Nexcom NSA 5190 Quick Reference Manual page 2

NSA 5190 Quick Reference Guide
J2
A1 A25
H2
BAT1
J3
H4
1
7
1
7
H3
B82 B12 B11 B1 B49
H1
PCIE1
J1
FAN1 FAN2
H27
CN1
B1 B11 B12 B18 B1
4
2 2 10
H5 JP2 JP3
2 8
1
1
1 7 2 6
JP1
PCIE5
1 5
B1 A1
B11 A11
B12 A12
DIMM1
(Run BMC)
1
U22
33
65
1
B49 A49
97 128
H9
143 144
145 146
BZ1 H6
BIOS_J1
BIOS1
H15
PCH1
H26
H7
H13 H16
H8 H10
B12 B11 B1 B49 B12 B11 B1 B49
PCIE2 PCIE3
PCIE5: PCIe Slot (for Standard PCIe Card Only Support NVMe Storage)
FAN3
FAN4
H22
1 4
B11 B12 B18 B1 B11 B12 B18
H21
H19
CPU1
52
50
42
40
30
F
20
10
1
A P
H18
H20
NVME1
2
1
74 75 H23 H24
H17
B12 B11 B1 B49 B12 B11 B1
PCIE4
Pin Signal
A1 GND
A2 12V
A3 12V
A4 GND
A5 NC
A6 NC
A7 NC
A8 NC
A9 3.3V
A10 3.3V
B1 A1
A11 reset
A12 GND
B11 A11
B12 A12
A13 CLK
A14 CLK
A15 GND
A16 RXP
A17 RXN
A18 GND
A19 NC
A20 GND
B49 A49
A21 RXP
A22 RXN
A23 GND
A24 GND
A25 RXP
A26 RXN
A27 GND
A28 GND
A29 RXP
A30 RXN
Pin Signal
B1 12V
B2 12V
B3 12V
B4 GND
B5 SMBCLK
B6 SMBDAT
B7 GND
B8 3.3V
B9 NC
B10 3.3V AUX
B11 wake
B12 NC
B13 GND
B14 TXP
B15 TXN
B16 GND
B17 NC
B18 GND
B19 TXP
B20 TXN
B21 GND
B22 GND
B23 TXP
B24 TXN
B25 GND
B26 GND
B27 TXP
B28 TXN
B29 GND
B30 NC
