The Handy 22750 Instructions Manual

B.u.l. lift

1. Center load on table = 2500 lb. maximum.

2. Connect to 120 psi maximum shop air.

3. Keep safety bar in position at all times - except when lowering.

4. Keep hands and tools from under carriage.

5. Do not mount table when in elevated position.

6. Do not ride vehicle onto lift.

7. Lift must be in the lowered position when moving.

8. Only trained persons should operate air lift.

9. The working area should be sufficiently lit.

10. Foot controller should be at least 3 feet away from

air lift during raising and lowering operation.

11. Recommended for indoor use only.

12. Tie-down straps must be used in conjunction with the holes provided

in the lift top.

13. Exhaust all air from bellows before removing the load from the lift.

14. Hose may remain connected, but when desired height is reached, foot

pedal must be in down position. Failure to put pedal in down position

may result in airbag failure.

B.U.L. LIFT –

Instructions ~ Part drawings

Item # 22750

Part list

Table of Contents

Need help?

Do you have a question about the 22750 and is the answer not in the manual?

Page 1 B.U.L. LIFT – Item # 22750 Instructions ~ Part drawings Part list 1. Center load on table = 2500 lb. maximum. 2. Connect to 120 psi maximum shop air. 3. Keep safety bar in position at all times - except when lowering.
Page 2 NOTE: READ ENTIRE MANUAL TO COMPLY WITH ALL SAFETY AND SERVICE PRECAUTIONS. DEATH, PERSONAL INJURY AND/OR PROPERTY DAMAGE MAY OCCUR UNLESS INSTRUCTIONS ARE FOLLOWED CAREFULLY. UNPACKING AND SET-UP 1. Cut banding and remove carton top. 2. Remove the two anchors that secure lift to the pallet. 3.
Page 3 OPERATION 1. Loads must be centered at all times. Lift is rated at a maximum of 2500 lbs. 2. It is the operator’s responsibility to determine if load needs to be additionally secured with straps. 3. To raise lift press UP side of the pedal, to lower lift press DOWN side of the pedal.
Page 4 FIGURE 2.
Page 5 PARTS DRAWING...
Page 6 PARTS LIST BRB5305-2RS...
Page 7 Also excluded in this warranty are items that were purchased for the Handy lift and installed on it after the factory such as electric motors, hand-held pendants and bearings. Parts considered wearable carry a 90-day warranty.
Page 8 Product has been tested and passed all inspections free of any leaks or malfunction. Inspected by: Handy, Division of Janco Industries Inc. 600 W 2 Ave, Sully, IA 50251 Ph: 855-752-5446 Fax: 641-594-3330 www.handyindustries.com 22750 4/20...
