LevelPro
— ProScan
2 Series
®
®
Radar Level Sensor (80GHz)
Quick Start Manual
Read the user's manual carefully before starting to use the unit.
Producer reserves the right to implement changes without prior notice.
1
25-0724 © Icon Process Controls Ltd.

Advertisement

loading
Need help?

Need help?

Do you have a question about the LevelPro ProScan 2 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for ICON LevelPro ProScan 2 Series

  • Page 1 — ProScan 2 Series ® ® Radar Level Sensor (80GHz) Quick Start Manual Read the user's manual carefully before starting to use the unit. Producer reserves the right to implement changes without prior notice. 25-0724 © Icon Process Controls Ltd.
  • Page 2 GFPP Body PTFE Antenna 316 SS+GFPP Body PTFE Antenna Epoxy Coated CI + 316 SS Body PTFE Antenna Dimensions 93mm x 190mm 93mm x 207mm 96.5mm x 221mm Installation 2" NPT 150lb ANSI Flange 25-0724 © Icon Process Controls Ltd.
  • Page 3 NEMA 4X Enclosure Back-lit LCD Display Thermoplastic Housing 2” NPT Connection PTFE Antenna Push Button Programming Visual Level Indication ProScan 2 Versions ® PTFE 316 Stainless Steel 316 Stainless Steel XP GFPP PTFE 316SS 25-0724 © Icon Process Controls Ltd.
  • Page 4 Wiring Diagram – External Display TVL Display ® ProScan ENTER MENU Power Supply Terminal 1 & 2 Red(+) wire Terminal 8 Black(-) wire Terminal 11 25-0724 © Icon Process Controls Ltd.
  • Page 5 Special consideration is required during the installation to ensure the blanking area is taken into account. 25-0724 © Icon Process Controls Ltd.
  • Page 6 LevelPro — ProScan 2 Series ® ® Radar Level Sensor (80GHz) Sensor Positioning 200 mm (7.87") 25-0724 © Icon Process Controls Ltd.
  • Page 7 The distance from the tip of the sensor to the highest liquid or 4 mA full level Display Description Temperature Display 1 Display 2 Damping Value Reading Real-Time Value Level / Distance Bar Indication Echo Strength mA Reading mA Reading Temperature Reading 25-0724 © Icon Process Controls Ltd.
  • Page 8 High/Low Calib. Material Type Near Range This setting is critical for complex applications like low Dielectric Constant (DK) liquid measurement and must be selected based on the application. Factory Default : >10 >10 3-10 <3 25-0724 © Icon Process Controls Ltd.
  • Page 9 Factory Default : 48.00 in. Far Range 48.00 Damping ▶ High/Low Calib. Near Range Far Range Damping Sensor Mode Damping Reduces the impact of sudden level fluctuations for a smoother output signal. Factory Default : 2 Sec Damping 25-0724 © Icon Process Controls Ltd.
  • Page 10 Sensor Mode Point to material surface. Level Level 3. Distance : Distance from Sensor Space Reference Point to material surface. Calibration Distance Point Home Screen ▶ 31.9157 31.916 Home Screen 11.489mA 28.0°C LEVELPRO 0000 25-0724 © Icon Process Controls Ltd.
  • Page 11 Temperature Unit Select the temperature unit : ºC | K Factory Default : ºC Temp Unit Language ▶ Sensor Unit Temp. Unit Language LCD Contrast Percent Current Language Factory Default : English Language English 25-0724 © Icon Process Controls Ltd.
  • Page 12 Antenna Material PS28000 GFPP PTFE Teflon ® Flange PS28500 GFPP PTFE Teflon ® PS28000S Epoxy Coated Cast Iron + 316SS PTFE Teflon ® Flange PS28500S Epoxy Coated Cast Iron + 316SS PTFE Teflon ® 25-0724 © Icon Process Controls Ltd.
  • Page 13 Icon Process Controls Ltd for a period of one year from the date of sale of such products. Icon Process Controls Ltd obligation under this warranty is solely...
