Operating Manual
az
EasySet 2
Control computer
for ZG-TX
Please read this operating
MG7806
manual before initial operation!
BAG0255.1 12.23
Keep it in a safe place for future
Printed in Germany
use!
en

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EasySet 2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Amazone EasySet 2

Summary of Contents for Amazone EasySet 2

  • Page 1 Operating Manual EasySet 2 Control computer for ZG-TX Please read this operating MG7806 manual before initial operation! BAG0255.1 12.23 Keep it in a safe place for future Printed in Germany use!
  • Page 2 EasySet BAG0255.1 12.23...

  • Page 3: Table Of Contents

    Displaying the area efficiency ....................24     Performing residual emptying ....................24     Connection ....................25     EasySet 2 configuration ................26     Setting the modes ........................26     Calibrating the double shutter ....................26    ...

  • Page 4: Product Description

    Product description Product description overview (1) Switch On and Off button (2) Adjustment buttons Some with LED for showing the activated function (3) Buttons for control during operation Some with LED for showing the activated function (4) Display with LED Display ...

  • Page 5: Adjustment Buttons

    Product description Adjustment buttons  Adjust the spread rate  Adjust the working width, accord- ing to the setting chart and spreading disc  Determine / set the calibration factor  Select the simulated speed. Cali- brate the distance sensor, enter the pulses per 100 m.

  • Page 6: Buttons For Operation

    Product description Buttons for operation Start / stop spreading Start / stop spreading on the Start / stop spreading on the left right (ZG-TX with double shutter) (ZG-TX with double shutter) LED for spreading on LED for spreading on Higher rate Higher rate on the left Higher rate on the right (only for ZG-TX with double...

  • Page 7: Preparing The Easyset2

    Preparing the EasySet2 Preparing the EasySet2 Switching the EasySet2 on and off Switch on the EasySet 2.  The current software version is shown for 2 seconds.  The set mode is shown for one second.  The Work display appears.

  • Page 8: Entering Working Width

    Preparing the EasySet2 Entering working width Select the working width setting.  The working width is shown in m. Enter the working width. The value is automatically saved Switch back to the work display. Determining/entering the calibration factor for fertiliser or lime The calibration factor determines the regulating behaviour of the im- plement computer and depends on the flow characteristics of the ma- terial to be spread.
  • Page 9 Preparing the EasySet2 Lime  The calibration factor for lime approximately corresponds to the specific weight in kg/litre, about 1.6 kg/litre  Use the specific weight in kg/litre as a basic value before calibra- tion.  The basic value is optimised through calibration. ...
  • Page 10 Preparing the EasySet2 Determine the calibration factor The calibration is performed when the im- plement is at a standstill and without the spread- ing disc drive! 1. Prepare for fertiliser calibration, refer to the implement operating manual. 2. When calibrating with large quantities, weigh the implement with enough spreading material.
  • Page 11 Preparing the EasySet2 Carry out calibration: Start spreading.  The calibration time is shown.  The calibration can be stopped at any time.  Large quantities produce a more precise calibration value. Stop spreading as soon as enough spreading material was collected. Small quantities: fill the collection bucket completely.

  • Page 12: Simulated Speed / Distance Sensor

    Preparing the EasySet2 Simulated speed / distance sensor Select  Depending on the last entered setting, the value for the pulses per 100 m or the value for the simulated speed will be displayed. Pulses per 100 m display:  Possible values from 250 to 35000.
  • Page 13 Preparing the EasySet2 Switching from the speed simulator to the distance sensor The shutter must be closed. Press until the speed simulator display reaches 30 (km/h). Press until the display changes from 30 (km/h) to 250 (pulses).  The pulses per 100 m can now be entered. ...

  • Page 14: Calibrating The Distance Sensor (Pulses Per 100 M)

    Preparing the EasySet2 2.5.1 Calibrating the distance sensor (pulses per 100 m) The on-board computer needs the "Pulses per 100 m" calibration value to  determine the actual forward speed [km/h].  determine the worked area. If the calibration value is not known, it must be determined by means of a "Pulses per 100 m"...
  • Page 15 Preparing the EasySet2 Determining the pulses per 100 m 1. Measure a calibration distance of exactly 100 m. 2. Mark the start and end points. 3. Drive up to the starting point. Press and hold the button for 6 seconds. ...

  • Page 16: Setting The Simulated Speed

    Preparing the EasySet2 2.5.2 Setting the simulated speed. Selecting a simulated speed enables working with the implement with- out a speed signal (distance sensor / pulses per 100 m). The forward speed must correspond to the simulated speed during operation. Otherwise, the correct spread rate will not be achieved. Select the simulated speed.

