Assembly Instructions - atd models ATD009 Instruction Manual

1. Detach Wall A and place it face down on your work surface. Then fold the tabs over on themselves
and glue. Repeat this step for Wall B.
Apply firm pressure on the tabs until the glue is semi cured to stop them from lifting.
i
2a. Detach Wall E and glue it to Wall A.
The window openings on Wall E are slightly
i
smaller than the window openings on Wall A.
Position Wall E so that there is around a 1mm
buffer along the two sides and bottom edge.
3a. Locate the Glazing Sheet, then cut out the windows and glue them into position, as per the
illustration below.
Ensure that you cut out the glazing along the thin, outer black lines. This will allow an overhang on
i
each piece of glazing making them easier to glue into position.
3b. Detach the main doors and glue them it
into position.
We have scored the doors giving you the
option to have them open by carefully
i
running the blade across the score lines.
2b. Detach Wall F and glue it to Wall B.
The window openings on Wall F are slightly
i
smaller than the window openings on Wall B.
Position Wall F so that there is around a 1mm
buffer along the two sides and bottom edge.
