The Handy 16867G Instructions, Parts Drawing, Part List

Gruntavore lift

1. Center load on table - 1800 lb. maximum.

2. Connect to 110 psi maximum shop air.

3. Keep safety bar in position at all times - except

4. Keep hands and tools from under carriage.

5. Do not mount table when in elevated position.

6. Do not ride vehicle onto lift.

7. Lift must be in the lowered position when moving.

8. Only trained persons should operate Air Lift.

9. The working area should be sufficiently lit.

10. Foot controller should be at least 3 feet away from

11. Recommended for indoor use only.

12. Tie-down straps must be used in conjunction with

the holes provided in the lift top.

HANDY Division of Janco Industries Inc . Ph: 855-752-5446

GRUNTAVORE LIFT



Instructions



ITEM # 16867G

when lowering.

Air Lift during raising and lowering operation.

Part drawings



Part list

Fax 641-594-3330 www.handyindustries.com

Table of Contents

Need help?

Do you have a question about the 16867G and is the answer not in the manual?

Page 1 Instructions  Part drawings  Part list ITEM # 16867G 1. Center load on table - 1800 lb. maximum. 2. Connect to 110 psi maximum shop air. 3. Keep safety bar in position at all times - except when lowering.
Page 2 NOTE: READ ENTIRE MANUAL TO COMPLY WITH ALL SAFETY AND SERVICE PRECAUTIONS. DEATH, PERSONAL INJURY AND/OR PROPERTY DAMAGE MAY OCCUR UNLESS INSTRUCTIONS ARE FOLLOWED CAREFULLY. UNPACKING AND SET-UP 1. Open carton, then remove ramp and shipping boards. 2. Connect foot-operated air valve to 110 psi maximum air supply. The lift may be damaged and/or personal injury may result if the pressure exceeds the maximum 110 psi rating.
Page 3 MOUNTING ILLUSTRATION AND PARTS DRAWING...
Page 4 It does not cover any cost of labor, transportation, freight, installation, misuse, abuse, or rust or failure of the air cylinder and/or foot pedal due to rust and or moisture. Also excluded in this warranty are items that were purchased for the Handy lift and installed on it at the factory such as electric motors, hand-held pendants and bearings.
