Building Structure - atd models ATD009 Instruction Manual

8a. Now turn the building on its side. Detach the
Ground Floor and glue it into the building.
You will notice that there are notches
i
cut out in the wall that will align with the tabs
on the floor like a jigsaw.
You may find it easier to apply glue inside
the notches before positioning the tabs.
8b. Detach two of the columns. Fold the score
lines on each of the columns, apply glue to
the tab and bond.
8d. Like step 8a, detach the First Floor and glue it into position. Then like Step 8c, glue two more
columns into position on the First Floor.
Repeat this process until the Fourth floor is glued into position.
9a. Detach the Trussing (x4). Carefully fold each
truss, back to back, along the score line and
glue them together.
8c. Glue the columns into position.
You will notice that we have marked the
i
recommended location of the column on the
floor.
9b. Glue the Trussing into position, as per the
illustration below.
