Connection Diagram - Sensor + 250B Display - ICON Level pro 200C Series Operating Manual

Submersible level sensors
Table of Contents

Advertisement

200C Series
(Capacitive Ceramic)
Continuous Submersible Level Transmitter
04
Wire Clamp Up
07
Do Not Drop Sensor
Connection Diagram -
200C Series Sensor
Supply +
Supply -
05
Connection : Sensor Wire
Red
wire Terminals # 1
Black
wire Terminals # 3
2" NPT
Connection
Carefully Lower
the Sensor
Sensor
+
250B Display
Sensor Wire
Red
Red
: Terminal # 1
Black
: Terminal # 3
V s
Black
3 4
-
+
Sensor Wire
7 8
08
Thread into Tank Fitting
Junction Box
3 4
Red
Black
www.iconprocon.com | sales@iconprocon.com | 905.469.9283
06
Do Not Use Tools
Hand Tighten Only
250B Series Display
R
Right Port for Sensor
Black
: Terminal # 2
: Terminal # 4
R
Clamp Down
to 'N' Terminal
Red
to 'L' Terminal
L
N
10
