200C Series Identification; Lp100 Junction Box - ICON Level pro 200C Series Operating Manual

200C Series 200C Series
(Capacitive Ceramic) (Capacitive Ceramic)
Continuous Submersible Level Transmitter Continuous Submersible Level Transmitter

200C Series Identification

The Solution to Tough Applications Where
Ultrasonic Sensors Simply DO NOT WORK!

LP100 Junction Box

®
The LevelPro 200C Series continuous submersible level transmitter
and tank level Junction box are a perfect pair for applications where
ultrasonic sensors aren't going to work.
Accurately measure tank levels with this rugged combination that's
simple to use and boasts superior chemical resistance along with
industry exclusive features
Gortex ® Breather
The 200C Series
Transmitter is designed
for Continuous Level
Measurement of
Aggressive Liquid Media
Internal Wiring
From Sensor
Out to Display
®
Vaporbloc
Nominal Type
Pressure Range Designation
pressure measurement
www. iconprocon.com
Type: Code:
Input : 0 - 10 m WC
Signal
Output : 4-20mA 2-wire
Supply: 12-36 VDC
Supply
The Device can be Identified by its
Manufacturing Label.
Features
New Vaporbloc
NEMA 4X Enclosure
Tool Free Wiring Terminals
All Plastic NEMA 4X Enclosure
2" Threaded Connection
Excellent Chemical Resistance
Weather Resistant
Gortex Air Breather Included
®
Polypropylene Cord Grips
Tethered Lid
Lightweight Glass Filled Polypropylene
Self-Draining Lid
Vaporbloc ®
Blocks out Corrosive Chemical Fumes
Pressure Tested to 75 psi
Protects Internal Wiring Connections
Eliminates Corrosive Funes Out-gassing
into Environment
Before
