Owner's Manual & Safety Instructions
Save This Manual
operating, inspection, maintenance and cleaning procedures. Write the product's serial number in the
back of the manual (or month and year of purchase if product has no number). Keep this manual and the
receipt in a safe and dry place for future reference.
7-1/4"
CIRCULAR SAW
Blade Sold Separately
email our technical support at: productsupport@harborfreight.com
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1‑888‑866‑5797 as soon as possible.
©
Copyright
2023 by Harbor Freight Tools
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Keep this manual for the safety warnings and precautions, assembly,
Visit our website at: http://www.harborfreight.com
®
. All rights reserved.
21701EB
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
23f
57672

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 21701EB and is the answer not in the manual?

Questions and answers

Related Manuals for Bauer 21701EB

Summary of Contents for Bauer 21701EB

  • Page 1 Write the product’s serial number in the back of the manual (or month and year of purchase if product has no number). Keep this manual and the receipt in a safe and dry place for future reference. 21701EB 7-1/4" CIRCULAR SAW Blade Sold Separately Visit our website at: http://www.harborfreight.com...

  • Page 2: Important Safety Information

    table of contents Safety ............2 Operation ........... 10 Specifications ..........8 Maintenance ..........13 Setup ............9 Warranty ............ 16 WarninG SyMBOLS anD DeFinitiOnS This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.
  • Page 3 d. Do not abuse the cord. never use the cord i. Only use safety equipment that has been for carrying, pulling or unplugging the power approved by an appropriate standards agency. tool. Keep cord away from heat, oil, sharp Unapproved safety equipment may not provide edges or moving parts.
  • Page 4 c. Disconnect the plug from the power c. adjust the cutting depth to the thickness of source and/or remove the battery pack, the workpiece. Less than a full tooth of the blade if detachable, from the power tool before teeth should be visible below the workpiece. making any adjustments, changing d.
  • Page 5 9. When blade is binding, or when interrupting 12. riving knife function a cut for any reason, release the trigger and a. use the appropriate saw blade for the riving hold the saw motionless in the material until knife. For the riving knife to function, the body the blade comes to a complete stop.

  • Page 6: Grounded Tools: Tools With Three Prong Plugs

    Grounding tO preVent eLectric SHOcK anD DeatH FrOM incOrrect GrOunDinG Wire cOnnectiOn: check with a qualified electrician if you are in doubt as to whether the outlet is properly grounded. Do not modify the power cord plug provided with the tool. never remove the grounding prong from the plug.
  • Page 7 5. If you are using one extension cord for more taBLe a: recOMMenDeD MiniMuM Wire than one tool, add the nameplate amperes GauGe FOr eXtenSiOn cOrDS* (120/240 VOLt) and use the sum to determine the required eXtenSiOn cOrD naMepLate minimum cord size. (See table a.) LenGtH aMpereS 6.
  • Page 8 Specifications Electrical Rating 120VAC / 60Hz / 14A No Load Speed : 5,200/min Bevel Capacity 0° to 52° 2‑7/16″ @ 90° Depth of Cut 1‑7/8″ @ 45° Maximum Blade Diameter 7‑1/4″ (185mm) Arbor 5/8″ (16mm) round Page 8 For technical questions, please call 1-888-866-5797. Item 57672...
  • Page 9 Setup - Before use: read the entire iMpOrtant SaFety inFOrMatiOn section at the beginning of this manual including all text under subheadings therein before set up or use of this product. Functions auxiliary Fixed Handle Guard Dust port Bevel Scale Bevel Lock Knob...

  • Page 10: Setting And Testing

    Operating instructions read the entire iMpOrtant SaFety inFOrMatiOn section at the beginning of this manual including all text under subheadings therein before set up or use of this product. tO preVent SeriOuS inJury FrOM acciDentaL OperatiOn: Make sure that the trigger is in the off-position and unplug the tool from its electrical outlet before performing any procedure in this section.

  • Page 11: Workpiece And Work Area Set Up

    adjusting Bevel 1. Loosen the Bevel Lock Knob to allow 2. Use the Bevel Scale to set the desired angle. the angle of cut to be adjusted. 3. After adjustment, tighten the Bevel Lock Knob. WarninG! tO preVent SeriOuS inJury: tighten Bevel Lock Knob before use.
  • Page 12 General instructions for use 1. Make sure that the Trigger is in the 6. Do not force the Circular Saw to cut faster off‑position, then plug in the tool. than it is designed to cut. Feed the saw blade gradually into the workpiece. 2.

  • Page 13: Cleaning, Maintenance, And Lubrication

    Maintenance and Servicing instructions procedures not specifically explained in this manual must be performed only by a qualified technician. tO preVent SeriOuS inJury FrOM acciDentaL OperatiOn: Make sure that the trigger is in the off-position and unplug the tool from its electrical outlet before performing any procedure in this section.

  • Page 14: Troubleshooting

    troubleshooting problem possible causes Likely Solutions Tool will not start. 1. Cord not connected. 1. Check that cord is plugged in. 2. No power at outlet. 2. Check power at outlet. If outlet is unpowered, turn off tool and check circuit breaker. If breaker is tripped, make sure circuit is right capacity for tool and circuit has no other loads.
  • Page 15 record product’s Serial number Here: note: if product has no serial number, record month and year of purchase instead. note: Reference UPC 193175420893. Item 57672 For technical questions, please call 1-888-866-5797. Page 15...
