SNOM M Series

User Guide

Instructions for

Snom M Series.

Table of Contents

Need help?

Do you have a question about the M Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Snom M Series

Page 1 SNOM M Series User Guide Instructions for Snom M Series.
Page 2: Table Of Contents
Snom M Series User Guide Contents Snom M Series User Guide Getting Started Setting up Snom M Series Devices Setting Up the Snom M30/M70 Pairing the Snom M30/M70 Quick Tips Snom M400 Hardware Features Snom M30 Hardware Features Snom M70 Hardware Features...
Page 3 Snom M Series User Guide Snom M Series Models Snom Snom Snom M400...
Page 4: Getting Started
Please ensure you do not plug your Snom Devices in or connect them to the internet until instructed to do so by the Onboarding Team. It is vital that Snom Devices have been added to the UC (Unified Communications) Portal by the Onboarding Team prior to activation.
Page 5: Setting Up Snom M Series Devices
The steps to set this up are as follows: Setup: Power over Ethernet The first step is to plug the Ethernet Cable into the Port at the back of the Snom M400 Base Station (Outlined in the above image as B).
Page 6 Snom M Series User Guide No Power over Ethernet If required, connect the 5V USB power adapter to the Snom M400 Base Station (Outlined in the above image as A). Once completed, the Base Station will begin to initialise. There is an LED indicator, located at the bottom of the device, which provides a signal status on the unit.
Page 7: Setting Up The Snom
Setting up the Snom M30/M70 Snom M30 Setup To setup the Snom M30 handset the steps are as follows: Push the cover of the battery compartment downward to get access to the pull tab of the battery. Pull the tab away from the handset at a 90-degree angle until it is free from the battery.
Page 8 Snom M Series User Guide Snom M70 Setup To setup the Snom M70 handset the steps are as follows: Unlock the battery cover on the back of the handset by pushing the lever anticlockwise onto the open symbol. Remove the battery cover from the back of the handset Pull the tab away from the handset at a 90-degree angle until it is free from the battery.
Page 9: Pairing The Snom M30/M70
I.E. Line 1, 1000, Kitchen etc. Pairing an Additional Handset To pair an additional handset to the Snom M400 base station, the steps are the same as above, once the Onboarding Team has confirmed the device is ready.
Page 10: Quick Tips
Quick Tips Call Transferring You can choose between attended and blind transfer to transfer calls on the Snom M30/M70 handset. The steps for both are outlined below: Attended Transfer With a call on the line, press the Hold softkey. This will place the call on hold...
Page 11 Snom M Series User Guide Blind Transfer: Incoming Call To transfer a call that is incoming on your handset, press the Transfer softkey. Enter the number you wish to transfer the call to Press the Transfer softkey The call will begin ringing on the other party’s handset. Your handset will display a...
Page 12 Snom M Series User Guide Call Forwarding The Snom M30/M70 handset can be set to forward calls under three circumstances: Unconditionally, Busy or No Answer. Forward Unconditionally: If this option is selected it will forward all calls to a specified...
Page 13 Ensure that Enabled is highlighted and press Select Muting a Call on Snom M30 The Snom M30 does not have a dedicated Mute button, so to mute the microphone, you need to do the following: When on a call, press the left side of the navigation key...
Page 14 Snom M Series User Guide Changing the Volume on Snom Snom M30 The M30 handset does not have a dedicated volume key. To adjust the volume when on a call, use the up and down rim of the navigation key.
Page 15: Snom M400 Hardware Features
Snom M Series User Guide Snom M400 Hardware Features...
Page 16 Snom M Series User Guide Hole for Wall Mounting: This will allow you mount the M400 Base Station to a wall if required Hole for Wall Mounting: This will allow you mount the M400 Base Station to a wall if required.
Page 17: Snom M30 Hardware Features
Snom M Series User Guide Snom M30 Hardware Features...
Page 18 Snom M Series User Guide Speaker: Provides ringer and audio output. Battery Charge Status: Indicates the level of battery left on the device Settings Menu: Allows you open the menu and select from different options. Cancel Key: Can be used to cancel actions and calls as well as allowing you to return to the previous screen.
Page 19: Snom M70 Hardware Features
Snom M Series User Guide Snom M70 Hardware Features...
Page 20 Snom M Series User Guide Speaker: Provides ringer and audio output. Battery Charge Status: Indicates the level of battery left on the device Settings Menu: Allows you open the menu and select from different options Cancel Key: Can be used to cancel actions and calls as well as allowing you to return to the previous screen.
Page 21 1-888-770-0971 | www.blueface-connect.com | sales@blueface-us.com...

This manual is also suitable for:

M30 M70 M400
