200C Series
(Capacitive Ceramic)
Continuous Submersible Level Transmitter

Safety Information

Warning | Caution | Danger
Indicates a potential hazard. Failure to follow all
warnings may lead to equipment damage, injury, or
death
Note | Technical Notes
Highlights additional information or detailed
procedure.

Introduction

The 200C Series Levelpro Submersible Level Transmitters are manufactured for years of trouble free service in tough industrial
applications. The 200C Series Levelpro Submersible Level Transmitter measures the height of liquid above the position of the sensing
diaphragm of the transmitter located inside the tank referenced to atmospheric pressure. The transmitter consists of a ceramic piezo-
resistive sensing element, encased in PVC, PVDF, PP, or 316 SS housing.
The Large Diameter flush diaphragm is non-clogging and damage resistant to floating solids.
The 200C Series transmitter is equipped with a high tensile strength FEP (Teflon) shielded and vented cable. and contains an internal
non-wetted weight and utilizes Kalrez O-ring seals The Ventilation tube in the cable automatically compensates for changes in
atmospheric pressure above the tank.

General Information

This operating manual contains important information on proper usage of the device. Read this operating manual carefully before
installing and starting up the pressure measuring device.
Adhere to the safety notes and operating instructions which are given in the operating manual. Additionally applicable regulations
regarding occupational safety, accident preven-tion as well as national installation standards and engineer-ing rules must be complied
with!
This operating manual is part of the device, and should be kept nearest its location, always accessible to all employees.
This operating manual is copyrighted. The contents of this operating manual reflect the version available at the time of printing. It has
been issued to our best knowledge. Levelpro is not liable for any incorrect statements and their effects.
Limitation of Liability
By non observance of the operating manual, inappropriate use, modification or damage, no liability is assumed and warranty claims will be excluded.
Intended Use
The Levelpro Level Sensors have been developed for continuous level measurement. It is the operator's responsibility to check and
verify the suitability of the device for the intended application. If any doubts remain, please contact our technical department in order to
ensure proper usage and compatibility. Levelpro is not liable for any incorrect selections and their effects!
Permissible media are liquids (no solids or frozen media), specified in the data sheet. In addition it has to be ensured, that this medium is
compatible with the any wetted parts of the level sensor.
The technical data listed in the current data sheet are engaging and must be complied with. If the data sheet is not available, please
order or download it from our homepage. (www.iconprocon.com)
Package Contents
Please verify that all listed parts are undamaged included in the delivery and check for consistency specified in your order:
Probe
Mounting Instructions
IMPORTANT!
indicates situations or cases which, if not avoided,
could result in damage or failure of the Products
equipment.
Do Not Use Tools
Use of tool(s) may damage product beyond repair
and potentially void product warranty.
