Switching the Visual Input Signal System

You can make this setting only when AUX is set to "On" (
Setup" (page 43).
Setting item:
Signal
Setting contents:
Auto (Initial setting) / NTSC/PAL
Auto:
The video input signal type (NTSC or PAL) will be
automatically selected.
NTSC/PAL:
Choose the video input signal type manually.

HDMI Setup

[HDMI] is selected on the Source Setup Menu screen in step 1. See
"Source Setup" (page 41).
You can set the name of an external device connected via HDMI.
Setting item:
HDMI
Setting contents:
HDMI (HDMI 1*) (Initial setting) / DVD
HDMI
Set when a smartphone is connected via HDMI.
(HDMI 1):
DVD:
Set when an external DVD player is connected.
* When the HDMI selector is set to "On, " "HDMI 1" is displayed in the
Setting contents. For details on setting the HDMI selector, see "Setting
the HDMI Selector On/Off " (page 48).
Setting the Bluetooth Pandora®
[Bluetooth Pandora] is selected on the Source Setup Menu screen in
step 1. See "Source Setup" (page 41).
To use Bluetooth Pandora, set the Bluetooth Pandora setting to "On. "
Setting item:
Bluetooth Pandora
Setting contents:
Off / On (Initial Setting)
• When "On" is set, the Bluetooth Pandora® source is displayed on the
Menu screen.
• When the current source is Bluetooth Pandora, this setting cannot be
adjusted.
44
-EN

System Setup

). See "AUX
[System] is selected on the Setup main screen in step 3. See "Setup
Operation" (page 28).
System Setup Menu screen
<Setting items>
1
Camera*
Camera Select
Camera Signal*
Guide Adjustment*
Camera Interrupt (Power Mode)*
Factory System Setup
USB/iPod / SiriusXM
Default Vehicle Screen
Maestro Module
Rear Seat Entertainment
Rear Seat Entertainment
Remote Sensor
External Accessories
External Audio Processor
HDMI selector
External Accessory Ctrl
Smartphone Apps
Alpine TuneIt App*
*1 When you select "Camera Selector" in "Camera Select", the setting item
is different. For details, see "Setting Multi Camera to On/Off "
(page 47).
*2 When Camera Select is set to "Off, " you cannot select this item.
*3 You can select this item only when Camera Select is "Front" or "Rear. "
*4 You can select this item only when Camera Select is "Rear. "
*5 Set this setting after closing the Alpine TuneIt App.
The following steps 1 to 3 are common to each "Setting
item" of System Setup. See each section for details.
1
Select the desired item.
2
To switch the setting, touch [ ], [ ], [ ], [ ], or mark the
checkboxes "Off" (
• If " " appears, there is a further hierarchy. Touch the desired
item.
3
Touch [ ] to return to the main source screen.
• To return to the previous List screen, touch [ ] in the previous
page. For details, see "About Basic Operation for List Screen"
(page 18).
2
3
4
5
) or "On" (
).
