CBIPADDLE FAMILY - OPERATING MANUAL // PAGE 20
1. Push and release the Paddle 2 times in a row in the direction of the position you wish to reach
(up for "Stand", down for "Sit").
▸ The Table Top will stop when Sit or Stand Memory Position is reached and the display will
indicate that Sit or Stand memory position has been reached:
SIGNAL
Con
Con
INFO
For a list of Control Boxes supporting displaying user information when memory position
is reached, please contact LOGICDATA.

7.4 CONTAINER STOP AND SHELF STOP POSITIONS

These features can limit the movement area of the Table Top (if e.g. a container is below the table or a shelf
is above it). Container Stop Positions become the new lowest end position, Shelf Stop Positions the highest.
INFO
Container Stop Positions can only be saved only in the lower half of the movement
area, Shelf Stop Positions in the upper half. You must set each position separately.

7.4.1 SAVE A CONTAINER STOP OR SHELF STOP POSITION

1. Use the Paddle to move the Table Top to the desired height.
2. Press and hold the Multi-functional Key for 10 seconds.
▸ The Container Stop / Shelf Stop Position is saved (Container Stop if you are in the bottom
half of the movement area, Shelf Stop if you are in the top half).
▸ Control Box clicks twice.

7.4.2 DELETE A CONTAINER STOP OR SHELF STOP POSITION

1. Use the Paddle to move the Table Top to the position you wish to delete.
2. Press and hold the Multi-functional Key for 10 seconds.
▸ The Container Stop / Shelf Stop Position is deleted (Container Stop if you are in the bottom
half of the movement area, Shelf Stop if you are in the top half).
▸ Control Box clicks once.
MESSAGE
Sit Memory Position is reached.
Stand Memory Position is reached.
