Setting the Balance/Fader/Rear Speaker/
Subwoofer
Set Balance/Fader/Rear Speaker/Subwoofer/Subwoofer Level/
Subwoofer Phase in the Bal./Fad. screen.
Setting item:
1 1
Balance* / Fader* / Rear Speaker / Subwoofer*
1
Subwoofer Phase*
*1 When selecting either of the above setting items, the Bal./Fad. screen is
displayed.
*2 When "BASS ENGINE SQ" is selected in the Shortcut Setup, this setting
is disabled.
• This setting can also be activated by touching Sound Setup shortcut key
on Audio source screen. Refer to "About the Shortcut Key" (page 22).
Fad./Bal. screen
Enables you to change to each setting screen.
Balance/Fader Image area
Setting the Balance/Fader
Touch the desired point within the image area. Or touch [
[ ] [ ] [ ].
Balance:
L15 to R15
Fader:
F15 to R15
• To reset to the initial setting (Balance: 0, Fader: 0), touch [Center].
Rear Speaker Setting
You can set the rear speaker output to "Off. "
Setting item:
Rear Speaker
Setting contents:
On (Initial setting) / Off
Turning Subwoofer ON/OFF
If an optional subwoofer is connected to the unit, make the following
setting.
Setting item:
Subwoofer
Setting contents:
On / Off (Initial setting)
32
-EN
Adjusting the Subwoofer Level
You can set the Subwoofer level when a Subwoofer is connected.
Setting item:
Setting contents:
• This setting is only available when "Subwoofer" is set to "On" (
2 1, 2
/ Subwoofer Level* /
Setting the Subwoofer Phase
The subwoofer output phase is toggled Subwoofer Normal (0°) or
Subwoofer Reverse (180°).
Setting item:
Setting contents:
• This setting is only available when "Subwoofer" is set to "On" (
Media Xpander (MX HD) makes vocals or instruments sound distinct
regardless of the music source. The HD-Radio Technology (FM)/
SiriusXM, USB Flash drive and iPod/iPhone, will be able to reproduce
the music clearly even in cars with a lot of road noise.
Setting item:
• When the Defeat setting is "On, " you cannot perform the set up.
• When "BASS ENGINE SQ" is selected in the Shortcut Setup, this setting
• The MX HD setting can be performed only when a source is currently
HD-Radio™ (FM)/SiriusXM: Off (Initial setting) / Level1 / Level2 / Level3
]
Compressed Media/Factory Audio: Off (Initial setting) / Level1 / Level2 /
Level3
HDMI/AUX: Off (Initial setting) / Compressed Media / Movie / Music
(Movie)
(Music)
• The effect increases as the MX HD setting value increases Level1
• You can set this for each source.
• iPod/iPhone/USB Audio/USB Video/Bluetooth Audio/Pandora/
• Factory Media (USB/iPod)/Factory SiriusXM correspond to Factory
Subwoofer Level
0 to 15 (Initial setting: 0)
Subwoofer Phase
0° (Initial setting) / 180°

Setting the Media Xpander (MX HD)

MX HD
is disabled.
selected.
Adjustable source (media) and setting value
The medium to high frequencies become more clear, and produces
well balanced sound in all the bands.
This corrects information that was omitted at the time of
compression. This reproduces a well-balanced sound close to the
original.
Choose the MX HD mode (Compressed Media, Movie, or Music) that
corresponds to the media connected.
The dialog portion of the video is reproduced more clearly
This file contains a large quantity of data such as music clip. MX uses
this data to reproduce the sound accurately.
Level2 Level3.
Bluetooth Pandora/Apple CarPlay Music/Google Play Music
correspond to Compressed Media.
Audio.
).
).
