STANDARD AIR LIFT
INSTRUCTIONS
WARNING: READ INSTRUCTIONS BEFORE OPERATING
1. Center load on table - 1000 lb. maximum.
2. Connect to 110 psi maximum shop air.
3. Keep safety bar in position at all times - except
when lowering.
4. Keep hands and tools from under carriage.
5. Do not mount table when in elevated position.
6. Do not ride vehicle onto lift.
7. Lift must be in the lowered position when moving.
8. Only trained persons should operate Air Lift.
9. The working area should be sufficiently lit.
10. Foot controller should be at least 3 feet away from
Air Lift during raising and lowering operation.
11. Recommended for indoor use only.
