Keep hair, loose clothing, neckties, jewelry, fingers, and all parts of body away from all moving parts. Do not place any tools,
weights, or other objects on the safety hood while operating the balancer.
ALWAYS WEAR OSHA APPROVED SAFETY GLASSES. Eyeglasses that have only impact resistant lenses are NOT safety
glasses.
Keep the safety hood and its safety interlock system in good working order. Verify that the wheel is mounted properly and
that the wing nut is firmly tightened before spinning the wheel. The safety hood must be closed before touching the green
"START" button, to spin the wheel.
Raise safety hood only after wheel has come to a complete stop. If safety hood is raised before the spin is completed,the
weight values will not be displayed.Do not let cord hang over any edge or contact fan blades or hot manifolds. The red
"STOP" button, can be used for emergency stops.
DANGER
Never reach under the hood while the balancer is performing a run out measurement or balance spin.

1.3. Electrical

The Hunter HD Elite Balancer is manufactured to operate at a specific voltage and amperage rating. Make sure that the
appropriate electrical supply circuit is of the same voltage and amperage ratings as marked on the balancer.
DANGER
DO NOT ALTER THE ELECTRICAL PLUG. Plugging the electrical plug into an unsuitable supply circuit will
damage the equipment.
Make sure that the electrical supply circuit and the appropriate receptacle is installed with proper grounding. To prevent the
possibility of electrical shock injury or damage to the equipment when servicing the balancer, power must be disconnected
by removing the power cord from the electrical power outlet.
After servicing, be sure the balancer ON/OFF switch is in the "O" (off) position before plugging the power cord into the
electrical power outlet. This device is rated as Class A for radiated emissions.In the event of radio interference, the display
read out may flicker - this is normal.

1.4. Decal Information

RIGHT SIDE VIEW
Decal HD Elite28-HD Elite 244-2 cautions the operator that spindle rotation may occur with foot pedal depression and to
keep clear of clamping components during shaft rotation.
Decal HD Elite 28-964-2 gives the maximum wheel diameter and maximum wheel weight for the HD Elite.
EN/IEC Class HD Elite Laser Product Certification is shown on Decal HD Elite 28-HD Elite 638-2. This labels shows the
EN/IEC standards for a Class HD Elite Laser Product.
An explanation of FDA compliance standards is shown on Decal HD Elite 28-HD, Elite HD Elite 7-2. FDA performance
standards compliance is shown on the decal.
