board it can take anywhere from 5 to 8 minutes. -
Page 12: Warranty
WARRANTY AM warrants this product to be free from major defects in material or workmanship to the original purchaser for a period of six (6) months from the date of purchase. This warranty is subject to the following MONTHS MONTHS limitations 1.
