S.A.M. ELECTRIC LIFT
WITH PUSH BUTTON CONTROL
INSTRUCTIONS
PARTS DRAWING
PART LIST
λ
λ
λ
P/N 16007G - 16007O - 16007R - 16007B
1. Center load on table - 1000 lb. maximum.
2. Connect to 115v power supply.
3. Keep hands and tools from under carriage.
4. Do not mount table when in elevated position.
5. Do not ride vehicle onto lift.
6. Lift must be in the lowered position when moving.
7. Only trained persons should operate Lift.
8. The working area should be sufficiently lit.
9. Recommended for indoor use only.
10. Tie-down straps must be used in conjunction with
the holes provided in the lift top.
Advertisement
Table of Contents
Related Manuals for The Handy 16007G
Summary of Contents for The Handy 16007G
- Page 1 PART LIST λ λ λ P/N 16007G - 16007O - 16007R - 16007B 1. Center load on table - 1000 lb. maximum. 2. Connect to 115v power supply. 3. Keep hands and tools from under carriage. 4. Do not mount table when in elevated position.
- Page 2 NOTE: READ ENTIRE MANUAL TO COMPLY WITH ALL SAFETY AND SERVICE PRECAUTIONS. DEATH, PERSONAL INJURY AND/OR PROPERTY DAMAGE MAY OCCUR UNLESS INSTRUCTIONS ARE FOLLOWED CAREFULLY. POWER SUPPLY This lift is for operation on 115 volt, 60 Hz current only. Check outlet voltage before plugging in equipment. WARNING: This lift is equipped with a 3-prong plug which must be plugged into a grounded 115 volt, 60 Hz power supply for your safety.
- Page 3 PARTS DRAWING - PARTS LIST...
- Page 4 WIRING DIAGRAM...
- Page 5 ELECTRIC CONTROL SYSTEM...
- Page 6 Also excluded in this warranty are items that were purchased for the Handy lift and installed on it at the factory such as electric motors, hand-held pendants and bearings.
