10. Technical specifications
RJ45
868 MHz radio
Analogue input
Digital inputs
Digital outputs
Relay contacts
44 / 152
RouterNode 2 SmartBridge
Network interface

10T/100T

HP Auto_MDX

DHCP-Client (DHCP: on)

IPv4

Service

TCP: 1x at Port 2101
¬
UDP: 1x for Digi-Scan (OAM
¬
tool)
Web server: Enable

WaveNet interface, range up to
30 m
1x with 12-bit resolution from 0 to
3.3 V
DC
3x. An external contact connected
to VOUT changes the logic state
from 0 to 1.
Low/Logical 0: 0 V

High/Logical 1: 2.0 V

3.3 V
DC
Maximum voltage: 4.1 V

2x open drain.
1x change-over contact, potential-
free.
to 0.8 V
DC DC
to
DC
DC
