RouterNode 2 SmartBridge
Installation
Temperature
Humidity
Standard protection rating
Operating voltage
Output
Output VOUT
Relay output O1
Digital outputs O2/O3
EN
10. Technical specifications
horizontal

vertical

Wall mounting possible

Integrated strain relief (3x)

Operational: -10 °C to +55 °C

Storage: -20 °C to +60 °C

Max. 90%, non-condensing
IP20
9 V to 32 V (reverse polarity
DC DC
protected) or PoE according to
IEEE 802.3af
Power supply via PoE and round
plug possible simultaneously:
round plug > 12 V
used, round plug < 12 V
used
max. 3 W
3.0 V to 3.3 V
DC DC
Max. switching voltage 30 V

24V (resistive load)
AC
Max. switching current 1 A

(resistive load)
Max. switching voltage 12 V
max. switching current 100mA
(resistive load)
→ Round plug
DC
→ PoE
DC
, max. 200 mA
DC
,
DC
