Freestanding Dual Horizontal
COMPONENT CHECKLIST
A
Crossbar
(x1)
B
VESA
Plate
(x2)
C
Upright
Pole
(x1)
IMPORTANT INFORMATION
! Please ensure this product is installed as per these installation instructions.
! Each VFS Display Head supports a maximum weight as per above weight range specification.
! This product supports VESA mounting hole configurations: 75x75mm and 100x100mm.
! The manufacturer accepts no responsibility for incorrect installation.
! This product is not suitable for outdoor use.
! Do not use this product for mobile applications.
M8x50mm
Screw (x1)
D
Base
H
(x1)
Mounting
Screw
M4x16mm
(x8)
E
3/5mm
Hex Key
(x1 each)
K
(Optional)
Security Screw
(x2)
F
G
M6x25mm
Cap Screw
(x1)
I
J
Mounting
Mounting
Screw
Screw
M4x12mm
M4x10mm
(x8)
(x8)
L
M
Cable Ball
Cable Clip
(x6)
(x4)
Installation Guide
VFS-DH
REQUIRED TOOLS
• Phillips Head Screwdriver
WEIGHT RANGE
Per Monitor
Flat Monitor
0 - 12kg (0 - 26.5lb)
Curved Monitor
0 - 9kg (0 - 20lb)
NOTE
• 120mm (4.75") max overall
monitor depth.
• 2kg (4.4lb) maximum weight
difference between monitors.
VFS-DH Page 1 of 4
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Atdec VFS-DH
Summary of Contents for Atdec VFS-DH
- Page 1 ! Please ensure this product is installed as per these installation instructions. ! Each VFS Display Head supports a maximum weight as per above weight range specification. ! This product supports VESA mounting hole configurations: 75x75mm and 100x100mm. ! The manufacturer accepts no responsibility for incorrect installation. ! This product is not suitable for outdoor use. ! Do not use this product for mobile applications. VFS-DH Page 1 of 4...
- Page 2 Flush Spacer • If spacers are needed, use the shortest possible combination between the display bracket and the display. Too long Too short VFS-DH Page 2 of 4...
- Page 3 NOTE: Ball joint tension may need to be loosened, adjusted and tightened to set the desired position. E - 3mm Hex Key VFS-DH Page 3 of 4...
- Page 4 No portion of this document or any artwork contained herein should be reproduced in any way without the express written consent of Atdec Pty Ltd. Due to continuing product development, the manufacturer reserves the right to alter specifications without notice. ©20231127 VFS-DH Page 4 of 4...
