200C Series
(Capacitive Ceramic)
Continuous Submersible Level Transmitter
Connection Diagram -
Junction Box Terminals
3 4
3 4
Junction Box Terminals
Red wire Terminal 3
Black wire Terminal 2
200C Series Sentinel LTE Telemetry
200C Series
Wiring Diagram
24VDC
Supply +
A
P
I Supply -
2-wire-system (current)
Sensor + Sentinel LTE
Junction Box Terminals
Red wire Terminal 6
Black wire Terminal 1
3 4
3 4
Junction Box Terminals
Green wire Terminal 5
Black wire Terminal 4
R
+
(Red)
V s
(White)
+ TVL Display
13 12 11 10 09 08 07
TVL Terminals
Red wire Terminal 8
Black Wire Terminal 11
TVL Channel Terminals
16 15 14 13 12 11 10 09 08 07
Sentinel LTE Series
Wiring Diagram
Green
V s
Black
2-Wire-System | 4-20mA
www.iconprocon.com | sales@iconprocon.com | 905.469.9283
Power Supply
120VAC
04 03 02 01
TVL Terminals
Black Wire Terminal 1
White Wire Terminal 2
120 VAC Power Supply
06 05 04 03 02 01
Supply +
Supply -
R
R