  • Page 17: Switching The Spreading Disc Speed Monitoring On/Off

    Preparing the EasySet2 Switching the spreading disc speed monitoring on/off Switching on the speed monitoring for normal spreading 1. Read the spreading disc speed to be moni- kg/ha tored from the setting chart. Switch the right side of the work display to the spreading disc speed.
  • Page 18 Preparing the EasySet2 Switching on the speed monitoring for boundary spreading 1. Read the spreading disc speed to be moni- kg/ha tored from the setting chart. Switch on boundary spreading. When spreading lime, only the LED shows the status. Switch the right side of the work display to the spreading disc speed.

  • Page 19: Using The Easyset2

    Using the EasySet2 Using the EasySet2 Spreading  Enter the values for the spread rate in kg/ha and the working width before operation.  Determine the calibration factor. 1. Read the switch-on point and switch-off point from the setting chart. Switch on the implement and the work display will be shown.

  • Page 20: Setting The Spreading Disc Speed Monitoring

    Using the EasySet2 3.1.1 Setting the spreading disc speed monitoring Show the spreading disc speed on the work display. Press and hold the button to save the current spreading disc speed as the nominal speed.  The nominal speed is monitored at +/- 50 rpm.

  • Page 21: Changing The Spread Rate

    Using the EasySet2 3.1.2 Changing the spread rate During operation, the spread rate can be changed by 10% each time the button is pressed. Moreover, the originally set spread rate (100%) can be restored. (1) Change the spread rate on the left (only with double shutter) (2) Change the spread rate on both sides (3) Change the spread rate on the right (only...

  • Page 22: Boundary Spreading

    Using the EasySet2 Boundary spreading 3.2.1 Boundary spreading with AutoTS for fertiliser Depending on the boundary spreading method, the spread rate must be reduced on the boundary side. 1. Read the percent rate reduction from the setting chart. Before boundary spreading / ditch spreading, reduce the rate on the boundary side.

  • Page 23: Boundary Spreading With Boundary Spreading Device For Lime

    Using the EasySet2 After boundary spreading: Switch off AutoTS.  The LED is turned off. If necessary, increase the spread rate on the boundary side back to 100%. 3.2.2 Boundary spreading with boundary spreading device for lime 1. Actuate the tractor control unit. ...

  • Page 24: Displaying The Area Efficiency

    Using the EasySet2 Displaying the area efficiency Daily counter: Display the worked area in ha since the last reset. Press and hold the button for 6 seconds to reset the daily counter. Total area efficiency: The total area efficiency in ha is shown for 2 seconds after switching off and cannot be reset.

  • Page 25: Connection

    Connection Connection (1) Connection cable 12 V (2) Equipment for installing the EasySet 2 in the tractor cab (3) Implement plug to connect the implement to the EasySet 2. Store the control computer in a dry place when you remove it from the tractor cab.

  • Page 26: Easyset 2 Configuration

    04 - Lime boundary spreading device hy- draulically actuated with position sensor and AutoTS boundary spreading Automatic switching for conversion to lime and fertiliser Save boundary spreading device mode.  EasySet 2 is automatically switched off. Calibrating the double shutter EasySet BAG0255.1 12.23...
  • Page 27 If the desired and actual spread rate do not concur.  After installing the double shutter. EasySet 2 is switched off! 1. Press the Power on, rate left + and right + buttons simultaneously and hold for 3 sec- onds.

  • Page 28: Autots Calibrate

    The current calibration values are flashing. Calibrate the normal spreading po- sition.  The new calibration value appears non- flashing. Calibrate the boundary spreading position.  The new calibration value appears non- flashing. Switch off the EasySet 2. EasySet BAG0255.1 12.23...

  • Page 29: Diagnosis Menu

    The current voltage is displayed. Press and hold the button for 15 seconds. The current value is displayed. Switch off the EasySet 2 to exit the diagnosis. In the Diagnosis menu, the setting motors are directly actuated with full power.

  • Page 30: Error Messages

    30 Warning Implement plug not Operation not pos- Insert the imple- connected. sible. ment plug on the EasySet 2 Warning The left shutter is not Drive deactivated. Check motor responding; the actu- Eliminate the Restart required. ated setpoint position blockage, refer to cannot be reached.
  • Page 31 Error messages Warning The position for The value has devi- Recalibrate. boundary spreading ated from the calibra- Check the posi- cannot be reached. tion factor. tions and free- wheel of the spreading vanes. Warning Calibration factor for The motor cannot Check the boundary spreading reach the tolerance...
  • Page 32 Error messages EasySet BAG0255.1 12.23...

  • Page 33: Overview

    Overview Overview 1. Spreading on / off 2. 6 seconds  residual emptying Ml20 Spreading on Spreading on the left the right on / off on / off (ZG with (ZG with double double shutter) shutter) Target rate on both sides higher / lower / 100% Spreading on the Spreading on the...
